U S E R M A N U A L
4x4 HDMI Matrix
Model No: HDMX0404

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDMX0404 and is the answer not in the manual?

Questions and answers

Related Manuals for Ask HDMX0404

Summary of Contents for Ask HDMX0404

  • Page 1 U S E R M A N U A L 4x4 HDMI Matrix Model No: HDMX0404...

  • Page 2: Dear Customer

    INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost- efficient.
  • Page 3 1、5V Power Adaptor 2、Remote 3、one pc of Manual Power Adaptor Remote Physical Connection Showing Picture： Figure 1.0 Front Panel Showing Picture Input 1- Input 4: HDMI input led status light IR: IR receiver LCD: Digital Tube Showing Switch A: HDMI A output switch button Switch B: HDMI B output switch button...
  • Page 4 Switch C: HDMI C output switch button Switch D: HDMI D output switch button Figure 1.1 rear panel showing picture DC 5V: 5V DC-DC Power Interface Switch：Power Adaptor led status light Output D：HDMI D output interface Output C：HDMI C output interface Output B：HDMI B output interface Output A：HDMI A output interface R232: RS232 communication port...

  • Page 5: Specifications

    SPECIFICATIONS: HDMX0404 HDMI resolution ………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i Support video color format …………………………..…………….24bit/deep color 30bit,36bit Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Max bandwidth…………………………………………………………………………….225MHz Max baud rate…………………….………………….…………………………………..6.75Gbps Input/Output TMDS signal ………….…………………………..………...0.5~1.5Volts p-p(TTL) Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL) Input cable distance..…... ………………………. ….…..≤15m AWG26 HDMI standard cable Output cable distance……………………………….…...≤25m AWG26 HDMI standard cable...
  • Page 6 The Hexadecimal Serial Communication Protocol： To control the input/output by sending the XXXX@X! ASCII Code( before the mark “ @”the XXXX means the output port, while the X after “ @” means input port,the mark “!” means the finish. One X means one hexadecimal number, there are 1,2,3,4 X before @, and there is only one hexadecimal number after @.
  • Page 7 Bits per second ......................9600 Data bits ........................8 Stop bits ..........................1 CRC bits………………………………………………………………………………………None Flow Control ......................None The Control Software Manual For the Matrix： 1．To open the control software and choose the serial port that connected with the Matrix and then click the Open,it will show as picture below.(the figure 2 is matched code of figure 1) 2．The letter “OPEN”...
  • Page 8 Figure IR Remote Operating Instruction 1．Firstly remove the plastic film in the rear board of the remote board. 2．The A, B, C, D signifies the A, B, C, D output. 3．If you want to select the Signal source to output A, press the A key directly. Repeat pressing the A key can switch the signal to the output.
  • Page 9 4. Pls hold the power adaptor head and do not pull the power cord when cut off from the socket. Pls turn the power off when the machine is not used for long time. 6. Pls do not open the cover and do not touch the inside parts. Pls use the original factory power adaptor.
