- Page 1 STEP-MXO2 Hardware Manual STEP FPGA STEP 2017/2/14...
- Page 2 STEP-MXO2 Hardware Manual STEP-MXO2 Hardware Manual CONCENTS 1．Introduction ................................3 2．Package Contents ..............................3 3. Layout and Components ............................4 3.1 Development Board Layout ........................4 3.2 FPGA Device ..............................5 3.3 Programming and Configuration ......................5 3.4 Connecters ..............................5 3.5 Display ................................
- Page 3 The STEP MXO2 FPGA development board includes hardware such as on-board JTAG Programmer, 7-Segment Displays, LEDs, GPIOs and much more. By leveraging all of these capabilities, the STEP MXO2 FPGA development board is the perfect solution for learning FPGA, evaluating and prototyping the true potential of the MXO2 FPGA.
- Page 4 STEP-MXO2 Hardware Manual 3. Layout and Components 3.1 Development Board Layout This section presents the features and design characteristics of the board. A photograph of the board is shown in Figure 2 and Figure 3. It depicts the layout of the board and indicates the location of the connectors and key components.
- Page 5 STEP-MXO2 Hardware Manual 3.2 FPGA Device Version MachXO2 4000HC Series MachXO2 Density LUTs 4320 EBR SRAM(Kbits) Dist. SRAM(Kbits) User Flash Memory(Kbits) DDR/DDR2/LPDDR Memory Support 3.3 Programming and Configuration · On-Board JTAG Programmer(Normal Micro-USB connector) 3.4 Connecters · 36 GPIO Header 3.5 Display...
- Page 6 STEP-MXO2 Hardware Manual 4．Block Diagram of Board Figure 4 gives the block diagram of the board. To provide maximum flexibility for the user, all connections are made through the MachXO2 4000HC FPGA device. Thus, the user can configure the FPGA to implement any system design.
- Page 7 STEP-MXO2 Hardware Manual 5．Pins Assignments STEP FPGA STEP FPGA Digital FPGA FPGA PINs PINs PINs PINs PINs Display1 PINs CLOCK 3.3V VBUS SEG-A1 PCLK GPIO29 SEG-B1 FPGA PINs GPIO28 SEG-C1 LED1 GPIO0 GPIO27 SEG-D1 LED2 GPIO1 GPIO26 SEG-E1 LED3 GPIO2...
