- Page 1 D O C - 0 4 4 0 - 0 1 0 , R E D DEMOAC Development Board for Freescale FLEXIS AC MCU Family Supports: MCF51AC256 MC9S08AC128 MC9S08AC60 MC9S08AC16 Hardware User Guide www.axman.com Web Site: Support: support@axman.com...
-
Page 2: Table Of Contents
D E M O A C U S E R G U I D E A P R I L 1 0 , 2 0 0 8 CONTENTS CAUTIONARY NOTES ......................4 TERMINOLOGY.........................4 FEATURES ..........................5 REFERENCES ...........................6 GETTING STARTED........................6 APPLICATION DEVELOPMENT ....................6 HARDWARE CONFIGURATION ....................6 INTEGRATED BDM....................... - Page 3 D E M O A C U S E R G U I D E A P R I L 1 0 , 2 0 0 8 INITIAL FLASH PROGRAMMING ................... 16 FIGURES Figure 1: BDM Connector ......................7 Figure 2: PWR Jack........................8 Figure 3: PWR_SEL Option Header ...................9 Figure 4: VX_EN Option Header ....................9 Figure 5: USB_COM Option Header ..................12...
-
Page 4: Cautionary Notes
3) EMC Information on the DEMOAC board: a) This product, as shipped from the factory with associated power supplies and cables, has been verified to meet with FCC requirements as a CLASS A product. -
Page 5: Features
ColdFire V1 MCF51AC256, and the MC9S08AC128/60/16. Application development on the DEMOAC is quick and easy with the integrated USB-BDM, sample software tools, and exam- ples. An optional BDM_PORT port is also provided to allow use of an external BDM cable. An 80-pin MCU_PORT connector provides access to all IO signals on the target MCU. -
Page 6: References
DEMOAC Top Silk GETTING STARTED To get started quickly, please refer to the DEMOAC Quick Start Guide. This quick start will il- lustrate connecting the board to a PC, installing the correct version of CodeWarrior Develop- ment Studio, and running a simple program. -
Page 7: Bdm Port Connector
POWER The DEMOAC may be powered from the integrated USB BDM, an on-board voltage regulator, or from the MCU connector at J1. Alternatively, the DEMOAC may be configured to provide power to external circuitry connected to the MCU connect J1. -
Page 8: Bdm Power
D E M O A C U S E R G U I D E A P R I L 1 0 , 2 0 0 8 Figure 2: PWR Jack 2.1mm, center-positive, +V input Applied voltage: +7V to +18V A voltage regulator provides +5V to the target MCU and board circuitry. -
Page 9: Vx_En Option Header
D E M O A C U S E R G U I D E A P R I L 1 0 , 2 0 0 8 Figure 3: PWR_SEL Option Header PWR_SEL • • • Selects input voltage from POWER connector NOTE: The VR1 input is connected to the regulator at VR2. -
Page 10: Mcuvdd
D E M O A C U S E R G U I D E A P R I L 1 0 , 2 0 0 8 apply an alternate power input, simply remove the cut-trace using a sharp knife. Then either solder a wire to the thru-hole via or install a pin header and wire-wrap a wire connection. -
Page 11: Reset Switch
MCU. Refer to the target device Reference Manual for further details. TIMING The DEMOAC board provide a 4Mhz oscillator timing source for use with the target MCU. The OSC_SEL option header allows this input to be disconnected if necessary. In default configu- rations, the OSC_SEL option header is not installed and cut-traces provide the default connec- tions. -
Page 12: Communications
2 0 0 8 Communications The DEMOAC board provides 2 UART ports, 1 IIC port, and 1 CAN port. Serial RS-232 com- munications is support through the integrated BDM. Access to each MCU UART is also avail- able at connector J1. RS-232 translation is not provided on signals to connector J1. -
Page 13: Potentiometer
D E M O A C U S E R G U I D E A P R I L 1 0 , 2 0 0 8 Potentiometer A 5k ohm, single-turn, thumb-wheel type, potentiometer at RV1 provides continuous, variable resistance input for user applications. -
Page 14: Accelerometer Configuration
1 0 , 2 0 0 8 The DEMOAC applies the MMA7260Q, 3-axis accelerometer for tilt and motion-sense applica- tions. The accelerometer supports 4 user selectable sensitivities - 1.5g / 2g / 4g / 6g. The SLEEP* input allows the device to be placed in a low-power mode. Separate X-, Y-, and Z- axis readings are routed to the MCU. -
Page 15: Mcu_Port
A P R I L 1 0 , 2 0 0 8 MCU_PORT The MCU PORT provides user access to the DEMOAC I/O ports. Refer to the MCF51AC256 or MC9S08AC128/60/16 Integrated Device Reference Manual for signal details. Figure 7: MCU_PORT Connector IRQ*/TPMCLK... -
Page 16: Troubleshooting
1 0 , 2 0 0 8 TROUBLESHOOTING The DEMOAC is fully tested and operational before shipping. If it fails to function properly, in- spect the board for obvious physical damage first. Verify the communications setup as de- scribed under GETTING STARTED. - Page 17 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Freescale Semiconductor DEMO51AC256KIT DC9S08AC128 DC9S08AC16 DC9S08AC60...
