- Page 1 Hoyer User Hoyer Instruction Power Patient Lifters Manual & P-C-HLA-2 & HPL402 Warranty...
-
Page 3: Introduction
Joerns Healthcare Supplier. Please feel free to write or call us at the address and telephone number below: Joerns Healthcare Inc. 2100 Design Road Suite 100, Arlington... -
Page 4: Table Of Contents
If you have questions regarding the safe use and/or assembly, maintenance or specifi- cations of your patient lifter, you should call Joerns Healthcare at 800.826.0270 For service and repair, remember your authorized Hoyer dealer is able to provide the assistance you need. -
Page 5: Models
M o d e l s MODELS HPL402 P-C-HLA-2 IM-459000... -
Page 6: Assembly
A s s e m b l y ASSEMBLY The following tools are required for assembly: HPL402: 3/4" & 1/2" wrench, 3/16" hex wrench, 1/8" hex wrench, and a thin layer of grease should be applied to all bolts. P-C-HLA-2: two 9/16" wrenches, 1/8" hex wrench, and a thin layer of grease should be applied to all bolts. - Page 7 A s s e m b l y 5. a. HPL402 only– Attach the actuator to the mast and the motor end to the boom with hardware. (Fig. 5) b. P-C-HLA-2– Attach top of actuator to the boom and motor end to the mast. 6.
- Page 8 A s s e m b l y 9. HPL402 only - Raise boom to highest position; pull vinyl boot over bolted connection (Fig. 9,10). 10. Attach adjusting lever handle into base (Fig. 11). 11. Wheel locks are provided for parking. To lock casters, step on cam lever on side of casters.
-
Page 9: Operating Instructions
O p e r a t i n g I n s t r u c t i o n s OPERATING INSTRUCTIONS A. HAND CONTROL The hand control activates the lifter and has two but- tons; one “up” and one “down”. Simply press the button for the direction you want the lifter to move. - Page 10 O p e r a t i n g I n s t r u c t i o n s D. EMERGENCY STOP BUTTON (Fig. 11) The red emergency stop button disconnects battery power to the control box. Pushing the button activates the stop button.
-
Page 11: Maintenance And Care
M a i n t e n a n c e & C a r e MAINTENANCE & CARE Regular maintenance of lifters and accessories is necessary to assure proper and safe operation. Read and observe the following recommended instructions: Initially Before Bi-Monthly... -
Page 12: Troubleshooting
T r o u b l e s h o o t i n g TROUBLESHOOTING Symptom Possible Cause Action Power indicator does not Not connected to mains Connect to mains • • light up. The fuse has blown Replace fuse, if the sys- •... -
Page 13: Specifications
S p e c i f i c a t i o n s SPECIFICATIONS HPL402 P-C-HLA-2 Base Adj. U Adj. U Max. Weight Capacity 400 lbs. 400 lbs. Lift-range of Boom 29"-76" 29"-80" Width of Base 24"-41" 23"-39" Length of Base 43.5"... -
Page 14: Limited Warranty
1. We do not warrant damage due to: a. Neglect, misuse or improper installation or repair b. Use of parts or changes not authorized by Joerns Healthcare c. Exceeding the specified weight limit of the lifter 2. This warranty is void if the original lifter serial number tag/label is removed or altered. - Page 16 Distributed by: Joerns Healthcare Inc. 2100 Design Road Suite 100 • Arlington TX 76014 • USA Tel: 800-826-0270 • Fax: 800-457-8827 www.joerns.com Printed in Taiwan © 2011, Joerns Healthcare IM-459000 Rev B DCO. 11-0375...
