Summary of Contents for Solomend HD PVR 800
- Page 1 HD PVR 800 ============== Solomend DVB-S2 High Definition Set Top Box ================= User Manual...
-
Page 2: Safety Instructions
Safety Instructions This product has been manufactured to applicable the international safety standards. Please read all of safety and operating instructions before operating the product and keep this manual for future reference. Main Power Supply AC 90-250V, 50/60Hz, Operate your product only from the type of power supply indicated on the marking label. - Page 3 Safety Precaution CAUTION: The lightning flash with arrowhead Warning: The exclamation point within an symbol, within an equilateral triangle, To reduce the risk of electric shock, equilateral triangle is intended to is intended to alert the user to don't open the cabinet.
- Page 4 Attachments: Never add any attachments and/or equipment without the manufacturer consent; as such additions may result in the risk of fire, electric shock, or other personal injury. Locating: Slots and openings in the cabinet are provided for ventilation to protect it from overheating. Do not block these openings or allow them to be blocked by placing the STB on a bed, sofa, or other similar surface, nor should it be placed over a radiator or heat register.
- Page 5 Features Accessories Main board (DB-M3602-02V01), ALi 48 Keys IR controller, USB HDD BOX(customer option) Board configuration 396MHz MIPS CPU, 128MB DDR400 RAM, Memory Clock 198Mhz, 2MB Serial Flash, Single Tuner, DVB-S2 demodulator, Power Supply Input 100V ~ 240V 50/60Hz Power Consumption 30W Max / 1W Standby (it’s optional by customer’s board) RS232...
-
Page 6: Table Of Contents
CONTENTS 1. REMOTE CONTROL 2. BASIC OPERATIONS 2.1 Turn on STB 2.2 Power 2.3Channel UP/Channel down 2.4Volume UP/Volume Down 2.5 Number 2.6Mute 2.7 Pause 2.8Recall 2.9Favorite 2.10 Audio 2.11 Information 2.12 EPG 2.13 TV/RADIO 2.14 Channel List 2.15 Sleep 2.16 Page UP/Page Down 2.17Multi Picture 2.18 TEXT 2.19 Subttile 2.20 Find 2.21 Zoom 2.22 TV/STB 2.23 Menu 2.24 Exit 3. CHANNEL 3.1 TV Channel List 3.1.1. Favorite 3.1.2. Lock 3.1.3. Skip 3.1.4. Move 3.1.5. Edit 3.2Radio Channel List 3.3Delete All ... - Page 7 4.INSTALLATION 4.1 Antenna Connection 4.2 Satellite List 4.3 Antenna Setup 4.4Single satellite search 4.5Multi satellite search 4.6 TP LIST 4.7 Other 5. SYSTEM SETUP 5.1 Language 5.2 TV System 5.3 Local time setting 5.4 Timer setting 5.5 Parental Lock 5.6 OSD setting 5.7 Favorite 6. Tool 6.1Information 6.2 Factory Setting 6.3Upgrade by RS232 6.4 COMMON INTERFACE 6.5 Upgrade By USB 6.6 Remove USB Device Safety 7. NETWORK LOCAL SETTING 7.1 NETWORK LOCAL SETTING 8. REC 8.1 MUSIC&PICTURE 8.2 RECORD MANAGER 8.2.1 LOCK 8.2.2 Delete 8.2.3 Rename 8.3 HDD Information 8.4 HDD Format 8.5 Time shift 8.6 Jump ...
- Page 8 Quick Start Connect your STB to TV by A/V Cable. You have 3 methods. Methods 1: If your TV is a standard definition TV and does not has components input port, please use a 3 lines cable (yellow, red and white) to connect your STB’s CVBS, Left analog audio port, right analog audio port to your TV’s corresponding port.
- Page 9 Turn on your STB power, select a satellite in satellite list menu and then enter the Antenna setup to config exact parameters of this antenna, select Single Satellite Search and select auto scan to search programs. If you want to want to get high picture quality, please check how big resolution could your TV support, and press V.Format key to switch your STB output.
-
Page 10: Remote Control
1. Remote Controller... -
Page 11: Basic Operations
2. Basic Operations 2.1 Turn on STB First, press the [Device’s Main Power] to turn on the Unit When the STB is first used, there will play the first channel from the default Channel List. If the STB is not first used, STB will play the same channel as last time before turning off. -
Page 12: Pause
2 Press [MUTE] key again to restore sound. 2.7 Pause 1 In playing mode, press [Pause] key, the picture will be paused, but the sound of the channel will still continues. 2 Press [PAUSE] key again, the screen’s picture will skip over to the current playing picture, and the sound of the channel will corresponding playing. -
Page 13: Information
3 Mode: Left/Right/Stereo/Mono 2.11 Information In full screen, press [INFO] key can open information screen, in the window shows the parameters of current channel. 2.12 EPG 1 The STB has an Electronic Program Guide (EPG) to help you navigate channels through all the possible viewing options. -
Page 14: Tv/Radio
2.13 TV/RADIO In TV mode, pressing [TV/RADIO]key can switch to radio mode. In radio mode. Press [TV/RADIO] key to switch to TVmode 2.14 Channel List 1 In full screen, press [OK] key or [CH List]can enter “Channel List”. 2 Press [Left/Right] key to change satellite. 3Press [Up/Down] key to move highlight and press [OK] key to play the highlighted channel. -
Page 15: Zoom
The search result display on the right screen. You can press [Red] key to delete the char, press [Blue] key to confirm, press [Green] key to cancel. 2 Pressing [Exit] key can close “Find” window. 2.20 Zoom 1 The [ZOOM] key allows you to magnify a certain area on the images 2 Press [ZOOM] key again, the image will enlarge rotate as x1, x2, x4, x6, x8, x12, x16. -
Page 16: Channel
3. Channel When you press [Menu] key to enter menu, there will display the picture like below: 1 Press [Up/Down] key to select menu pages among Edit Channel, Installation, System Setup, Tools and Game. 2 Press [OK] or [Right] key to enter the “Edit Channel”... -
Page 17: Lock
4 After marking, pressing [Exit] key can back to “TV Channel List” , there will show a favorite mark beside the marked channel. 3.1.2. Lock 1 Press [Red] key can enter lock mode. 2 Press [Up/Down] key to move the highlight and press [OK] key, it will display a dialogue to ask you to input password. -
Page 18: Radio Channel List
3.1.5.1. Sort 1 Press [Red] key can open the “Sort” window like above. There are four kinds of sorting ways. You can press [Channel Up/Channel Down] key to move highlight and press [OK] key to confirm you selection. 2 The five kinds of sorting way are: Name (A-Z): Sorting in Alphabetical Order, ignore “$”... -
Page 19: Delete All
“Radio Channel List” mode, there is no video information, so it will always display Radio’s logo in the right side preview window. 3.3 Delete All 1 Press [Ok] key, it will show up a warning message box to inquire you whether delete all or not. -
Page 20: Antenna Connection
Installation 1 Press [Up/Down] key to select menu pages among Edit Channel, Installation, System Setup, Tools , network local setting nd REC(multimedia) 2 Press [OK] or [Right] key to enter the “Installation”. If Menu Lock is “On”, it will display an dialogue for user to key in password. -
Page 21: Antenna Setup
3 Press [Yellow] key, you will be asked “Are you sure to delete?”. Select “Yes” to delete the satellite that highlight focus on. Select “No” to cancel the operation. 4.3 Antenna Setup Fixed Antenna If you select “Fixed Antenna” in “Antenna Connection”... - Page 22 1 LNB Type: 5150/5750/5950/9750/10000/10050/10450/10600/10700/10750/11250/11300/515 0-5750/5750-5150/ Universal(9750-10600)/Unicable(9750-10600)/ Unicable10200 2 Motor Type: DiSEqC1.2/USALS 3 Local Longitude/Local Latitude: If you select “USALS”, “Local Longitude / Local Latitude” is available. Press [OK] and number key to input. 4 Delete All: This operation will delete all satellite positions. It will display a dialogue “Are you sure…”.
-
Page 23: Single Satellite Search
Switching the satellite can move the dish to the right place. 6 Limit Setup: 1 When you set “limit setup” to “West Limit/ East Limit”, you can move the highlight to “Limit Setup” line and move the dish to west or east by pressing [Left/Right] key manually. - Page 24 1 In “Satellite” item, press [Enter] key to see the selected satellite. The system will use DiSEqC1.0/ DiSEqC1.2 / USALS function to search satellite and scan channels. It will scan all the satellite displaying in the bottom box. scanning channel. 6 In the “Multi Search”...
-
Page 25: Other
3 Press [Green] key, open new TP menu. User can add a new TP. 4 Press [Yellow] key will open dialog box asking you whether confirm to delete current TP. When select “Yes”, you will delete the channel which highlight focus on. When select “No”, it will cancel the operation. -
Page 26: Language
3 Press [Up/Down] key to select menu items among TV channel, Radio Channel and Delete All. 4. Press [Left] key or [Exit] key to go back to main menu. 5 Language When you enter to “Language” menu, you will see the screen like below. 1 Language: press [Volume Up/ Volume Down] key to select menu languages, the selections of languages include:... -
Page 27: Local Time Setting
Auto means system won’t do any asp ect ration translation, 16:9 picture source will be good display on a 16:9 TV but will be too narrow on a 4:3 TV, and 4:3 picture source will be too wide in a 16:9 TV but will be good display in a 4:3 TV. 3 RF system and RF channel are for user to set the TV RF modulator output signal VHF/UHF channel and TV system mode. -
Page 28: Parental Lock
modify the time information in “Time” item. 2 Timer Mode: There are several modes for Timer to setting, include Off, Once, Daily 3 Wakeup Channel: press [OK] key to enter channel list and select channel that you want to setting. 4 Wakeup Date: use number keys to input your wakeup date. -
Page 29: Information
2 OSD Transparency: You can press [Volume Up/Volume Down] key to select the values. There are 5 levels of transparency, 10%, 20%, 30%, and 40% and “NO” (means no transparency function). 3 Press [Exit] key to draw back from the “OSD Setting” menu. 5.7 Favortie When you input to “Favorite”... -
Page 30: Common Interface
1 It will show a warning message to inquiry you “The operation will load default and erase all the channels that user added, continue?”. 2 If you select “Yes” option, the revised parameters of the receiver will reset to default value. Please carefully to using this function. -
Page 31: Remove Usb Device Safety
Open Upgrade By USB menu according to Menu -> Tools-> Upgrade By USB. Upgrade Mode has only 1 option: All Code, it means that you can only upgrade whole file to your STB’s flash. Please rename your new fw file name to be the format“all*.abs”, * means any others string is acceptable, but the initial 3 letters must be “all”... -
Page 32: Rec
When you enter to “REC” menu, you will see the screen like below: 1 Press [Up/Down] key to select menu pages among Edit Channel, Installation, System Setup, Game and REC. 2 Press [OK] or [Right] key to enter the ”REC”. If Menu Lock is “On”, it will display a dialogue for user to key in password. -
Page 33: Record Manager
Size(Screen)select: Real: show the real size if the image size less than full screen size, but only partial image, the image is shown from left Top corner, don’t show for over part. Full: Full screen display and show real size if the image is less than screen: Menu operation: (1) Setup option... -
Page 34: Lock
8.2.1 Lock 1 Press [Green]key to lock a program on HDD. 2.If you want to cancel the lock mark for a program, press[Green] key again. It will ask you input password. Once you input the correct password, it will cancel the lock feature for the program. 8.2.2 Delete 1 Press [Blue] key to make a delete mark on the highlight program. -
Page 35: Jump
2 press [Left/Right] to switch timeshift “on/off”. 3 If set timeshift “on”, it will tiemshift the program when user watch TV. 4 Press [Info] key to see timeshift OSD as below. 5 You can press [Left/Right] to move the slide to left or right. But can not exceed the current time.
