- Page 1 INSTALLATION INSTRUCTIONS (English) WWW.BRINKAIRFORLIFE.NL 614796-B...
-
Page 2: Installation Instructions
English (EN) Installation instructions Humidifier for central ventilation with heat recovery KEEP WITH THE PRODUCT This product may be used by children aged 12 years and over, persons with reduced mental capacity, physical limitations or lack or experience and knowledge if they are supervised or have been instructed in the use the product safely and are aware of the possible hazards. -
Page 3: Table Of Contents
Table of Contents Delivery Scope of supply Accessoires Evap humidifier Operation Principle of operation Safety Description of the components Description of the components Technical specifications Specifications Illustrations Setup Order of operation Faults Maintenance Procedure for replacing Evap cassette Wiring diagram Service Service products Declaration of Conformity... -
Page 4: Delivery
Section 1 – Delivery Scope of supply Before installing the Evap, check that the Evap Air Humidifier is complete and undamaged. The following components are supplied with the Evap humidifier: An EPP housing fitted with 2 round connections of R200 mm. The following components are attached to the housing: •... -
Page 5: Operation
Section 2 – Operation The purpose of the Evap is to humidify air passing through wetted media in an energy-efficient, silent and safe way. The adiabatic humidification process is carried out in the humidifier unit and increases the humidity in the air supply to the room. -
Page 6: Use
Section 3 – Use The Evap can be used on any central balanced ventilation system. Description of the components The main components of the Evap are: The housing The housing of the Evap is made of EPP (expanded polypropylene). The advantages of this material are its low weight, good water tightness, good air tightness and recyclability. -
Page 7: Technical Specifications
Section 4 – Technical specifications Specifications Description Dimensions LxBxH 258 x 344 x 340 mm Humidification capacity 0-4 litre Load capacities 230V/ 50HZ Maximum power consumption 800 W/h Average annual consumption 160 kWh Maximum water consumption 5 litre per hour Water supply connection ¾... -
Page 8: Setup
Section 5 – Installation Order of operation 1. Locate the Evap air humidifier in the air supply duct as close as possible to the HRV unit. The minimum distance after a bend is 150mm. 2. It is important during installation that sufficient clearance is available so that the Evap humidifier can be rotated at all times without the need for dismantling when replacing the Evap cassette. -
Page 9: Faults
Section 6 – Faults When the control in the Evap detects a fault, this is displayed at the bottom of the product by the alarm symbol (bell) by means of an LED. To reset the alarm the product must be briefly disconnected from the power supply by removing the plug from the socket and then replacing this in the socket after 10 seconds. -
Page 10: Maintenance
Section 7 – Maintenance The Evap humidifier is equipped with a removable cassette (product code 351025) in which a matrix and LegioSafe filter are fitted. The matrix cannot be cleaned. The Evap cassette must be replaced as soon as the service indicator light for filter replacement is illuminated, but at minimum every 2 years. -
Page 11: Wiring Diagram
Section 8 – Wiring diagram Evap... -
Page 12: Service
Section 9 – Service Service products Product description Product code Evap cassette + LegioSafe 351025 Evap cassette 351026 Evap air heater 351027 Evap water valve 351028 Evap drain 351029 Evap knee 351030 Evap PCB 1 351031 Evap... -
Page 13: Declaration Of Conformity
Under the EC Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU we declare that the product Evap humidifier has been developed and constructed in accordance with these Directives. Supplier: Brink Climate systems B.V. Address: Postbus 11 NL-7950 AA Staphorst, The Netherlands... - Page 14 BRINK CLIMATE SYSTEMS B.V. Postbus 11 NL-7950 AA Staphorst Wethouder Wassebaliestraat 8 7951SN Staphorst T. +31 (0) 522 46 99 44 F. +31 (0) 522 46 94 00 info@brinkclimatesystems.nl www.brinkclimatesystems.nl...
