Summary of Contents for Intellian ShelfADD
-
Page 1: Installation Guide
Extend Your Signage Network with Intellian ShelfADD 7inch Wi-Fi Touch Player Installation Guide Intellian Technologies, Inc. ©Intellian Technologies, Inc., 2009 Proprietary & Confidential to Intellian... -
Page 2: Network Setting
Table of Contents Power on and Open OSD(On Screen Display) Menu Network Setting Environment Setting Firmware Upgrade Intellian Proprietary and Confidential... - Page 3 • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Intellian Proprietary and Confidential...
- Page 4 Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Intellian Proprietary and Confidential...
- Page 5 This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Intellian Proprietary and Confidential...
- Page 6 Rear Side 7inch Monitor Remote Controller Menu Button 1. Connect the DC power to DC Power Jack and power on the player. 2. After the player is booted, click the menu button of the remote controller. Intellian Proprietary and Confidential...
- Page 7 Network Setting ② 1. Open OSD menu. 2. Click the Network icon. Intellian Proprietary and Confidential...
- Page 8 Network Setting ③ 3. When Network menu appears, click the Change button. Intellian Proprietary and Confidential...
- Page 9 Network Setting ④ ⑤ 4. When Wireless window appears, select Use to activate wireless mode. 5. Click Next button. Intellian Proprietary and Confidential...
- Page 10 ⑥ 6. When Setup ESSID window appears, click the OK button of the remote controller. 7. Screen keyboard appears. 8. Enter the ESSID of your wireless network. 9. After you enter the ESSID, click Next button. Intellian Proprietary and Confidential...
- Page 11 Network Setting ⑩ ⑪ 10. When Security Mode window appears, select security mode of your wireless network. 11. Click Next button. Intellian Proprietary and Confidential...
- Page 12 Network Setting ⑫ ⑬ 12. When Encryption Mode window appears, select encryption mode of your wireless network. 13. Click Next button. Intellian Proprietary and Confidential...
- Page 13 ⑮ 14. When Setup KEY window appears, enter network key of your wireless network. Click the OK button of the remote controller to open the screen keyboard. 15. After you enter the KEY, click Next button. Intellian Proprietary and Confidential...
- Page 14 Network Setting 16. When IP Address window appears, select IP address allocation method. 17. Click Next button. Intellian Proprietary and Confidential...
- Page 15 Network Setting 18. When DNS allocation window appears, select DNS allocation method. 19. Click Next button. Intellian Proprietary and Confidential...
- Page 16 Network Setting 20. Click Apply button to apply new network setup. Intellian Proprietary and Confidential...
- Page 17 Environment Setting ② 1. Open OSD menu. 2. Click the Environment icon. Intellian Proprietary and Confidential...
- Page 18 4. Click OK button of the remote controller to open the screen keyboard. 5. Click Up and Down button of the remote controller to change the item. 6. After you enter all values, click OK button. Intellian Proprietary and Confidential...
- Page 19 1. Before the firmware upgrade, copy the firmware image file at the root directory of your SD memory. 2. Power on the player. After the player is booted, open OSD menu. 3. Click the Advanced icon. Intellian Proprietary and Confidential...
- Page 20 Firmware Upgrade ④ 4. Click the file select button to open the firmware image file. Intellian Proprietary and Confidential...
- Page 21 Firmware Upgrade ⑤ ⑥ 5. When file select window appears, select upgrade file. 6. Click OK button. Intellian Proprietary and Confidential...
- Page 22 7. Confirm your upgrade version and Click Yes to proceed the upgrade. Do not power off the player during upgrading. If the player is shout down during upgrading, it can not work normally. When the upgrade is finished, it reboots automatically. Intellian Proprietary and Confidential...
