Summary of Contents for Tone King Gremlin
- Page 1 Tone King User’s Manual Tone King Amplifiers www.toneking.com mail@toneking.com...
- Page 2 (though that’s not the stock sound) At 8W, the Gremlin was still too loud to be used in a home environment, so we added a custom version of our Ironman II attenuator, with 6 levels of attenuation, to bring the volume down by as much as 35db, all the way to a genuine bedroom volume.
- Page 3 Safety Instructions Please keep this instruction manual for future reference and for the duration of owning this Tone King Amplifier. Please carefully read and understand the instructions inside this user’s manual before attempting to operate your new amp. This instruction manual includes essential safety information regarding the use and maintenance of the amplifier.
- Page 4 reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. 11. Power-Cord Protection – Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to the cord in correspondence of plugs, convenience receptacles, and the point where they exit from the amplifier.
-
Page 5: Table Of Contents
Contents 1. Top Panel Controls Rhythm and Lead Inputs Volume and Tone Controls 2. Dialing In Your Sound Rhythm Voicing Lead Voicing 3. Back Panel Controls AC Power Fuse Power Switch Speaker Jack Direct Out Jack Attenuation Controls Notes on Using the Attenuator 4. -
Page 6: Top Panel Controls
Tone controls, it may take some experimenting to become familiar with how best to use 2. Dialing In Your Sound The Gremlin is capable of a surprisingly wide range of tones, between the two inputs. Each channel is intended for a specific use, and it’s important to know the intention of each voicing in order to get the most out of the Gremlin. -
Page 7: Back Panel Controls
It is a standard ¼” mono jack. The output impedance of the amplifier is 8 Ohms. If you wish to use the Gremlin with an extension cabinet, it’s best to use an 8-ohm cabinet. You can connect it with a standard ¼” mono speaker cable by pulling out the plug from the internal speaker, and plugging the cable into the speaker jack. -
Page 8: Notes On Using The Attenuator
Notes on using the attenuator In the 0db position, the attenuator is completely bypassed, and the speaker is connected directly to the output transformer secondary, with no additional circuitry touching the signal path. Although the Ironman II attenuator does an excellent job of reducing output power without changing the tone of the amp’s circuitry, there are other variables in play at lower volume which do result in some apparent tone change. -
Page 9: Replacing Output Tubes
Replacing Output Tubes The output stage of the Gremlin is fully cathode biased, and no bias adjustment is necessary when changing output tubes. The design of the Gremlin’s output stage allows a fair amount of margin for variation in tube characteristics, so any known brand of KT66 can be installed, and will work properly and be appropriately self-biased. -
Page 10: Warranty
AMPLIFIERS: Tone King offers a limited lifetime warranty to the original purchaser that a Tone King amplifier will be free from defects in material and workmanship. A dated sales receipt will establish coverage under this warranty, PLEASE KEEP YOUR PROOF OF PURCHASE TO USE YOUR WARRANTY. - Page 11 Tone King product, even if a Tone King dealer has been advised of the possibility of such damages, or any other claim by any other party. Some states do not allow the exclusion or limitation of consequential damages, so the above limitation and exclusion may not apply to you.
