Page 1
à la configuration de vos appareils iOS et d’iTunes, rendez-vous sur: http://alerat.ec/pdm-guides Para consultar la guía del usuario en inglés, francés o spagnolo y las recomendaciones que incluye sobre la configuración de sus dispositivos iOS y de iTunes, visite: http://alerat.ec/pdm-guides Part No. / Pièce n° / Ref. 400103...
• • Heavy-duty,•metal•enclosure•designed•for•reliability•in•deployment• environments • • LED•indicators•show•the•charge•or•sync•status•of•your•attached• tablets • • Includes•stands•to•hold•your•16•tablets•while•being•charged•or• synced Key Items on the Charge and Sync Station 16 LED Charge and Sync Indicators USB Port AC Power In Power Switch 16 USB Charge and Sync Ports www.aleratec.com...
Using the Charge and Sync Station 16 Labeling Your Cables Apply the numbering labels to each end of your charge and sync cables for easier identification. Charge and sync cables not included. www.aleratec.com...
Page 5
Setting up the power connection to your Charge and Sync Station 16. Make sure the power switch is in the OFF position. 2. Plug in the power cord into the side of the unit and into a US power outlet. www.aleratec.com...
Page 6
Please note that this station only serves as a pathway for communication between your devices and the computer. Actual management and synchronization is handled by software or apps independent of this station. After syncing, eject each device properly from the computer before disconnecting or powering off. www.aleratec.com...
Page 7
Using the Charge and Sync Station 16 Connection -•Continued 4. Plug in devices. 5. Turn ON station. www.aleratec.com...
• • Puissance•de•2,4•A•par•port•pour•charger•rapidement•les•16•appareils • • Synchronisation•simultanée•de•16•tablettes•ou•autres•appareils•USB • • Boîtier•métallique•robuste•conçu•pour•une•fiabilité•à•toute•épreuve•dans• les•environnements•de•déploiement • • Voyants•montrant•l’état•de•charge•ou•de•synchronisation•des•tablettes• raccordées • • Supports•fournis•pour•maintenir•les•16•tablettes•pendant•leur•chargement•ou• synchronisation Principaux éléments du Charge and Sync Station 16 Voyants de chargement et synchronisation Connecteur USB Prise d’adaptateur d’alimentation Bouton marche/arrêt Fentes USB www.aleratec.com...
Page 11
Utilisation du Charge and Sync Station 16 Étiquetage de vos câbles Appliquez les étiquettes de numérotation à chaque extrémité de vos câbles de chargement et synchronisation afin de les identifier facilement. Chargement et synchronisation câbles pas inclus. www.aleratec.com...
Page 12
Utilisation du Charge and Sync Station 16 Raccordement Raccordement électrique de votre Charge and Sync Station 16. Mettez l’interrupteur en position OFF. Branchez le cordon d’alimentation sur le côté de l’appareil et à une prise de pouvoir des États-Unis. www.aleratec.com...
Page 13
La gestion et la synchronisation proprement dites sont réalisées par des logiciels ou applications indépendants de cette base Une fois la synchronisation terminée, éjectez chaque appareil correctement via l’ordinateur avant de le débrancher ou de l’éteindre. www.aleratec.com...
Page 14
Utilisation du Charge and Sync Station 16 Raccordement (suite) 4. Branchez les appareils. 5. Allumez la base en mettant l’interrupteur sur ON. www.aleratec.com...
• • Caja•metálica•robusta•diseñada•para•fiabilidad•en•los•entornos•de• despliegue • • Los•indicadores•LED•muestran•el•estado•de•carga•o•sincronización• de•las•tabletas•conectadas • • Incluye•soportes•para•sujetar•sus•16•tabletas•mientras•se•cargan•o• sincronizan Elementos clave del Charge and Sync Station 16 Indicadores LED de carga y sincronización Conector USB Puerto del adaptador de alimentación Botón de encendido 16 USB Charge/Sync Puertos www.aleratec.com...
Utilisation du Charge and Sync Station 16 Etiquetar los cables Utilice las etiquetas numeradas a cada extremo de los cables de carga y sincronización para una identificación más fácil. Carga y sincronización cables no incluidos. www.aleratec.com...
Page 19
Utilización del Charge and Sync Station 16 Conexión Configuración de la conexión eléctrica del Charge and Sync Station 16. Apague el interruptor de encendido. Conecte el cable de alimentación en el lado de la unidad y en una toma de poder de EE.UU. www.aleratec.com...
Page 20
La sincronización y la gestión real de los dispositivos se deben realizar mediante software o aplicaciones independientes de esta base. Después de la sincronización, expulse correctamente cada dispositivo del ordenador antes de desconectarlo o apagarlo. www.aleratec.com...
Page 21
Utilización del Charge and Sync Station 16 Conexión (continuación) 4. Conecte los dispositivos. 5. Encienda la base. www.aleratec.com...
