Summary of Contents for Sonorix C2
-
Page 3: Table Of Contents
Wearing the C2......................5 Charging the Battery ....................5 Switching the C2 ON/OFF..................... 5 Pairing C2 with Bluetooth Devices ................6 Stereo Audio & Remote Control Operations ............... 6 Using C2 for Handsfree Operations................7 Hints for Optimum Audio Transmission ..............8 Specifications........................ -
Page 4: Safety Instructions
Firmware Upgradeable Introduction Thank you for purchasing our C2 Stereo Headset. Product Functions The C2 Stereo Headset is a high quality Bluetooth Functions as Stereo Headset when connected enabled audio device for audio entertainment and to Bluetooth Devices Supporting A2DP voice functions at its best. -
Page 5: What's Included In The Package
During charging mode, LED will light up red. When charged, LED will change to constant blue. Switching the C2 ON/OFF To switch ON C2, slide the power switch to O. To switch OFF C2, slide the power switch to X. -
Page 6: Pairing C2 With Bluetooth Devices
Function Action / LED / Tone Indicator To put C2 in pairing mode, click and hold ‘MFB’ and slide Power Switch to O. Pairing Mode Blue LED will first flash rapidly and then change to alternating red and blue flash. -
Page 7: Using C2 For Handsfree Operations
To end call first, long click ‘MFB’ during ‘Talk Mode’. If the other party ends the call, End Call then C2 will automatically return to handsfree standby mode. Call Transfer Short click ‘MFB’ during ‘Talk Mode’ to talk over the phone and vice versa. Reconnect To reconnect C2 with phone, long click MFB in standby mode. -
Page 8: Hints For Optimum Audio Transmission
Likewise, the human body also affects the performance and since the C2 is clipped onto clothing and held close to the body, it is a good practice not to cover the C2 or the host device with hand. Specifications Standards Bluetooth Specification V1.2... - Page 9 Product Warranty Disclaimer Notice * Openbrain Technologies warrants this product against all The manufacturer shall not be liable for errors contained herein or defects in material and workmanship for a period of one year for incidental or consequential damages in connection with the from the date of purchase by end user.
- Page 10 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
- Page 15 CONTENTS Safety Instructions......................4 Introduction........................4 Product Features ......................4 Product Functions ......................4 What’s Included in the Package................... 5 Description of Parts ...................... 5 OLED Display Window....................5 Wearing the C3......................5 Charging the Battery ....................6 Switching the C3 ON/OFF..................... 6 Pairing C3 with Bluetooth Devices ................
-
Page 16: Safety Instructions
Safety Instructions Product Features Check the laws and regulations on the use of CD Quality Sound And High Quality Voice mobile phones and handsfree equipments in Supports A2DP For Stereo Audio Streaming and areas you intend to use. AVRCP For Remote Controlling Of Music Continuous listening of music at high volume Playback Functions may cause hearing defects. -
Page 17: What's Included In The Package
What’s Included in the Package OLED Display Window C3 Stereo Headset Earphone Set Audio Handsfree Battery Spare sponge set for earphone Connection Connection Level DC Adapter for charging USB Cable User Manual Description of Parts Earphone Jack Wearing the C3 Simply clip the Stereo Headset onto shirt or clothing. -
Page 18: Charging The Battery
To switch ON C3, slide the power switch to O. indicator. If battery level is low, beep tone will be sonorix icon will first be displayed for 3 seconds heard for 1 minute and C3 will switch OFF. followed by Service icons for 3 seconds. -
Page 19: Pairing C3 With Bluetooth Devices
Pairing C3 with Bluetooth Devices Function Action OLED Indicator To put device in pairing mode, click and hold ‘MFB’ and slide Switch to O. When the icons Wait for Pairing ‘Wait for Pairing’ & ‘BD_ADDR’ are displayed, release button. Pairing Mode Pairing mode lasts for 3 minutes. -
Page 20: Using C3 For Handsfree Operations
Using C3 for Handsfree Operations Function Action OLED Indicator On an incoming call, ‘Ringing’ and ‘Caller ID’ Ringing icons are displayed alternately with ring tone. Short click MFB to answer call. Answer Call Note : If Caller ID function is not supported by 0313810295 phone, only ‘Ringing’... - Page 21 Function Action OLED Indicator Reject Call To reject call, long click ‘MFB’. To end call first, long click ‘MFB’ during ‘Talk Mode’. If the other party ends the call, then C3 End Call will automatically return to handsfree standby mode. Short click ‘MFB’...
-
Page 22: Stereo Audio & Remote Control Operations
Stereo Audio & Remote Control Operations Function Action OLED Indicator Short click MFB to play. Play / Pause To pause, short click MFB. Icon display for 1 second. Long click (+) key to skip to next song. Next Icon display for 1 second. Long click (-) key to play previous song. -
Page 23: Hints For Optimum Audio Transmission
C3 or the host device with hand. Firmware Upgrading To maintain maximum interoperability among Bluetooth devices, provides interface for firmware upgrading. For the instructions on how to upgrade firmware of C3, please visit our website, www.sonorix.com... -
Page 24: Specifications
Specifications Standards Bluetooth Specification V1.2 RF Frequency Range 2402 ~ 2480 MHz Profiles Supported A2DP, AVRCP, Headset, Handsfree Transmission Power 0.25 ~ 2.5mW (Class 2) Receiver Sensitivity < -80dBm (PER 1 %) Distance 10m (in open space) Audio Output > 20mW Audio S/N >... - Page 25 Product Warranty Disclaimer Notice * Openbrain Technologies warrants this product against all The manufacturer shall not be liable for errors contained herein or defects in material and workmanship for a period of one year for incidental or consequential damages in connection with the from the date of purchase by end user.
- Page 26 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
