Heat Pump
Model HP6220
220-240 V~, 50 Hz
For illustrative purposes only.
Don't forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance,
which may result in updates to the instruction manual without
notice.
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O
Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European
Union by/Distribué dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
(307IO) HEAT PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 12/15/2016
IMPORTANT
SAFETY RULES
Read, Understand, and Follow
all Instructions Carefully before
Installing and using this Product.
©2016 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.
- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
307
English
IO
307-*IO-R0-1712
Advertisement
Table of Contents
Related Manuals for Intex HP6220
Summary of Contents for Intex HP6220
-
Page 1: Heat Pump
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –... -
Page 2: Table Of Contents
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English TABLE OF CONTENTS Warnings................3-4 Parts Reference..............5-6 Product Specifications............7 Set Up Instructions............... 8-12 Display Control Panel Operation......... 13 Maintenance................14 Pool Water Chemistry............14 Heat Pump Caring..............15 Troubleshooting.............. -
Page 3: Warnings
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • This appliance shall be installed in accordance with national wiring regulations. -
Page 4: Warnings
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English WARNING • Check if the voltage indicated on the heat pump corresponds to the local mains voltage before you connect the unit. • Do not use the heat pump in combination with other heating system such as electric or gas heaters. -
Page 5: Parts Reference
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English PARTS REFERENCE Before installing your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. REF. - Page 6 (307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English PARTS REFERENCE (continued) Before installing your product, please take a few minutes to check the contents and become familiar with all the parts. For 38mm collar nut hose connection For 50mm pipe fitting NOTE: Drawings for illustration purpose only.
-
Page 7: Product Specifications
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English PRODUCT SPECIFICATIONS *Measured Condition at 27°C Ambient Air, 27°C Water, 80% Humidity Heat Output 8.20 kW (27,820 Btu) / hr Power Consumption 1.71 kW (5,800 Btu) / hr Coefficient of Performance (COP) *Measured Condition at 15°C Ambient Air, 26°C Water, 70% Humidity Heat Output... -
Page 8: Set Up Instructions
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SET UP INSTRUCTIONS IMPORTANT Always keep the unit upright. If the unit has been tilted or put on its side, wait 24 hours before starting the heat pump. Location and Space Requirement •... -
Page 9: Drain Hose Connector 2
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SET UP INSTRUCTIONS (continued) Condensation Draining Hose Installation NOTE: The air drawn into the heat pump is strongly cooled by the operation of the heat pump for heating the pool water, which may cause condensation on the evaporator fins. The amount of condensation may be as much as several liters per hour at high relative humidity. - Page 10 (307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SET UP INSTRUCTIONS (continued) Typical above ground pool arrangement Pool Chemical Treatment Filter Pump NOTE: To allow water to flow into the heat pump, make sure the valve in the middle of the bypass kit is closed and the other two valves on the sides are open.
-
Page 11: Electrical Connection
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SET UP INSTRUCTIONS (continued) Electrical Connection WARNING Although the heat pump is electrically isolated from the rest of the swimming pool system, this only prevents the flow of electrical current to or from the water in the pool. Grounding the heat pump is required for protection against short-circuits inside the unit. -
Page 12: Set Up Instructions
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SET UP INSTRUCTIONS (continued) 7. To set the water temperature and program the heat pump, see “Display Control Panel Operation” section for details. Depending on the initial temperature of the pool water and the ambient air temperature, it may take several days to heat the pool water to the desired temperature. -
Page 13: Display Control Panel Operation
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English DISPLAY CONTROL PANEL OPERATION CONTROL UNIT PANEL A: On/Off Button B: Temperature Increase Button C: Temperature Decrease Button D: Set Button E: LED Display F: Heating G: Timer Off H: Timer On I: Warning On/Off Button: Press this button to start the heat pump, the LED display will show the... -
Page 14: Maintenance
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English MAINTENANCE 1. Check the water supply circulation system regularly for water leakage and air entering into the system, as the performance and reliability of the unit will be reduced. 2. -
Page 15: Heat Pump Caring
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English HEAT PUMP CARING INSTALLATION - Verify that the installation was done This Flow Chart will teach according to owner's manual instructions. you the steps to follow to protect your heater. FIRST TIME OR SPRING STARTUP - Hook up pool water piping but do not hook up the Heater yet. -
Page 16: Troubleshooting
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English TROUBLESHOOTING PROBLEM CAUSE SOLUTION THE HEAT PUMP • Not plugged in, the instructions in “Initial • Follow the instructions in “Initial Operation” section. DOES NOT TURN Operation” section were not followed. •... -
Page 17: Service By Qualified Technicians
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SERVICE BY QUALIFIED TECHNICIANS Parameter Setting The following sections shall be operated only by qualified technicians for after-service or maintenance. • Check the parameters: Press , then press to check the parameter of B - C - D - E - F - G. - Page 18 (307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SERVICE BY QUALIFIED TECHNICIANS (continued) LED Display Error Code ERROR CODE SHOWN ON LED CAUSE SOLUTION DISPLAY • Check ambient air temperature variation, specially from day time to mid-night. Wait until ambient air temperature rises for •...
- Page 19 (307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SERVICE BY QUALIFIED TECHNICIANS (continued) Use the following procedure to adjust the bypass: • Fully open all three valves. • Slowly close valve 1 until the water pressure is increased and until the water flow switch is on. •...
- Page 20 (307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SERVICE BY QUALIFIED TECHNICIANS (continued) Regulation (EU) N 517/2014 of 16/04/14 on fluorinated greenhouse gases and repealing Regulation (EC) N 842/2006 Leak checks Operators of equipment that contains fluorinated greenhouses gases in quantities of 5 tons of , equivalent or more and not contained in foams shall ensure that the equipment is checked for leaks.
- Page 21 (307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SERVICE BY QUALIFIED TECHNICIANS (continued) Parts Diagram (for qualified technician use only). SAVE THESE INSTRUCTIONS Page 21...
-
Page 22: Service By Qualified Technicians
(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016 English English SERVICE BY QUALIFIED TECHNICIANS (continued) REF. NO. DESCRIPTION REF. NO. DESCRIPTION TOP COVER EXHAUST PIPE TOP FRAME HIGH PRESSURE PROTECTION SWITCH AMBIENT TEMPERATURE SENSOR RETURN PIPE AMBIENT TEMPERATURE SENSOR CLIP LOW PRESSURE PROTECTION SWITCH DISTRIBUTOR SETS SUCTION VALVE... -
Page 23: Limited Warranty
