Summary of Contents for SynCrown SMP-M240
- Page 1 2inch Mobile thermal printer SMP-M240 User Manual SynCrown Inc. #704, E&C dream-tower 8th, 45 Gasan Digital 1st Rd. GeumCheon, Seoul 153-793 Korea TEL：+82-70-4814-0100 FAX：+82-2-6974-1533 www.syncrown.com...
-
Page 2: Table Of Contents
SMP-M240 Content Precautions · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3 1. -
Page 3: Precautions
SMP-M240 Precautions 1. Safety Precautions Be sure to use the specified battery and power source provided by our company. Connection to an improper power source may cause fire, explosion or damage to the printer. Don’t put the battery into the fire or water, don’t disassemble or modify the ... -
Page 4: Storage Precautions
SMP-M240 In the black mark detecting mode, the printer requires that the preprinted black mark is accordant with the black mark specifications (details please refer to 4.2), otherwise the black mark can not be detected correctly. Be sure to use up the power of the battery before charge it, as it can ensure the ... - Page 5 SMP-M240 chemical reaction, and then may cause the battery overheat, ignite, and / or explosion. Do not make the battery contact with the power outlet and / or car cigarette lighter socket. This may cause high pressure and excessive current, and lead to the battery overheat, burning and / or explosion.
-
Page 6: Chapter 1 Brief Introduction
SMP-M240 Chapter 1 Brief Introduction 1.1Appearance 1.Power indicator(Red Light) 2.Status indicator(Blue Light) 3.Infrared ray (IR) interface 4.USB/RS232 interface 5.Power input 6.FEED button 7.Power on/off 8.Top cover 9.RS232 interface 10.Li-ion battery cover USER_MANUAL www.syncrown.com... -
Page 7: Accessories
SMP-M240 1.2 Accessories Standard accessories Li-ion battery Power Adapter Paper USB cable Optional accessories Leather case Serial interface cable USER_MANUAL www.syncrown.com... -
Page 8: Chapter 2 Specifications
SMP-M240 Chapter 2 Specifications Item Parameter Printing method Thermal line printing Resolution 203DPI, 8dots/mm Printing Printing speed 50~70mm/s Valid printing width 48mm Interface IrDA,Bluetooth,RS232,USB Power saving Sleep mode Character Set Font ASCII: 8×16 9×24 12×24;EUC:16×16;Multiple code pages support UPC-A, UPC-E, EAN8, EAN13, CODE39, ITF, CODEBAR, CODE128,... -
Page 9: Chapter 3 Operation Methods
SMP-M240 Chapter 3 Operation Methods 3.1 Preparation before using 3.1.1 Li-ion battery installation 1) Refer to the picture, put the battery in the battery slot, please pay attention to the correct insert, (+) and (-). 2) Close the battery case. -
Page 10: Basic Function
SMP-M240 3.2 Basic Function 3.2.1 Printer on The printer is powered on by pressing the 【Power】 button for about 2 seconds; the power indicator is on with red color whenever the printer is on. Notice: when the batter is almost exhausted, the power indicator blinks with blue color, in this case, you must charge the battery by using the adaptor. -
Page 11: Interface And Printing
3.3.2 Infrared ray (IR) & IrDA interface SMP-M240 can be connected to your main device through IR, RAW-IR and IrDA can not be available at the same time. Reset the printer if it is not the model you want. -
Page 12: Led Indicator And Buzzer Definition
SMP-M240 3.4 LED indicator and Buzzer definition There are one buzzer and two LED indicators to indicate the printer status. LED indicators indicate current status and buzzer indicates the changes of status. Status indicator（blue） Power indicator (red） Status Flash quickly... -
Page 13: The Installation Of Printer Driver
SMP-M240 3.5 The installation of printer driver 1) Double click“SynCrownSMPMPrinterDriver-v-1.0.0.2.exe”， Click “Install ”. 2) Choose the printer port and printer type you need and click “OK” to next step. 3) Click “Finish” . A successful installation USER_MANUAL www.syncrown.com... -
Page 14: Chapter 4 Other Information
SMP-M240 Chapter 4 Other information 4.1 Printer technical manual(control command) Please refer to SMP-M240 technical manual. 4.2 Preprinted black mark specification If user wants to locate receipt by detecting preprinted black mark, shall accord to the following specification for the black mark. Otherwise it may cause printer can’t recognize the black mark.
