HungTurn UTS-232AD Quick Installation Manual

USB TO RS-232/RS-422/RS-485 ADAPTER For Android

Introduction

The USB to serial adapter enables you to connect a RS-232, RS-422, or RS-485 device to a smart phone or tablet
with Android OS.
Designed for mobility and integration into mixed environments
barcode scanning etc.;
version 3.2 Honeycomb or later devices including the Samsung Galaxy Note®, Galaxy® S5, S4, S3, or S2, Google
Nexus 7™, 5, or 4, and Motorola or HTC mobile devices.
Exception: serial mouse, serial printer, or serial modem is not for application.

System Requirements

Android OS Version 3.2 Honeycomb or later

Features

Fully Compliant with USB Specification 1.1 and 2.0
USB to Straight-Through RS-232/RS-422/RS-485 DB9 Serial Adapter for Android.
Supports data transfer rate up to 230 kbps (RS-232), 921 kbps (RS-422/RS-485); or up to 115kbps with no
flow control.
Standard UART interface (RX, TX, RTS, CTS and GND pins)
UART TX buffer size is 256 bytes, UART RX buffer size is 5512 bytes.
Supports ±15kV HBM ESD protection
Supports OTG (On-The-Go) mode but no external OTG cable is required.
Powers and charges the connected Android device, USB-powered via PC USB port, USB wall charger, or
USB mobile battery pack.
Compatible with Android OS Version 3.2 Honeycomb or later. (Suitable for use on any Android platform
supporting Android open Accessory Mode)

Specification

Model No.
Chipset
USB Specification
Data Transfer Rates
Connector
LED
Power Mode
Cable Length
Housing

Quick Installation Guide

this portable and lightweight single cable solution is compatible with nearly all Android OS
USB
Serial
Upstream
Device
USB Micro B/M
USB A/M
such as Controlling instrumentation, Home automation,
UTS-232AD
USB 1.1/2.0 compliant
1.5 / 12 Mbps
230 kbps
USB Type A Male X 1; USB Micro-B Male X 1
Bus or External Powered
1-6
UTS-422AD UTS-485AD
FTDI
921 kbps
DB-9/M
3
1.1m
0.3m
Plastic
