- Page 1 GM-200F User Manual Infrared Forehead Thermometer...
- Page 2 Thank you for purchasing the Non-Contact Infrared Forehead Thermometer (GM-200F). The Forehead thermometer is a high quality product incorporating the latest technology and tested in accordance with international standards. It measures infrared energy radiated from the skin above the eyebrow area and the surrounding tissue.
- Page 3 Even in the absence of fever, those who exhibit a normal temperature may still need to receive medical attention. People who are on antibiotics, analgesics, or antipyretics should not be assessed solely on temperature readings to determine the severity of their illness. Temperature elevation may signal a serious illness, especially in adults who are old, frail, and have a weakened immune system, as well as neonates and infants.
- Page 4 Product Structure...
- Page 5 How to use your forehead thermometer? First time use: Remove battery insulation strip. 1. Turn thermometer on Press and release the measure/power button once. 2. Position thermometer above forehead Clean the forehead from hair, sweat, and dirt. Aim scanner at the center of the forehead, just above the middle of the eyebrow.
- Page 6 2. If 37.6ºC ≤ T ≤ 42.2ºC, the thermometer gives three quick short beeps, the white background light is on for 3 seconds, and the screen flashes. Object mode: If 0.0ºC ≤ T < 100.0ºC, the thermometer gives a long beep, and the white background light is on for 3 seconds.
- Page 7 Remove batteries if the thermometer will not be used for more than two months. Temperature taking tips It is important to know each individual’s normal temperature when they are well. This is the only way to accurately diagnose a fever. Record readings twice a day (early morning and late afternoon).
- Page 8 cool cloth may impact your reading. It is advised to wait 10 minutes before taking a reading. In the following situations it is recommended that 3-5 temperatures in the same location be taken and the highest one taken as the reading: •...
- Page 9 Symptom Possible Cause Description & Solution Polarities of the batteries Ensure the batteries are in the are reversed. right position "Er4" is Memory Error Contact manufacturer. displayed. The lens of the probe is Clean the lens with a cotton dirty. swab.
- Page 10 Symptom Possible Cause Description & Solution The battery level is low, Replace batteries but the thermometer can still be used. The power voltage is Replace batteries lower than 2.5 V± 0.1V. Specifications Product Name Non-Contact Infrared Forehead Thermometer Internal power supply Power Supply Mode Operating Voltage DC 3V...
- Page 11 Product Name Non-Contact Infrared Forehead Thermometer The low-battery symbol is displayed if the power Low-battery Alert voltage is lower than 2.5 V±0.1V. The thermometer automatically powers off if it is Automatic Power-off not used within 30±1 seconds. Outer dimensions (mm) 160×56×46 Weight (g) 97.4 g (with batteries)
- Page 12 A personal injury or thermometer damage may occur if the Warning thermometer is not correctly used. Inaccurate reading or thermometer damage may occur if Attention the thermometer is not correctly used. Distributed by Generation Guard Pty Ltd Eltham North Victoria, AUSTRALIA 3095 Made in China info@generationguard.com...
