Summary of Contents for Walkera Vitus Starlight
- Page 1 Starlight QUICK START GUIDE V1.0 Sep., 12th, 2017 www.walkera.com...
-
Page 2: Table Of Contents
2.0 Get to know your remote controller 3.0 Specifications 4.0 Attention before flight 5.0 Charging 6.0 Downloading/Installing Game App Walkera GO & Operation App Walkera Drone 7.0 Walkera Drone Operating Main Interface Instructions 8.0 Walkera GO Main Interface Instruction 9.0 Prepare for Aircraft 10.0 Prepare for Remote Controller... -
Page 3: Get To Know Your Aircraft
12. Stand cushion(A) 19. Status indicator * To avoid property loss and personal injury caused by wrong operation, please read the manual carefully, upgrade the firmware and calibrate the related items by watching the tutorial video at www.walkera.com before using VITUS Starlight. -
Page 4: Get To Know Your Remote Controller
DEVO F8S is in-built with a ground receiving terminal of 5.8G WiFi digital video transmission system, which can achieve a real-time display of high-definition images on a mobile device by using Walkera Drone APP, with a foldable holder capable of holding mobile devices. -
Page 5: Specifications
Quick Start Guide Starlight 3.0 Specifications Aircraft 177mm Main Rotor Dia.: 229 x 279 x 113mm Dimensions (L x W x H): 920g(batteries included) Weight: DEVO F8S Remote Controller: VITUS 320 Main board: WK-WS-28-017A Brushless Motor: VITUS 320 Brushless ESC: 11.4V 5200mAh LiPo 3S Battery: 22minutes for positioning flight (with10% battery level residual) / 25minutes for ultimate flight... -
Page 6: Attention Before Flight
Avoid using it where there is WIFI interference. 2) The VITUS Starlight is intended for pilots, 14 years or older, with RC hobby experience. 3) Please do not fly in severe weather conditions, such as rainy, snowy, windy or foggy conditions. -
Page 7: Walkera Drone Operating Main Interface Instructions
Quick Start Guide Starlight 7.0 Walkera Drone Operating Main Interface Instructions On the interface, HD video and photographs can be previewed in realtime and you can set the dynamic parameters, such as aircraft, remote controller, gimbal and battery. Connected AUTO Mode... -
Page 8: Walkera Go Main Interface Instruction
8.0 Walkera GO Main Interface Instruction The Walkera GO can be activated when the aircraft is in Auto Mode with a strong GPS signal. 1. FPV simulation mode: Just connecting remote controller with your cellphone, you can enjoy a flight experience simulating a real scene. -
Page 9: Prepare For Remote Controller
Open the Mobile Wi-Fi device and wait for 30 seconds, when at the same time “Vitus-Ground-***” and “Vitus-Air-***” appears, click “Vitus-Ground-***” , input password “1234567890” to connect and exit settings after a successful connection. 11.2 APP Connection Connect the operation app. Walkera Drone Connected AUTO Mode Walkera Drone... -
Page 10: Gps Indicator Lights
2. Connecting ..3. Enter main interface Walkera GO & Walkera Drone cannot be simultaneously used on the same mobile device, you can use another APP only when an App is exited. 11.3 GPS Indicator Lights Left red LED light... -
Page 11: Flight Control
1) Make sure that the GPS signal is received (left red LED light slowly flashes). 2) Only when “Connected” displays on the upper bar of the main interface of the Walkera Drone APP, you can perform APP operation. 3) Please unlock motors before takeoff. (refer to Page 10 for the detailed method) - Page 12 Quick Start Guide Starlight Return to Home (Remote controller or APP operation) Auto Manual Sports Click this icon on the APP interface, Long press the aircraft will return automatically. the aircraft will return automatically. Horizontal distance between aircraft & Home point＞30m a.
- Page 13 Quick Start Guide Starlight Active Track Mode (APP operation) There are two modes：Lock Mode & Follow Mode Follow Lock ActiveTrack in the Auto Mode Click this icon. Click the icon Choose what you need Lock Mode: aircraft position unchanged, Follow Mode: aircraft position & heading heading locks the target to be followed.
- Page 14 Quick Start Guide Starlight Circle Flight (APP operation) Aircraft in the Click the icon on the APP map interface, Auto Mode the aircraft enters the Circle Flight mode. Attention: 1) The aircraft is at a quiescent state when it is in Circle Flight. The circling function can only work after toggling aileron stick left or right you set circle speed and direction by (-5m/s to +5m/s speed changeable, 0m/s at default).
-
Page 15: End Flight
Quick Start Guide Starlight Photo & Video ( remote controller or APP operation) Remote Controller Operation: APP Operation: Take photo by short pressing the 1) Select working mode: photo or video button of Remote Controller 2) Touch the Photo or video icon to take photo or video. -
Page 16: Additional Instruction
Quick Start Guide Starlight 14.0 Additional Instruction 14.1 Optical Flow Positioning System Utilizing camera to get aircraft location information, it achieves accurate positioning of aircraft. It is suitable for environments with altitude of less than 3 meters without GPS signal or with weak GPS signal. -
Page 17: Stick Mode Switch, Stick Calibration & Fixed Id
Rudder Aileron Rudder Aileron ※ Customization also supported in Walkera Drone APP. Stick Calibration: Long press “ ” for 3~5 sec, you will hear a beep. Enter stick calibration, repeatedly move sticks from minimum to maximum mechanical range for several times, and then back to the middle. -
Page 18: Compass Calibration
Quick Start Guide Starlight 14.4 Compass Calibration 14.4 Compass Calibration Calibrate compass when abnormal circle flight or skewing occurs during flight (motor locked, light red LED remains on). Please conduct calibration in an open outdoor area away from electromagnetic interference. The compass calibration steps are as follows: The compass calibration steps are as follows: Place right/left sticks at lowest location, toggle them... -
Page 19: Instruction Of Intelligent Flight Battery Safety
Never use it in rain or a wet condition. When internally contacting with water, battery may decompose, auto-ignite or explode. 2) Only batteries supplied by Walkera can be used. In case of replacement, please go to Walkera official website for the purchase information. Walkera will not be responsible for any flight failure or other accidents, which are resulted from use of other batteries which are not supplied by Walkera. - Page 20 Manufacturer: Guangzhou Walkera Technology Co.,Ltd. Add: No.48 Wantai Rd, Taishi Industrial Park, Dongchong Town, Nansha Dist, Guangzhou, China.511453 Hotline: +86 400-931-8878 User manual is subject to change without prior notice. Please go to Walkera official website to get the latest version.
