- Page 1 0402163 ITEM # OLONY PARK 4 PC CONVERSATIONAL SET CR-13S023B MODEL # ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents ...........................3 Hardware Contents ..........................6 Safety Information ..........................6 Preparation ............................6 Assembly Instructions ........................7 Operating Instructions ........................10 Care and Maintenance ........................10 Warranty ............................10 Replacement Parts List ........................10 Lowes.com/gardentreasures... -
Page 3: Package Contents
PACKAGE CONTENTS PART PART DESCRIPTION QUANTITY DESCRIPTION QUANTITY Table Top Frame Table Leg 2 Table Leg 1 Connector Bracket Lowes.com/gardentreasures... - Page 4 PACKAGE CONTENTS PART PART DESCRIPTION DESCRIPTION QUANTITY QUANTITY Seat Frame Backrest Left Armrest Chair Cushion 1 Right Armrest Chair Cushion 2 Lowes.com/gardentreasures...
- Page 5 PACKAGE CONTENTS PART PART DESCRIPTION QUANTITY DESCRIPTION QUANTITY Sofa Seat Frame Sofa Backrest Left Sofa Armrest Sofa Cushion 1 Right Sofa Armrest Sofa Cushion 2 Lowes.com/gardentreasures...
-
Page 6: Hardware Contents
HARDWARE CONTENTS (shown actual size) Dia.18 x T1.2 Bolt Nut M6 x 12 Washer Short Bolt Qty. 8 Qty. 8 Qty. 20 M6 x 25 Wrench Hex Wrench Medium Bolt Qty. 1 Hex Wrench M6 x 35 Qty. 1 (Not actual Long Bolt Qty. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Insert table legs 1 (B) and table legs 2 (C) into the table top frame (A), lining up the holes. Secure using short bolts (BB) and the hex wrench (DD). Hardware Used M6 x 12 Short Bolt Hex Wrench 2. - Page 8 ASSEMBLY INSTRUCTIONS 3. Attach the left armrest (F) and the right armrest (G) to the seat frame (E) using long bolts (FF), washers (GG) and the hex wrench (HH). Attach the backrest (H) to the left armrest (F) and right armrest (G) using long bolts (FF), washers (GG) and the hex wrench (HH).
- Page 9 ASSEMBLY INSTRUCTIONS 5. Attach the left sofa armrest (L) and the right sofa armrest (M) to the sofa seat frame (K) using long bolts (FF), washers (GG) and the hex wrench (HH). Attach the sofa backrest (N) to the left sofa armrest (L) and right sofa armrest (M) using long bolts (FF), washers (GG) and the hex wrench (HH).
-
Page 10: Operating Instructions
For replacement parts, call our customer service department at 1-800-643-0067, 8 a.m. - 8 p.m., EST, Monday - Friday. PART DESCRIPTION PART# Medium Bolt Short Bolt Bolt Nut Hex Wrench Wrench Long Bolt Washer Hex Wrench Printed in China Garden Treasures is a registered trademark ® of LF, LLC. All rights reserved. Lowes.com/gardentreasures...
