NEXTLINK A/S Bluespoon AX2 User Manual

Bluespoon™ AX2 overview and features.
FIG 1-Front view
Charging port for
Mini-USB cable and neck carrying strap
Button
VOLUME DOWN
FIG 4-Charging the battery
Mini-USB plug connected
to headset
Normal USB plug
Connected to computer
FIG 6-Preparing the earpieces
Two earpieces with soft springs are supplied.
Soft springs are made extra long, and can be cut by
you to fit your ear.
Soft spring part
FIG.8-How earpiece/headset sits in your ear
A) B)
FIG 2-Rear view
Center button
TALK
(blue and red
light)
Button
VOLUME UP Loudspeaker
Charge headset
for 8 hours
before "first
time use"
We recommend that you
cut a little piece of the
soft spring at a time.
Approx. 0.3 cm.
(0.125 inches)
Put the earpiece with soft
spring on the headset, and
try headset on.
Additional cutting might be
needed. Use scissors or a
hobby knife for cutting.
NOTE: Remember to put
earpiece with soft spring on
headset when trying it on.
Battery drawer with
finger grip
Earpiece with
Soft spring
Microphone
FIG 5-Changing the battery
ONLY USE ORIGINAL BLUESPOON™
AX2 BATTERIES!
FIG 7- Left or right ear usage
Put one of the earpieces with softspring on the
headset, and turn it to the approx. angles shown
below.
You may adjust earpieces further for a more comfortable fit.
Left ear
A) Illustration shows how the earpiece with soft spring
should sit in your ear.
Do not place earpiece with soft spring in the ear, without
the headset attached (illustration is only to show position
of the earpiece)
HOW TO PLACE HEADSET:
Hold headset with three fingers, insert the headset in
your ear. Use your indexfinger to bend the soft spring.
Place soft spring in the upper bend of your ear
(see illustration A)
B) Illustration shows how the headset should sit in the right
ear.
FIG 3-Side view
Charging port for
Mini-USB cable and
neck carrying strap
Coin Cell type battery
(Widest side downwards)
Battery drawer out
(drawer can be pulled all
the way out)
Right ear
