Alphason Designs ABR800 Assembly Instructions Manual

Ambri series av cabinet

Hide thumbs

Table of Contents

Quick Links

Download this manual

BEFORE STARTING THIS

ASSEMBLY PLEASE TAKE TIME

TO FAMILIARISE YOURSELF

WITH THE COMPONENTS

LISTED ON THE BACK PAGE

Please Note:

Maximum load for this support is 80Kg.

This support must be assembled in accordance with these assembly instructions.

Maximum load for each glass shelf is 60kg.

Alphason Designs Ltd. accepts no liability for any damage caused through incorrect or inappropriate use of this audio visual support.

Alphason Designs Limited

Alphason House, Bolton Road, Atherton, Greater Manchester M46 9AW UK

Tel: +44 (0)1942 885600

Fax: +44 (0)1942 876955

www.alphasondesigns.com

MODEL: ABR800

AV CABINET

ASSEMBLY INSTRUCTIONS

PLEASE NOTE OTHER TOOLS REQUIRED:

CROSS-HEAD SCREWDRIVER

A HAMMER

issue

AI-01 09/06

181751

Table of Contents

Need help?

Do you have a question about the ABR800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alphason Designs ABR800

Page 1 This support must be assembled in accordance with these assembly instructions. Maximum load for each glass shelf is 60kg. Alphason Designs Ltd. accepts no liability for any damage caused through incorrect or inappropriate use of this audio visual support. Alphason Designs Limited...
Page 2 STAGE 1 1. 1. • Place base panel on its back edge, on a clean flat surface to avoid scratching. Using screws attach panels to panel Insert 4X (Minifix cams) into large holes in panel • Ensure arrows are pointing to the outside edge of the panel. STAGE 2 2.
Page 3 STAGE 5 • Assemble top panel as shown in the diagram to the left. • Ensure dowel fixings align with corresponding holes in panels Tighten all cams that were put in place in stage 2. • STAGE 6 Position location tape pieces around the rebate in •...
Page 4 STAGE 9 • Attach left and right hand flap stays using screws If adjustment of flap stays is required, this can • be achieved by turning grey plastic column shown in fig 9a below. The flap stays may require adjusting; Adjustable Screw clockwise to loosen the movement.
Page 5 MODEL: ABR800 CERTIFICATE OF CONFORMITY COM PO NENT DE S CRI P TI ON PACKED BY BASE PANEL (with pre fitted dowels) TOP PANEL LEFT END PANEL RIGHT END PANEL (with pre fitted dowels) BACK PANEL GLASS PANEL FOR DOOR...
Page 6 C O M PO NENT PACKED BY DE S C RIPTI ON FLAP HINGE 6 x 1/2” SCREW RIGHT HAND FLAP STAY LEFT HAND FLAP STAY TOUCH PLATE 6 X 5/8” SCREW ROLLER GLIDE SHELF PEG 34mm MINIFIX DOWEL MINIFIX CAM PINE TREE CLIP 8 X 1”...
