2. Description The W4 is a dual-relay access control with EM & HID 125 KHz card reader. It is suitable for mounting either indoor or outdoor in harsh environments. It is housed in a strong, sturdy and vandal proof zinc alloy electroplated structure. The electronics are fully potted so the W4 is waterproof and conforms to IP65.
> With manager cards for adding or deleting card user easily > Very low power consumption (25mA) > Backlight keypad > Light and sound of keypad can be set > Support door bell connection (Zone 2) > Built in light dependent resistor (LDR) for anti tamper >...
Page 4
Anti-demolition alarm PCB connect diagram 6. Wiring Description Color Function Orange Relay1 NC NC 1 Purple Relay1 COM COM1 Relay1 NO Blue NO 1 Relay2 NC Green & Black NC 2 Relay2 COM White & Black COM2 Relay2 NO Pink NO 2 12-24V DC / 12-18V AC AC&DC...
Page 5
COM 2(White & Black) Black NO 2(Pink) Door Bell installation & usage: Connect door bell with wires:NO2 COM2. ', Press the W4 reader will send out a signal to the door bell. Special Power Supply Orange NC 1 Purple COM1...
Page 6
Remarks: Reset to factory default, the user's information is still retained. 9. Anti Tamper Alarm The W4 uses a LDR (light dependent resistor) as an anti tamper alarm. If the keypad is removed from the cover then the tamper alarm will operate.
10. Sound and Light Indication Operation status Red Light Green Light Blue Light Buzzer Bright Short Ring Zone 1, unlock Zone 2, unlock Bright Short Ring Long Ring Bright Power on Shines Stand by Slowly Press keypad Short Ring Long Ring Operation successful Bright 3 Short Rings...
Page 8
Card or PIN Mode - Factory default setting ( 3 1 2 # for Zone 1 or 3 2 2 # for Zone 2) To add a PIN user 1 1 User ID number # PIN # Zone 1(User ID: 1-2000) The PIN is any 4-8 digits 1 2 User ID number # PIN # between 0000-99999999 with...
Page 9
To delete a card user by user ID This option can be used when a 2 0 User ID number # user has lost their card 2 0 Card number # To delete a card user by Card Users can be deleted continuously number without exiting from programming mode Card and PIN mode ( 3 1 1 # for Zone 1 or 3 2 1 # for Zone 2)
Page 10
Manager delete card Read user card To delete Card User by Manager Manager delete card Cards can be Delete Card deleted continuously To unlock the door Enter the PIN then press # For a PIN user For a card User Read card For a card and PIN user Read card then enter PIN #...
Page 11
Door open detection setting To disable door open detection 6 0 # (Factory default) To enable door open detection 6 1 # Keypad Lockout & Alarm Output Options. If read 10 invalid cards or input 10 incorrect PIN in a 10 minute period either the keypad will lockout for 10 minutes or the alarm will operate for 0-3 minutes, depending on the option selected below.
Page 12
To set the alarm output time 5 0-3 # (Factory default : 1 minute) (0-3 minutes) Remove the alarm To reset the Door Forced Open Read valid card or Master Code # warning To reset the Door Open Too Long Close the door or Read valid card or warning Master Code #...
Page 13
15. Interconnecting Two Devices 15.1 W4 operating as a Wiegand Output Reader In this mode the W4 supports a Wiegand 26-37 bit output so the Wiegand data lines can be connected to any controller which supports a Wiegand 26-37 bit input.
Page 14
In this mode the W4 supports a Wiegand 26-37 bit input so an external Wiegand device with a 26-37 bit output can be connected to the Wiegand input terminals on the W4. Either an ID card reader (125 KHz) or an IC card reader (13.56MHz) can be connected to the W4. See figure 2.
Page 15
W4 Quick Reference Programming Guide * Master code # To enter the programming mode 888888 is the default factory master code To exit from the programming mode Note that to undertake the following programming the master user must be logged in...
