SIGMA TANDEM SYSTEM OWNER'S MANUAL
The advantages of this system are obvious. The spherical shape of the ripcord handles, and their
method of attachment, makes snagging highly unlikely. If dislodged, they automatically return to
position, so no more searching for "floating" ripcords. And the unique "Safety Pin," connected to
the drogue bridle, makes it virtually impossible for a snagged ripcord handle to cause an accidental
container opening. And let's not forget, you no longer have to waste time and effort stowing the
handles after opening, or searching for them at packing time.
Because this system is new (The first production rigs went into service Summer 2000), we don't yet know how long the
recoil ripcord system will last under actual field conditions. Although bench tests show that the ripcord system can
last for over 1,000 jumps, you should inspect the whole system often for signs of wear.
Look for wear at the junction of the Spectra ripcords and the handles, and around the pin area. The Spectra is 1,000
lbs. strong, and the force required to pull the pin is less than 10 lbs. That's over a 100 to 1 safety margin, so a small
amount of fraying should not be cause for alarm. Besides, the ripcord system is designed to be redundant. If one side
were to break or jam for any reason, the other side is still fully functional.
Also notice if the recoil system is doing its job properly. With the rig packed, each ripcord should snap back into place
when pulled a few inches and released. But please realize, if you pull and release each ripcord handle several times
before each jump, you will shorten the life of the system by a factor of three. Inspect, but don't play with the system
incessantly if you want maximum life from your ripcords.

UNDERSTANDING THE SIGMA SKYHOOK RSL COLLINS' LANYARD

The Collins' lanyard was designed to prevent a main-reserve entanglement, by releasing the left (non-RSL side) main
riser, in the event that the right (RSL side) main riser breaks or prematurely releases by itself, for any reason. On the
Sigma, it is integrated into the RSL with no external lanyard. This is accomplished by threading the left riser 3-ring
release cable through a loop in the reserve static line (RSL). As the right riser leaves, the RSL automatically pulls the
left cutaway cable as it pulls the reserve pin, yielding an almost simultanious breakaway and clean reserve deployment.
A standard RSL does one thing. It pulls the reserve ripcord pin automatically after a breakaway. The Skyhook RSL does
this, and then goes two steps further.
A. It automatically releases the Left (non-RSL) riser, if the right (RSL) riser releases prematurely for any reason (Collins.
Lanyard). (You wouldn.t want your reserve container opened with one riser still attached, would you?)
B. It then uses your departing main canopy as a super .pilot chute. to get your reserve to line stretch faster
than ever before. Breakaway, to canopy-out-of-bag times are between ½ and ¾ of a second, depending on the
size of your reserve canopy. This is up to three times faster than a pilot chute can do it alone.
If you have a main total malfunction, or your AAD fires, the Skyhook Lanyard automatically releases, and
therefore does nothing to hinder normal reserve deployment.
Page 12:X Section 2: Equipment • Chapter 1 - Description 11301 - 00.00.0000
