USER'S MANUAL
AUDIO CONTROL UNIT
(ACU)
Model 580230
For
The Rail Network
Atlanta
Aug 3, 2005
Applied Wireless Inc. ♦ 1250 Avenida Acaso, Unit F, Camarillo, CA 93012
TEL 805 383-9600 ♦ FAX 805 383-9001 ♦ www.appliedwireless.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 580230 and is the answer not in the manual?

Questions and answers

Summary of Contents for Applied Wireless 580230

  • Page 1 USER’S MANUAL AUDIO CONTROL UNIT (ACU) Model 580230 The Rail Network Atlanta Aug 3, 2005 Applied Wireless Inc. ♦ 1250 Avenida Acaso, Unit F, Camarillo, CA 93012 TEL 805 383-9600 ♦ FAX 805 383-9001 ♦ www.appliedwireless.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page General Description FCC Notice Front Panel Features/Connections (580320-PINOUTS) Antenna Connections Spares List Manufacturer Contact Information Appendix Frequency Allocation Chart Electrical Specifications Block Diagram Schematics 460320 Wiring Diagram 450323 MAIN Power Board 450327 48V Power Board 450326 DB9 Interface Board Outline Drawing Page 2 of 19...

  • Page 3: General Description

    The unit is powered by the 37.5-volt supply from the rail transit vehicle. The product is to be professionally installed and used in mass transit rail vehicles. FCC Notice FCC ID: QY4-580230 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
  • Page 4 Page 4 of 19...
  • Page 5 FRONT PANEL FEATURES (refer to drawing 580320-PINOUTS) Stereo/Mono Switch Set to appropriate setting Modulation LED’s LED’s should usually be in the green, with occasional flashes of RED. No LED’s lighted indicates no audio input. SW2(LSB)/SW1 (MSB) Set to appropriate channel. Reference the Frequency Allocation Chart. Power LED LED is lighted when power is applied.

  • Page 6: Antenna Connections

    ANTENNA INSTALLATION The antenna system and ACU, which are exclusively installed in mass transit rail cars, must be professionally installed in accordance with these instructions. The ACU is to be installed in the utility cabinet of the “B” rail car of a “married pair” rail car pair.
  • Page 7 7/07/2005 09:18:02a f=1.01 C:\Program Files\EAGLE-4.13\projects\TRAIN\550320-ANT.sch (Sheet: 1/1) Page 7 of 19...
  • Page 8 Page 8 of 19...

  • Page 9: Spares List

    Molex 09-50-8033 450326) 600092-PHO Contact Pins, Female, 18-20 AWG (used on Molex 08-52-0113 600091 Connector shells) MANUFACTURER CONTACT INFORMATION Applied Wireless Inc. 1250 Avenida Acaso, Unit F Camarillo, CA 93012 TEL 805 383-9600 FAX 805 383-9001 www.appliedwireless.com Page 9 of 19...

  • Page 10: Appendix

    APPENDIX Page 10 of 19...
  • Page 11 ACU Frequency Allocation Table Channel Freq.(Mhz) Channel Freq.(Mhz) 88.100 98.100 88.300 98.300 88.500 98.500 88.700 98.700 88.900 98.900 89.100 99.100 89.300 99.300 89.500 99.500 89.700 99.700 89.900 99.900 90.100 100.100 90.300 100.300 90.500 100.500 90.700 100.700 90.900 100.900 91.100 101.100 91.300 101.300 91.500...

  • Page 12: Electrical Specifications

    400mA Typical, 470mA max Power Dissipation 26W, with SU Load, 37.5 VDC Input Audio Input 0dB, 600ohm, Balanced. 4-wires/channel Applied Wireless Inc., 1250 Avenida Acaso, Unit F, Camarillo, CA 93012 Phone 805 383-9600 • Fax 805 383-9001 • www.appliedwireless.com Page 12 of 19...
  • Page 13 Per EN61000-4-4, 2KV on Power Lines Power Line Surges Per EN61000-4-5, Line to Gnd, Line to Line, +/- 0.5kV, +/-1.0kV, +/-2.0kV Applied Wireless Inc., 1250 Avenida Acaso, Unit F, Camarillo, CA 93012 Phone 805 383-9600 • Fax 805 383-9001 • www.appliedwireless.com Page 13 of 19...

  • Page 14: Block Diagram

    Combiner Transmitter 2- Way Amplifier Filter U8-11 Splitter Module 4 Transmitter Module 5 Antenna Applied Wireless Transmitter System 7 Channel 88-108 MHz FM Module 6 Rail Car B Stereo Transmitter Block Diagram Transmitter Ref. Schematics 400320B, 400322, 400323, 400327 Module 7...
  • Page 15 5/25/2005 07:59:51a f=1.01 C:\Program Files\EAGLE-4.13\projects\TRAIN\460320A.sch (Sheet: 1/1) Page 15 of 19...
  • Page 16 10/20/2004 11:46:26a C:\Program Files\EAGLE-4.13\projects\TRAIN\400323.sch (Sheet: 1/1) Page 16 of 19...
  • Page 17 1/10/2005 09:41:31a f=1.01 C:\Program Files\EAGLE-4.13\projects\TRAIN\400327.sch (Sheet: 1/1) Page 17 of 19...
  • Page 18 12/02/2004 11:02:32a f=1.01 C:\Program Files\EAGLE-4.13\projects\TRAIN\400326a.sch (Sheet: 1/1) Page 18 of 19...
  • Page 19 Page 19 of 19...
