- Page 1 OWNERS INSTALLATION & OPERATION MANUAL LENNOVATOR POOL/SPA CONTROL SYSTEM LEN GORDON CO Electronic/Pneumatic Controls & Components 7215 Bermuda Rd Las Vegas 89119-4304 Phone (702) 361-0600 Fax (702) 361-0613 www.gordon-aqualine.com...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical in pregnant women, and (6) unconsciousness equipment, basic safety precautions should resulting in a danger of drowning. always be followed, including: WARNING - The use of alcohol, drugs or READ AND FOLLOW ALL INSTRUCTIONS medication can greatly increase the risk of fatal hypothermia.
-
Page 3: Table Of Contents
Remote Operated Spa & Pool Control ......1 Transceiver ............7 SUMMARY OF TIME DEVICE FUNCTIONS ..7 FEATURES FILTRATION TIMER OPERATION ...... 7 Lennovator Combo Control Module Standard-Single Timer System ................2 INSTALLATION ............ 8 Hand-Held Radio Frequency Remote ......2 Panel Layout ............8 Grounding .............. - Page 4 This Page Left Blank Intentionally...
-
Page 5: Description
REMOTE OPERATED SPA & POOL CONTROL The Lennovator is a remote operated spa & pool control system. It assumes that an external gas heater or heat pump with temperature and hi-limit controls exists. The external heater and associated safety circuits are not part of the Lennovator System. -
Page 6: Lennovator Combo Control Module Standard-Single Timer System
Handheld Radio Frequency Remote provides control of pool or spa operating mode, spa water temperature and pool and/or spa light. Controls spa/pool up to 300 feet from Lennovator. -
Page 7: Lcd Display
REMOTE OPERATED CONTROL FUNCTIONS 1. RF REMOTE CONTROL UNIT (Figure 2) 5. LCD DISPLAY The LCD Display is custom designed. It has a 2 1/2 digit This unit is a hand held battery operated device which screen segment display and 9 Icons. contains a key pad, LCD display with a transceiver unit and associated electronics. -
Page 8: Down Switch
REMOTE OPERATED CONTROL FUNCTIONS DOWN SWITCH AUX-1 The down switch operates the same as the up switch with The “AUX-1" switch sends an AUX-1 command to the master the exception that it lowers the temperature set point. If control unit which toggles the AUX-1 function on or off. When the up and down switches are depressed together, a reset the AUX-1 function is on, the AUX-1 icon will be displayed. -
Page 9: Master Control Unit Features
MASTER CONTROL UNIT FEATURES The Master Control Unit is made up of four basic blocks: C. HEAT COMMAND 1. Processor When a “HEAT” command is received from the remote control unit, the processor will do the following: 2. Relays & Relay Control Logic 1. - Page 10 MASTER CONTROL UNIT FEATURES F. AUX-1 B. HI PUMP (JETS) RELAY K-2 The AUX-1 will be normally used to operate a blower “HI PUMP” relay will turn on any time it receives the “JETS” motor. This command will be handled the same as the command from the processor.
-
Page 11: Power Supply
ON times spaced around the timer. Wait a few days and adjust as necessary to maintain Lennovator single timer systems include a 24 hour filtration timeclock, which controls the pool/spa pump. sparkling clear water with a minimum of ON times. -
Page 12: Installation
If extended, the sensor lead should be less earth ground. than 30 feet, #22AWG. The temperature sensor plugs into J5, pins 1 and 2 on the master Lennovator card (See GROUNDING Figures 3 and 3A). Connect the grounding terminal in the Control Module to the grounding terminal on your electric service or supply panel. - Page 13 INSTALLATION...
-
Page 14: External Gas-Fired Heater Interconnect
EXTERNAL GAS - FIXED HEATER INTERCONNECT Examples of two typical installations of the Lennovator heat control wired to 2 and 3 wire external gas heaters are shown in Figure 6. Refer to interconnection Figures 5 (A), 5 (B) and 5 (C). -
Page 15: Wiring Diagrams
WIRING DIAGRAMS LENNOVATOR HEATER INTERCONNECT Examples of two installations are shown below. For specific details on connecting to the gas-fired heater, refer to the installation instructions provided by heater manufacturer. FIGURE 6... - Page 16 WIRING DIAGRAMS...
- Page 17 WIRING DIAGRAMS...
- Page 18 WIRING DIAGRAMS...
- Page 19 This Page Left Blank Intentionally...
-
Page 20: Initial Start Up
INITIAL START UP LCD WARNING DISPLAYS INITIAL START UP High Temperature Warning 1.Open all valves in the water inlet and/or water outlet to allow water to flow into the pump. Digital temperature displays will flash when water temperatures range between 109EF and 120EF 2.Fill the pool and spa with water following the manufacturers instructions. -
Page 21: Troubleshooting
Make certain all fuses are screwed in operate the equipment. tightly. LEN GORDON CO LAS VEGAS, NV FCC ID: This device complies with Part 15 of the FCC Rules. Operation of this... -
Page 22: Limited Warranty
7215 Bermuda Road Las Vegas, NV 89119 If the repair is required after the expiration date of the warranty period, Len Gordon Co will repair this product and bill for any necessary labor, replacement parts, shipping and handling. This warranty is void if the unit: 1) is not installed in accordance with the instructions; 2) is connected to improper voltage;... - Page 23 LEN GORDON CO Electronic/Pneumatic Controls & Components 7215 Bermuda Rd Las Vegas NV 89119 (702) 361-0600 • Fax (702) 361-0613 • Website: www.gordon-aqualine.com ©Len Gordon Co 2000...
