Summary of Contents for ND Audio Visual ND-FM-12
- Page 1 ND Audio Visual WWW.NDAV.IO USER MANUAL ND-FM-12/16/32 Flexible Matrix Switchers ND Audio Visual WWW.NDAV.IO Page 1 of 17...
-
Page 2: Table Of Contents
ND Audio Visual WWW.NDAV.IO Contents Contents ............................2 Introduction ...........................3 Application Diagram .......................3 Operation ..........................4 3.1 Video Switching Menu ....................5 3.2 Configuration Menu - Input Port ...................5 3.3 Configuration Menu - Output Port ..................6 3.4 Scene Saving Menu ......................6 3.5 Scene Recall Menu ......................6 3.6 EDID Copy Menu .......................7... -
Page 3: Introduction
ND Audio Visual WWW.NDAV.IO 1. Introduction ND-FM-12 is a high-performance SEAMLESS AV modular matrix switcher with 12 flexible PCI-E slots for single HDMI, VGA, CVBS, YPBPR, DVI /SDI or HDBaseT input and output cards. Its advanced modularization design allows the Flexible Matrix inputs and outputs can be freely configured such 11x1, 6x6 or 1x11 and can be comprised of HDMI, VGA, DVI, SDI and HDBaseT. -
Page 4: Operation
ND Audio Visual WWW.NDAV.IO 3. Operation The Matrix supports a variety of control methods such as front panel touch screen control, RS232, TCP/IP control protocol, WEB page control, PC-side software, third-party control. The system uses a common user interface design across the touch screen, WEB and PC software making it easy to learn. -
Page 5: Video Switching Menu
ND Audio Visual WWW.NDAV.IO The function menu is divided into three sections Video Switching, EDID Distribution, and System Settings. 3.1 Video Switching Menu Features Video Switching, Scene Saving and Recall, plus Input and Output board settings. Click on the corresponding Input buttone and Output button to switch video, click on the Input button with All button to switch to all the output operation. -
Page 6: Configuration Menu - Output Port
ND Audio Visual WWW.NDAV.IO 3.3 Configuration Menu - Output Port Click on circular button to left of output button. A pop up configuration menu will appear. Different output boards will have different properties. Output Board Properties Port name: Enter a meaningful name and click rename button, it will be displayed on the output button. -
Page 7: Edid Copy Menu
ND Audio Visual WWW.NDAV.IO 3.6 EDID Copy Menu The EDID assignment menu is used to copy EDIDs from outputs connected to displays to inputs. When the HDMI / DVI / HDBaseT digital board is connected to a display device, the... -
Page 8: Control Command
ND Audio Visual WWW.NDAV.IO change the data, such as on-site preservation, callback, the system EDID unchanged, click on the application must be re-power to start the machine before the normal work. System Software: Displays the software version number of the current system. - Page 9 ND Audio Visual WWW.NDAV.IO Output resolution setting *Resolution:OUT1,720x480@60. Output resolution query #Resolution:OUT1. Port type query #Port:IN1. Output lock *Lock:OUT1. Output Analog format selection *VGA:OUT1,YPBPR. (VGA/YPBPR/CVBS) EDID Copy Command 3 to 1 *E3to1. 1 to many *E1to2,3,5. 1 to many *E1All.
-
Page 10: Pc Control Software
ND Audio Visual WWW.NDAV.IO 3.9 PC Control Software Connected matrix to the PC via a serial port or local area network. Install the matrix control software and run it. Select the Ethernet Device, enter the port number of matrix. The default is 1001, click on the Refresh button, the matrix on the LAN will be displayed in the device list, click the connection button. - Page 11 ND Audio Visual WWW.NDAV.IO EDID Configure Menu System settings menu includes updating the matrix by LAN, click load button select the software bin file, click the upgrade button, the matrix will then start the update process. Page 11 of 17...
-
Page 12: Signal Board Introduction
ND Audio Visual WWW.NDAV.IO 4.Signal board introduction 4.1 VGA signal Seamless input / output card • Scaler up output resolution to 1080p or 1920 x 1200. • Support manually change the type of signal: VGA , YPbPr , CVBS. • Each output resolution of the output signal could setup provided by the... -
Page 13: Dvi Signal Seamless Input / Output Card
ND Audio Visual WWW.NDAV.IO SDI signal seamless input / output card • Input card: one SDI input with the loop output. • Output card: two SDI output. • Signal format supports SDI, HD-SDI, 3G- SDI. • Input resolution automatic recognition. - Page 14 ND Audio Visual WWW.NDAV.IO 4.4 HDMI signal Seamless input / output card • Compatible HDMI1.3 and HDCP1.4 standards.. • Input and output ports support DVI, HDMI format. • Input resolution scaler up to 1080P output. • Output signal format set by WEB menu.
-
Page 15: Hdbaset Signal Seamless Input / Output Card
ND Audio Visual WWW.NDAV.IO 4.5 HDBaseT signal Seamless input / output card • Compatible HDMI1.3 and HDCP1.4 standards.. • Input and output ports support DVI, HDMI format. • Input resolution scaler up to 1080P output. • Output signal format set by WEB menu. - Page 16 ND Audio Visual WWW.NDAV.IO Video port for the RJ45, the use Class A or B-type straight-through twisted pair connection, suggest to use Class B straight line, the following is A / B type of direct line reference standard: TIA / EIA 568A...
-
Page 17: Common Faults
ND Audio Visual WWW.NDAV.IO 5.Common faults Cause Fault phenomenon Method of exclusion Analysis The signal lines are not Check the signal line at both ends of the interface to ensure connected at both ends that the connection is correct Color loss or no video signal...
