Summary of Contents for Rowbike Crew 2.0
- Page 1 ROWBIKE ASSEMBLY INSTRUCTIONS Step 1 Foot rest assembly page 3 Step 2 Power bar position page 5 Step 3 Mount the handle bars page 6 Step 4 Installing the seat page 7 Step 5 Installing the seat stop page 8...
- Page 2 Your new Rowbike will arrive in a single carton Unpack the large carton you will find your new Rowbike along with two smaller boxes and one foot rest. Page | 2...
- Page 3 Foot rest assembly Assemble the foot rests starting from the right side of the Rowbike. The foot rests themselves fit into the frame. The elongated metal piece should be on the right side of the Rowbike as pictured below. Page | 3...
- Page 4 Once you have assembled the foot rest assembly as shown above, go ahead and tighten it up. Page | 4...
- Page 5 Step 2: Power bar position Pull the power bar from rear to front so it rests on the cushions that you just installed with the foot rest assembly. The chain will hang loosely. Page | 5...
- Page 6 Step 3: Mount the handle bars Simply slide the handle bar mounting ring over the silver nut as shown in the series of three photos below. Then tighten down the bolt with the allen wrench. Page | 6...
- Page 7 Step 4: Installing the seat Simply slide the seat on the rail from the rear of the Rowbike as shown below. Page | 7...
- Page 8 Step 5: Installing the seat stop Install the parts in the order pictured above. Page | 8...
- Page 9 Then slide the bolt through a seat stop hole as shown below. The second hole from the front of the Rowbike is a good place to start. Ultimately, you will want to use the hole that best suits you. The proper adjustment is so that at full extension, your legs are almost, but not quite fully extended.
- Page 10 Step 6: Installing the reflector Using the bolt, washers and nut supplied. Install the reflector using one washer against the bolt head and the other against the nut. Tighten using a wrench and an allen wrench. Page | 10...
- Page 11 Step 7: Putting on the chain Loop the chain around the Dave Cam as shown below: To do this you will need to pull a lot of chain slack out of the power bar and manipulate the slack through the derailleur and over the sprockets. Collect enough chain to loop it over the Dave Cam.
- Page 12 Step 8: Checking the cables Check that the cables don’t bind on the power bar. Pull the power bar back and look at where the black cables exit at the bottom of the power bar tube. If you find a cable binding, simply feed more cable through by lightly pulling on the cable as shown.
- Page 13 Remove the protective packaging from your new Rowbike Step 11: Tighten the handle bars With the Rowbike upright, check that the handle bars and the front wheel are both straight. Then make sure to tighten up the handle bars with the allen wrench (see step 3).
- Page 14 Congratulations, you are ready for; YOUR FIRST ROWL!! Now that you have your new Rowbike assembled you are ready for your first ride! The two most important things to remember are: ALWAYS have one foot in a foot rest, whether starting, stopping or just stopped.
