Table of Content TG 3030-12V 1. User manual ........................2. Legal regulations ......................3. Safety instructions ......................4. Technical information ....................5. Functional principle ...................... 6. Technical data ........................ 8. Mounting ......................... 9. Cut out dimensions ....................... 10. Dimensions (H x W x D) .................... -
Page 2: User Manual
1. User manual This instruction manual contains information and instructions to enable the user to work safely, correctly and economically on the unit. Understanding and adhering to the manual can help one: Avoid any dangers. Reduce repair costs and stoppages. Extend and improve the reliability and working life of the unit. -
Page 3: Safety Instructions
Disregarding the instruction manual Operating error Inappropriate work on or with the unit The use of non-specified spare parts and accessories Unauthorised modifications or changes to the unit by the user or his personnel The supplier is only liable for errors and omissions as outlined in the guarantee conditions contained in the main contractual agreement. -
Page 4: Technical Information
4. Technical information Peltier cooling units are intended to be used as a complementary accessory to larger industrial equipment. Theyare used where heat needs to be dissipated from electrical control cabinets or similar enclosures in order to protect heat sensitive components. Peltier cooling units can dissipate heat from sealed enclosures such as control cabinets. -
Page 5: Technical Data
6. Technical data Order Number 3030305 Cooling capacity L35L35 30 W Temperature range -20°C - +65°C Air volume flow Ambient air circuit: 39 m³/h Cabinet air circuit: 20 m³/h Mounting External (with frame) Housing Material Stainless steel AISI 304 (V2A) Dimension HxWxD 212 x 158 x 131 mm Weight... -
Page 6: Mounting
8. Mounting Always switch off power supply before starting any work on the unit. Installation Ensure that flows of air leaving and entering the cooling unit, internal and external, are not obstructed. Before drilling the enclosure, ensure the fixing elements and couplings will not interfere with the equipment inside the enclosure itself. -
Page 7: Cut Out Dimensions
9. Cut out dimensions Version Nr. 1-1 - 11.11.2017 Doc. Nr. 993030305 7 / 12... -
Page 8: Dimensions (H X W X D)
10. Dimensions (H x W x D) Version Nr. 1-1 - 11.11.2017 Doc. Nr. 993030305 8 / 12... -
Page 9: Electrical Connection
11. Electrical connection High electric voltage present. Installation, maintenance, cleaning and any other work must be carried out by qualified personnel only. The personnel must ensure that for the duration of this work the unit and the cabinet are disconnected from the electrical supply and protected against unauthorised/accidental reconnection. -
Page 10: Wiring Diagram
12. Wiring diagram Thermoelectric Elements Internal Fan Ambient Fan Version Nr. 1-1 - 11.11.2017 Doc. Nr. 993030305 10 / 12... -
Page 11: Taking Into Operation
13. Taking into operation The power supply rating on the rating plate must comply with mains supply Always disconnect the power supply before opening the unit. Heat load to be dissipated from enclosure should not exceed specific cooling output of the unit at any condition. -
Page 12: Maintenance
1 x CE Conformity Declaration 4 x Screws M6*10 4 x Washers Seifert Systems GmbH Seifert Systems Ltd. Seifert Systems AG Seifert Systems Inc. Seifert Systems Pty Ltd. Haßlinghauser Str. 156 HF09/10 Wilerstrasse 16 75 Circuit Drive 105 Lewis Road Hal-Far Industrial Estate...
