Summary of Contents for Research C104
- Page 1 Cool Model C104 - Cooling System Instruction Manual February 26, 2015 Research, Inc. • USA • Ph: 952.949-9009 • Fax: 952.949-9559 • • tsdsales@researchinc.com www.researchinc.com...
-
Page 2: Table Of Contents
Table 2 - cooling performance………………………………………………………………………6 Table 3 - spare parts ………..……………………………………………………………………….8 Revision History Revision Description ECN Number Date Initial Release 11/01/2013 Add 230v 10/21/2014 Cooling spec 02/26/2015 Research, Inc. • USA • Ph: 952.9419-9009 • Fax: 952.949-9559 • • tsdsales@researchinc.com www.researchinc.com... -
Page 3: Section 1 - Introduction
Section 1 - Introduction The Model C104 is a self-contained heat exchanger designed to provide circulating coolant for small Research Inc. aluminum-reflector heaters. Figure 1 below shows the C104 connection side. Power to the motor is provided with a 10ft power cord and molded plug. -
Page 4: Section 2 - Installation And Operation
Always use an isolated oscilloscope for checking waveforms. Sizing The C104 can handle up to 5 KW of cooling load. The amount of cooling load is dependent upon the heater style, lamp wattage, and heating application. Table 1 shows how to size the C104. -
Page 5: Sizing The C104 To The Heater
Remove filler cap and fill reservoir with one of the following coolant types: Add mixture of distilled water (3 gallons) and propylene glycol (1 gallon, RV type, pink color) solution. Checked monthly and changed as needed. Research, Inc. • USA • Ph: 952.949-9009 • Fax: 952.949-9559• • tsdsales@researchinc.com... - Page 6 (60C). Table 2 shows the coolant temperature as a function of cooling KW. Operate the cooler only at the voltage and frequency stamped on the serial nameplate (120V, 230V, 50/60 Hz), Research, Inc. • USA • Ph: 952.9419-9009 • Fax: 952.949-9559 • • tsdsales@researchinc.com...
-
Page 7: Operation
Operation The C104 system needs to run when the heater is being run. After the heater is shut off, the user should continue to run the C104 system for 3 – 5 minutes to allowing the heater to cool. Section 3 - Specifications... -
Page 8: Section 4 - Maintenance And Parts
5kW heat exchanger, 120v motor C104-120-PK 5kW heat exchanger, 120v motor , heater protection kit C104-230 5kW heat exchanger, 230v motor C104-230-PK 5kW heat exchanger, 230v motor, heater protection Kit Research, Inc. • USA • Ph: 952.9419-9009 • Fax: 952.949-9559 • • tsdsales@researchinc.com www.researchinc.com... -
Page 9: Exploded View
Figure 2 - Exploded view Research, Inc. • USA • Ph: 952.949-9009 • Fax: 952.949-9559• • tsdsales@researchinc.com www.researchinc.com... -
Page 10: Part List
Coupler, drive pump Strainer – screen, not shown Cable, pwr, 115vac 16ga. , 3conductor, 10ft Bracket, motor mount Label, warning moving parts Blade, fan 10” Tubing, Research, Inc. • USA • Ph: 952.9419-9009 • Fax: 952.949-9559 • • tsdsales@researchinc.com www.researchinc.com...
