Prime

5510

INSTRUCTION MANUAL

DIR | www.dirgroup.co.uk |

Table of Contents

Need help?

Do you have a question about the Prime 5510 and is the answer not in the manual?

Questions and answers

Summary of Contents for DIR Prime 5510

Page 1 Prime 5510 INSTRUCTION MANUAL DIR | www.dirgroup.co.uk |...
Page 2: Table Of Contents
CONTENTS www.dirgroup.co.uk Product Introduction Warranty Important Safety Warning Name and function of components Function Method of usage Instructions Product specification Aftercare Instructions Contact Us Please read the operation manual before using the product. Please put the operation manual in the place easy for you to read and you can read it at any time.
Page 3: Product Introduction
Product Name: Prime Product Code: 5510 Thank you for selecting DIR, the leading salon and beauty Furniture company in the UK. The Toya pedicure spa comes with four-wheel driven muted massage system which gives you the experience of ultimate relaxation. Please take time to read this entire manual before assembly and use.
Page 4: Warranty
WARRANTY www.dirgroup.co.uk The warranty period is one year. DIR warrants to you, the original buyer, that goods shall be free of defects in material and/or workmanship attributable to manufacture for one year from date of buyer’s receipt of product. Damage resulting from improper handling after merchandise is received, or from exposure to weather or extreme atmospheric conditions is not covered by the warranty.
Page 5: Important Safety Warning
ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 1.IMPORTANT SAFETY WARNING. Don t allow children to touch moveable part of this product. Please use well-grounding power supply suited to this product. Please pull out the plug after use or before cleaning to avoid injury or Damage to the product. Please operate this product according to this manual instruction.
Page 6 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk People who are suffering from fever are not suitable to use this product. Pregnant women or women that are in menses period are not suitable to use thisproduct. People who got injured or skin disease are not suitable to use this product. Children under 14-year old or people mentally unbalanced without being supervised are not allowed to use this machine.
Page 7 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk If this product will be left unused for long, please curl up the wires and reserve this product in dry and dustless environment. Don t reserve this product under high temperature or near fire and avoid longtime direct sunshine. If the detachable cord / supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a Hazard.
Page 8: Name And Function Of Components
ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk Function Designed with a four-wheel driven muted massage mechanism which can move up and down in the backrest. Programmed with five kinds of emulational massage functions of Shiatsu, kneading, flapping, knocking and synchronous kneading and flapping. Programmed with manual and automatic control modes for the upper body. Under the automatic mode, it offers three automatic changed combinations of massage function: lower, upper and full...
Page 9: Method Of Usage
ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 1.Controller operate Button Adjust massage balls To start or stop massage of the upper body (1)Auto Massage Button Adjust massage balls To carrying on automatic massage around the neck shoulder mainly Carry on automatic massage around in carrying the waist mainly Adopt the various tactics to carry on automatic massage to different position of the upper part of the body, the massage...
Page 10 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk Press this button continually and the backrest frame For speed and massage treatments sel- will move upward, loose your finger and the movement ection.five speed options available.the Speed will stop. indicators are as follows(black stands Recline for on) Back Press this button continually and the backrest frame Width:when massage treatment of flap-...
Page 11: Instructions
ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 2.Components install direction Place the bottom frame of massage chair on the spa tub. Make sure the holes of the bottom frame are aligned with the pre-drilled holes on the spa tub. Secure the massage chair onto spa tub by using provided hardware as shown in the diagram below.
Page 12 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 3.armrest assembling instructions (1)The hex head bolt (M10X40) goes through the hole of armrest mounting bolt (2)Make the right position for the armrest turning mechanism, a screw hole, the seat positioning pin of armrest mounting and hex head bolt, then tighten the bolt 4.Instruction of backrest installation (1).Put the back spindle in the slot of the installation base.
Page 13 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk (2).Put the installation hole of the electro-motional rod in the backrest in order with the seat hole of the electro-motional rod in the backrest.and then insert the peg Caution (1). The correct method of operation: before operating the controller, please make sure that the backrest electronic cylinder is connected well with the pin that fixes the backrest.
Page 14 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 5.Operation sequence SWITCH ON POWER (1).insert the plug into the socket outlet. (2).switch on the power button behind the armrest. MASSAGE (1)Select relative massage according to the operation instructions of the control. SWITCH OFF POWER (1).stop overall massage. (2).switch off the power button behind the armrest.
Page 15 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 6.Attaching or detaching the pillow pad and back cushion The pillow pad and back cushion (recommended) reduces the kneading intensity of your neck and shoulder, but you can decide to put it on or not according to your personal need.(1) Sticker connects the pillow pad and back cushion. WARNING : IN CASE OF DANGER, DO NOT REMOVE THE CUSHION...
Page 16 ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 7.To Adjust The Back Simultaneously Backrest adjustment press and hold the button on the controller,the backrest will recline backward slowly. Release the button,then the backrest will be stopped upright press and hold the button on the controller,the backrest will move slowly Loose the button,then the backrest will be stopped WARNING: DO NOT EXERT ANY PRESSURE OTHER THAN YOUR OWN BODY ON THE BACK WHILE IT IS RISING.
Page 17: Product Specification
ASSEMBLY INSTRUCTIONS www.dirgroup.co.uk 8.To Adjust Seat Frame Separately The flex fuction of seat frame could fix the different height of the people to adjust the massage place of the calf airbags,the maximum distance moving forward and backward is 120mm. Power supply: 110-120V~ 60Hz 220-240V~ 50Hz/60Hz Rated power: 160W Safety structure: Class I...
Page 18: Aftercare Instructions
AFTERCARE INSTRUCTIONS www.dirgroup.co.uk After an initial period of use, check all fastenings for any loosened screws etc. If found, please tightened appropriately...
Page 19: Contact Us
CONTACT US www.dirgroup.co.uk DIR BIRMINGHAM DIR NEW YORK DIR IRELAND (HEADQUATERS) 66 Rea Street South 24 Woodward Ave. Unit 5 Block E Birmingham Suite C Riverview Business Park B5 6LR Queens, NY 11385 Nangor Road Dublin 12 Sales: +44(0)800 085 3667...
