Page 1 JPD-FR302 User Manual Infrared Thermometer...
Page 2 User Instructions  For proper use of the product, please read this manual before using the product, and follow this manual when operating the product .  Before using the product, please read and follow Safety Precautions.
Page 3: Table Of Contents
Contents Safety Precautions .................. 1 Warning ....................3 Symbol Conventions ................4 Product Introduction ................5 Functions and Features ................6 Schematic Diagram of Appearance ............8 Measurement Method ................8 Display and Operation Instructions ............. 12 Battery Replacing Method ..............16 Cleaning and Disinfection ..............
Page 4 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: （1）this device may not cause harmful interference. （2）this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 5 user’s authority to operate the equipment.
Page 6: Safety Precautions
Safety Precautions Before using the thermometer, please carefully read the following precautions: Caution  This product cannot be used to replace a monitoring instrument that continuously monitors the body temperature.  The temperature probe is a sensitive component of the infrared thermometer, and keep it carefully.
Page 7  After using the product, clean it, and keep it in a dust-free, dry, and ventilated place. When using the product, note the safety precautions below:  The product is not waterproof, and do not put it into water or other liquid.
Page 8: Warning
Warning Warning  During measurement, do not forcibly insert the temperature probe into the auditory meatus, which may hurt the auditory meatus.  The thermometer is not a diagnostic instrument, and the measurement result is only used as reference for a doctor. ...
Page 9: Symbol Conventions
Do not use the thermometer to make measurement for any part of the body except the ear; the measurement result may be incorrect. Keep out of reach of children. Symbol Conventions Description Symbol BF-type application part Caution! Please see this manual. Indicates general prohibitions, where specific content is described following the symbol.
Page 10: Product Introduction
Product Introduction (1) Overview The JPD-FR302 infrared thermometer (referred to as thermometer in the following) is a measurement instrument that uses the infrared receiving principle to measure the temperature in the tympanic membrane of the earhole. You only need to insert the temperature...
Page 11: Functions And Features
(4) Expected Usage This product intends to be used by a medical department or a family to measure the body temperature. (5) Scope of Application The temperature of a measured object is displayed by measuring thermal radiation of the thermal radiation of the earhole. (6) Contraindications Do not use this instrument for an individual having diseases such as otitis media and ear fester.
Page 12  Conforming to ergonomic design  One-key measurement and automatic temperature measurement  No interference to daily life, where measurement may be made when a child is asleep 3. Fast Measurement  One-second measurement and no waiting 4. High Accuracy ...
Page 13: Schematic Diagram Of Appearance
Schematic Diagram of Appearance Measurement Method 1. Precautions before Use 1) This thermometer is applicable to indoor environments. There should be no strong cross-ventilation between the instrument and a measured object during measurement (for example, a fan, an air-conditioner, and a heater blow against each other). 2) This thermometer is sensitive to the environment temperature;...
Page 14 5) Do not have emotional outbursts or take acute exercise before measurement. 6) Make measurement 30 minutes later after taking the thermometer into the measurement environment, if there is a temperature difference between the storage environment and the measurement environment. 7) The measured individual is advised to take a more than 10 minutes rest before measurement, if the individual enters the measurement environment from an environment and there is a...
Page 15 to make the auditory meatus straight and the temperature probe aim at the tympanic membrane direction. 3) When measuring the temperature of the ear, press and release the measurement key. The buzzer beeps once, and the display screen displays the measurement value about 1s later. 3.
Page 16 1) After the measurement is completed, in the power-off state, long press the measurement key for more than 4s but less than 6s to enter the memory query mode, in which you can view previous measurement records. For detailed operations, see Query of 20 Groups of Memory Data in the following table.
Page 17: Display And Operation Instructions
Display and Operation Instructions Operation Method and Sound and Backlight Display Display Instructions In the power-off state, press the measurement key for less than 4s. Then, the One long buzzing sound and 3s green backlight thermometer displays the measurement value and starts 1.
Page 18 and it is automatically identified as the temperature of the object. When the measured Three short buzzing temperature is higher than sounds and 3s green 100C (212F) backlight When the measured Three short beeps and temperature is lower than 0C 3s green backlight (32F) Query of 20 Groups of Memory Data...
Page 19 there are 20 groups of memory data in total. If there is no measurement data, the LCD displays only "- No sound is emitted. - - " and the M symbol, and the M symbol blinks. C/F Conversion Operation Steps Sound and Backlight Display In the power-off state, press...
Page 20 When there is a read/write error in the EEPROM data or Three short buzzing correction is not completed, sounds and 3s green "ErC" is displayed. In this backlight case, contact the supplier. When the voltage of the battery is lower than 2.51V±0.15V, a low voltage symbol (not blinking) is No sound is emitted.
Page 21: Battery Replacing Method
Battery Replacing Method 1) When replacing the battery, press and hold the upward sign on the battery cover, take off the battery cover, put two AAA batteries into the battery holder according to electrode signs, and close the battery cover. 2) After the thermometer has been used for a period of time, if the display screen displays the low voltage symbol after the thermometer is powered on, replace the batteries with new ones...
Page 22: Cleaning And Disinfection
Cleaning and Disinfection Device Cleaning: Recommended detergent: * Medical detergent * Household neutral detergent Cleaning steps: 1) Take out the battery before cleaning. 2) If the instrument body is dirty, use a soft and clean cloth to soak neutral detergent or water, wring the cloth and then wipe the instrument body, and immediately use tissue or dry cloth to wipe the instrument body.
Page 23 You are advised to clean the thermometer weekly, finish cleaning within 3 minutes each time, and clean the thermometer not more than three times each time. Disinfection: Recommended sanitizer: * Isopropanol solution of 70% concentration * Medicinal alcohol of 75% concentration * Sodium hypochlorite solution of 3% concentration Disinfection steps: 1) Use a clean soft cloth to soak a small amount of disinfectant to...
Page 24: Maintenance
Maintenance 1) Each time finishing using the instrument, clean the instrument body and the temperature probe and perform operations following Cleaning and Disinfection. 2) Keep the thermometer in a dry, ventilated, dust-free, and pollution-free place, prevent the thermometer from direct solar radiation, and store and transport the thermometer according to corresponding environment requirements.
Page 25: Troubleshooting
Troubleshooting Fault Possible Cause Solution Symptom The battery level is Use new batteries of extremely low. the same type or specifications. The batteries are Check whether the installed according to batteries are installed wrong positive and in the battery holder negative electrodes.
Page 26 Fault Possible Cause Solution Symptom after the than 40C or lower than temperature of 10C instrument is 10C. to 40C. powered on "ErC" is There is a read/write Contact the displayed error in internal storage manufacturer for after the data or temperature processing.
Page 27 Fault Possible Cause Solution Symptom The temperature probe is Contact the damaged. manufacturer for measurement There is direct incidence repairing. result is of strong light. Do not make higher than a measurement under normal value strong light.
Page 28: Technical Specifications
Technical Specifications Product Name Infrared thermometer Model JPD-FR302 Battery Working Internal power supply Mode Working Voltage DC 3V Battery AAA×2 Specifications Battery Life Alkaline dry battery, about 20000 times Running Mode Short-time continuous running Input Power Less than 60mW Display Mode...
Page 29: Safety Class
Barometric pressure: 86kPa to 106kPa The maximum permissible error of the accuracy of clinical diagnosis test is specified by using the formula below: Accuracy of Clinical Diagnosis Test  0.3C/0.6F (for 95%) where, T1 and T2 are two temperature reading values of two times of measurement of the tested thermometer, and Tref is a fixed reference temperature.
Page 30: Appendix I：manufacturer's Declaration Of The Eut
– for all equipment and systems The Infrared Thermometer JPD-FR302 is intended for use in the electromagnetic environment specified below. The customer or the user of the Infrared Thermometer JPD-FR302 should assure that it is used in such an environment. Emissions...
Page 31 Guidance and manufacturer’s declaration – Electromagnetic immunity – for all equipment and systems The Infrared Thermometer JPD-FR302 is intended for use in the electromagnetic environment specified below. customer or the user of the Infrared Thermometer JPD-FR302 should assure that it is used in such an environment.
Page 32 dips, short (>95% dip in interruption UT) for 0.5 s and cycle voltage variations 40 % UT on power (60 % dip in supply input lines for 5 cycles 61000-4-11 70 % UT (30 % dip in for 25 cycles <5 % UT (>95 % dip in UT)
Page 33 The Infrared Thermometer JPD-FR302 is intended for use in the electromagnetic environment specified below. customer or the user of the Infrared Thermometer JPD-FR302 should assure that it is used in such an environment. 60601 Electromagnetic Immunity Compliance Test environment- test...
Page 34 where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer and d is the recommended separation distance in meters (m). Field strengths from fixed RF transmitters ， as determined by an electromagnetic site survey, a should...
Page 35 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the JPD-FR302 is used exceeds the applicable RF compliance level above，the JPD-FR302 should be observed to verify normal operation. If abnormal performance is observed，additional measures may...
Page 36 RF communications equipment (transmitters) and The Infrared Thermometer JPD-FR302 as recommended below ， according to the maximum output power of the communications equipment. Separation distance according to frequency of Rated transmitter maximum output 80 MHz to 800 MHz 800 MHz to 2.5 GHz...
