Summary of Contents for SilverLeaf Electronics VDX 404
- Page 1 VDX 404 Manual VDX 404 Automotive Video Switch Installation and Configuration Manual SilverLeaf Electronics, Inc. 2472 SW Ferry St. Albany, OR 97322 (541) 967-8111 www.vidswitch.com Page 1...
- Page 2 VDX 404 Manual Product Summary The VDX 404 allows four video sources to be routed to four video outputs in virtually any combination. The switch status is controlled by a set of discrete inputs that can be connected to vehicle blinkers or other switches or devices. It can also read a J1939 vehicle data bus to determine whether the vehicle is in Reverse.
- Page 3 The program is available for download at www.vidswitch.com. The adapter cable (p.n. HA060) can be ordered from SilverLeaf Electronics. The cable includes a pass-through so power can be maintained to the unit while it is hooked up to the PC.
- Page 4 COM port. When you have the correct port chosen, within a few seconds the unit will download the current configuration from the VDX 404. The window should look something like the diagram.
- Page 5 VDX 404 Manual You can manually change this by clicking on Manual Command. You can then send a command to switch the outputs around. This also puts the unit into “Manual” mode. This feature is provides mostly as a way to test the wiring.
- Page 6 VDX 404 Manual the unit is programmed to recognize the repetitive on- off-on-off behavior and treat the signal as being “on” until it is seen to be off for a certain period of time. A “Momentary” switch is an input that triggers briefly to indicate a change from being on to being off.
-
Page 7: Ordering Information
The process can take up to a minute or more, depending on the complexity of the configuration. Ordering Information VDX 404 Automotive Video Switch JR404 Serial Programming Cable HA060 USB-Serial Adapter HA302 Connector Kit (2 Molex Connectors, 20 Pins) HA061 All parts can be ordered directly from SilverLeaf Electronics, Inc.. Page 7... - Page 8 This warranty shall be invalid if the product is damaged as a result of defacement, misuse, abuse, neglect, accident, destruction, alteration, improper electrical voltages or currents, repair or maintenance by any party other than SilverLeaf Electronics Inc. or an authorized service facility, or any use violative of instructions furnished by us.
