- Page 1 ~ 1965 VOX Berkeley Super Reverb ~ - Owners Manual -...
- Page 2 Contents: Warnings – Do’s and Don’ts ……………………………………….Pages 1, 2 Part Numbers and other Information ……………………………. Page 2 Mirror Image of Bottom View of Amp Chassis and Tubes ……. Page 3 Factory Chassis Layout …………………………………………... Page 4 Factory Schematic Diagram ……………………………………… Page 5 Factory Parts List …………………………………………………..
-
Page 3: Warning Read Carefully
Warnings – Dos and Don’ts – Always use, and fully tighten, the head clamp to the trolley so the head doesn’t slide off. – Always plug in the speaker cable at each end before plugging in AC power cord. – Never turn on any tube Amp unless the speaker cable is hooked up; If you don’t, you’ll blow the output section of the AMP. - Page 4 Warnings – Dos and Don’ts Cont. To remove the preamp shields, push up and turn clockwise. If you ever have a problem with any tube Amp, unplug it, let the tubes cool down, and reseat all the tubes. This is done by pushing up on the tube while rotating the bottom end. I had to do this with a new Fender Amp once.
- Page 5 ~ Mirror Image of Bottom View of Amp Chassis ~ 12AU7 12 AX7 12 AX7 EL-84 EL-84 EZ81 12AX7 The tubes in this amp are listed in the table below. Note that America and Britten have their own tube designations i.e. the Brits call a 12AX7 an ECC83… Tube used for: American British...
- Page 6 Note – Only use this view when the cassis is removed and turned over. Use the view on page 3 when working on the amp with the chassis installed.
- Page 7 INPUT INPUT INPUT BERKELEY SUPER REVERB...
