Vendor: S000180
ASSEMBLY INSTRUCTIONS
RICHMOND 4 DRAWER CHEST
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR RICHMOND 4 DRAWER CHEST
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEALTH & SAFETY:
DO NOT use this chest if any parts are missing, damaged or worn
DO NOT use this chest unless all fixings are secured
Always use on a level, even surface
CARE & MAINTENANCE:
Assemble on a soft, clean surface to prevent damages
Periodically check all screws & fixings to ensure they are secure
DO NOT push the chest as this will damage the feet
Always lift the chest with two people to reposition
Keep any sharp objects away from the chest
www.birlea.com
Page 1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Birlea RICHMOND
Summary of Contents for Birlea RICHMOND
- Page 1 ASSEMBLY INSTRUCTIONS RICHMOND 4 DRAWER CHEST IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR RICHMOND 4 DRAWER CHEST PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE HEALTH & SAFETY: DO NOT use this chest if any parts are missing, damaged or worn...
- Page 2 Vendor: S000180 Parts List Hardware List Part Description Part Description Left Panel 4.5 x 32 mm CSK Screw Right Panel 3.5 x 15 mm CSK Screw Top Panel 3.5 x 12 mm CSK Screw Lower Front Frame 6 x 9 mm Euro Screw Lower Back Frame 6 x 20 mm Wooden Dowel Middle Back Frame...
- Page 3 Vendor: S000180 Step 1: Insert hardware parts E and F as shown using hardware part N and a small mallet (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 2: Insert hardware part G as shown using a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Page 3 of 8...
- Page 4 Vendor: S000180 Step 3: Assemble the drawers as shown using hardware parts A, C, J, L1, L2, N and Q with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Page 4 of 8...
- Page 5 Vendor: S000180 Step 4: Attach hardware parts K1 and K2 to the left panel (1) and right panel (2) using hardware part D and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 5: Attach the lower back plinth (10) to the lower back frame (5) then attach the lower front plinth (8) to the lower front frame (4) using hardware parts H and N with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim...
- Page 6 Vendor: S000180 Step 7: Attach the right side panel (2) using hardware parts H and N with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 8: Insert the back panels (17) DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 9: Attach the top panel (3) using hardware parts A, J and N with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim...
- Page 7 Vendor: S000180 Step 10: Insert the assembled drawers to the frame DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 11: Secure the back panels (17) using hardware parts B and M with a screwdriver (not provided) If mounting the chest to a wall, attach hardware part P with a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim Page 7 of 8...
- Page 8 Step 12: Fix the assembled chest to a wall if required DO NOT use any power tools as this may damage the frame and will invalidate any claim For complete product information, images and dimension diagrams please visit www.birlea.com Page 8 of 8...
