Summary of Contents for RED SHIELD Boltek Zumi IPC-135
-
Page 1: User Manual
Red Shield SENSOR SERIES Z MI IP-Camera • Remote access, motion detection alert & two-way audio User Manual Model No. IPC-135... -
Page 2: Table Of Contents
Index Part A – Introduction 1. Package Contents 2. Product Introduction Part B – Start Guide 3. Prepare for Starting 3.1 Connecting to your home network 3.2 Login the "BOLTEK" app 3.3 Entry from “System Control" 4. Getting Started 4.1 Connect hard ware 4.2 Add new device from your app 4.3 Link up to Smart Panel 4.4 Successfully added a device on the app... -
Page 3: Package Contents
Part A: Introduction 1. Package Contents • Zumi IP- Camera • Wall mounting unit • Antenna x 2 • Power adaptor • Screw pack • User manual • Quick setup guide 2. Product Introduction Wifi antenna RF antenna Light sensor Lens Infrared Lens cover... -
Page 4: Prepare For Starting
Part B: Start Guide 3. Prepare for Starting 3.1 Connecting to your home network Connect using LAN Cable Zumi Router Adaptor Power LAN cable LAN cable (Internet) Connect using Wifi Zumi Router Adaptor Power LAN cable (Internet) • Connect Zumi to your home internet network before getting started. •... -
Page 5: Entry From "System Control
3.3 Entry from "system control / IP CAM" Carrier Carrier 100% 100% IP Camera IP Camera Back Back BOLTEK 1 BOLTEK 1 IP Cam Add Camera & Wi-Fi Add Camera & Wi-Fi Multi View Multi View IP Cam IP Cam Event Event Photo... - Page 6 WiFi Setup Search Camera Carrier Carrier 100% 100% Carrier Carrier 100% 100% Carrier Carrier 100% 100% Back Back Onekey Config Onekey Config IP Camera IP Camera Add Camera & Wi-Fi Add Camera & Wi-Fi IP Camera IP Camera Add Camera & Wi-Fi Add Camera &...
-
Page 7: Getting Started
5. Locating Zumi after Getting Started 5.1 Determine the location First, determine the location and monitor area of Zumi, which should be placed: -Within a few feet of an electrical outlet. -Within effective distance from BOLTEK: 100m (open area). -In the most vulnerable rooms or near key points. -Where better RF performance can be achieved. -
Page 8: Adjusting The Camera Focus
5.4 Adjusting the camera focus If the camera’s view or focus is unsatisfactory after it has been mounted, you can adjust the camera lens by: -Remove the lens cover by rotating anticlockwise a little. -Rotate the ring of the lens clockwise or anticlockwise while watching the app in live view to optimize the view. -Fix the lens cover back on. - Page 9 Tap on the live view screen to see more setting options: Framerate: 9 / 12 F ramer Framer Framer Framer Framer ate: 9 ate: 9 ate: 9 ate: 9 ate: 9 / 12 / 12 / 12 / 12 / 12 / 12 4908 B [1280x720] [b:256] 4908...
-
Page 10: Camera Setting
Framerate: 9 / 12 F ramer Framer Framer Framer Framer ate: 9 ate: 9 ate: 9 ate: 9 ate: 9 / 12 / 12 / 12 / 12 / 12 / 12 4908 B [1280x720] [b:256] 4908 4908 08 B 08 B 08 B 1280x... -
Page 11: Multi View
Camera Name Sensitivity Restart Record Settings Carrier Carrier 100% 100% Carrier Carrier 100% 100% Carrier Carrier 100% 100% Carrier Carrier 100% 100% Edit Settings Edit Settings Camera 01 Settings Camera 01 Settings Back Back Back Back Alarm Settings Alarm Settings IP Camera IP Camera Back... -
Page 12: Event
9. Event Carrier Carrier 100% 100% Carrier Carrier 100% 100% Alarm Event Logs Alarm Event Logs Alarm Logs Alarm Logs Back Back Back Back Motion Detected Motion Detected Dec 27, 2015 Dec 27, 2015 BOLTEK 1 BOLTEK 1 06:17 am 06:17 am Camera 01 Camera 01... -
Page 13: Video
Part D: Working with the Smart Panel / Remote 12. Arm / Disarm the Smart Panel 06:30PM 06:30PM 06:30PM 31/12/2016 31/12/2016 31/12/2016 STATUS: STATUS: STATUS: disarm After Zumi has been added to the panel, it can be used in all the 3 modes: ARM, ALERT, HOME. You can arm or disarm the system in 3 ways: from the Smart Panel, the remote control, or the mobile app. -
Page 14: Maintenance Of Equipment
Part E: Maintenance and Tips 15. Maintenance of equipment • The product can be cleaned with a soft dry cloth. Do not use abrasive, solvent based or aerosol cleaners as this may damage and / or discolor the product. • Do not allow water to enter or attempt to clean the inside of the unit. If the camera is affected with damp, please use a soft dry cloth as soon as possible. -
Page 15: Reset
Network Smart Alarm Motion detective / Build-in Siren / Connect to WS-135 smart panel Triggered Alarm siren / Video record (E-mail / SMS / App notification) Record Triggered / Manual / Schedule RF (Radio Frequency) 433.92 Mhz Protocol TCP / IP, HTTP, etc. Reset Button Data Storage Maximum 32G SD Card / Smart phone / Tablet... -
Page 16: Customer Contact Details
Q: Can I still use the same equipment if I move and change a WiFi network? A: The Red Shield SNAP-Console System is completely portable. When you move, you can unmount your security accessories and re-install them in your new property. - Page 17 Powered by DC adaptor Powered by DC adaptor (i (i FEATURE: • A member of Red Shield Sensor Series • Makes home surveillance simple and easy with BOLTEK mobile app • With our unique smartphone app, you can remotely monitor and control your camera from anywhere in the world •...
- Page 18 *Support Micro SD Card up to 32GB (not included) © 2016 Red Shield Security Limited. All rights reserved. Red Shield logo is the trademark owned by Red Shield Security Limited. iPhone, iPad and iPod touch are registered trademarks of Apple Inc. iPad mini is a trademark of Apple Inc. App Store is a service mark of Apple Inc.
