SUSTAINABLE. PRE-ASSEMBLED. MODULAR.
OUTDOOR KITCHEN RANGE FOR WEBER
ASSEMBLY INSTRUCTIONS
BYRON
FOR WEBER SUMMIT BUILT IN BARBECUES
BYRON, ELSTON & NEPTUNE for Weber Summit E-460 and E-660 Built In Barbecues
The models illustrated in these instructions may vary slightly from the model purchased
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO CABINETS THAT ARE NOT
ASSEMBLED AS PER INSTRUCTIONS.
PARTS MAY CONTAIN SHARP EDGES & CORNERS, CARE MUST BE TAKEN WHEN HANDLING VARIUS PIECES TO AVOID
A MISHAP.
PARTS MAY BE HEAVY AND ASSISTANCE IS ALWAYS RECOMMENDED WHILE ASSEMBLING & MOVING CABINTRY
INTO POSITION, AS PER INSTRUCTIONS.
ALWAYS WEAR PERSONAL PROTECTIVE EQUIPMENT (PPE) WHEN ASSEMBLING THE CABINETS.
This product complies with Australian Standard No. AS/NZS 5601.1 for gas installation (barbecues in residential premises and
cylinders in an enclosure or recess). The warranty does not cover damage to products that is caused by hazardous gas, heat or
fire.
The installation of products must comply with Australian Standards which override any of the product manufacturers' installation
manuals.
IMPORTANT!
Refer to the product manufacturer's barbecue installation manual when determining a location for your barbecue.
Assembly Instructions – SustainaPod Outdoor Kitchen Range by VerdeLife
ELSTON
NEPTUNE
www.verdelife.com.au
Advertisement
Table of Contents
Summary of Contents for VerdeLife BYRON
- Page 1 NEPTUNE FOR WEBER SUMMIT BUILT IN BARBECUES BYRON, ELSTON & NEPTUNE for Weber Summit E-460 and E-660 Built In Barbecues The models illustrated in these instructions may vary slightly from the model purchased THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO CABINETS THAT ARE NOT ASSEMBLED AS PER INSTRUCTIONS.
- Page 2 The cabinet must be properly level for all door and drawer components to work properly. Follow each of the steps in these Assembly Instructions in the order they are written. Assembly Instructions – SustainaPod Outdoor Kitchen Range by VerdeLife www.verdelife.com.au...
- Page 3 SINK & TAP (to be installed) ELSTON/NEPTUNE - S/S LEGS BIN (drawer-mounted in POD) DEMON BOLTS 3-DRAWERS (mounted in POD) ASSEMBLY KEYS KICK BOARD PLATES WITH CLIPS BAG OF DOCUMENTS: ASSEMBLY, CARE, WARRANTY Assembly Instructions – SustainaPod Outdoor Kitchen Range by VerdeLife www.verdelife.com.au...
- Page 4 It will not cover the full height of the leg. Barbeque Installation Refer to your barbecue manufacturer’s installation guide Installation of Optional Sink/Tap Upgrade We recommend that sink and tap installation be done by a professional Assembly Instructions – SustainaPod Outdoor Kitchen Range by VerdeLife www.verdelife.com.au...
