Castle Nut
Cotter Pin
Spindle
•
Maintain recommended tire air pressure at all times.
•
Check the casters for proper adjustment to minimize
any unwanted motion in the caster. If unwanted mo-
tion occurs with the caster, it can be easily elimi-
nated by removing the cotter pin on the chassis spin-
dle immediately above the tire and then tighten the
slotted nut until it appears a little on the tight side.
•
If caster ever locks up and will not swivel, remove the
castle nut, drop the caster from the spindle, clean out
any road debris, lubricate spindle with a light ap-
plication of axel grease, and then secure the caster
onto the spindle using the castle nut and cotter pin.
Consumer Information
CALL or write with any comments or questions about our
products or service.
Monday-Friday 8:00 a.m.—6:00 p.m. Eastern Time.
Consumer Relations, Smart Trailers, Inc,
536 S. Combee Rd.
Lakeland, FL 33801 USA
1 (863) 644-6060
12
SMART TRAILERS
A Division of Iron Men Industries, Inc
Owner's Manual
For Smart Trailers: Model 200
Warning! Read and understand the contents of
this manual for safe use of your Smart Trailer.
Use caution when using your Smart Trailer!
© May, 12, 2005
Updated April, 2016
Advertisement
Summary of Contents for Smart Trailers 200
- Page 1 • Maintain recommended tire air pressure at all times. • For Smart Trailers: Model 200 Check the casters for proper adjustment to minimize any unwanted motion in the caster. If unwanted mo- tion occurs with the caster, it can be easily elimi-...
- Page 2 Table of Contents Things ALWAYS to Do! • Always maintain recommended tire air Receiving Your Trailer pressure. Steps to follow • Always secure safety chains. Hitching Trailer to Vehicle • Always tightly secure the load onto the How to attach hitch adapter trailer and check frequently.
- Page 3 • Do not exceed the recommended tongue Because Smart Trailers are unique in design, we take weight for your trailer hitch. every precaution in making sure it is properly • Do not make short, sharp turns to right prepared for shipping.
- Page 4 Receiving Your Trailer—continued Hitching Trailer to Vehicle continued 7. Always make sure that when the hitch couplers are latched onto the coupler balls that there is no 12-15 inches long (total of six pieces) and place loose play in the connection. Use locking pins. near each end of trailer.
- Page 5 Hitching Trailer to Vehicle continued Receiving Your Trailer—continued 6. Remove cotter pin, castle nut, and one white UHMW washer from spindle on front of trailer. Place 2-point hitch on spindle and put UHMW washer on shoulder of spindle. Place castle nut on snuggly, insert cotter pin, and spread the ends.
- Page 6 III or heavier receiver hitch. Some fifth-wheel over the eye-bolt and slightly tighten nut on trailers may be suitable for our Model SL-200 if the bottom of eye-bolt. This takes the stress off of underneath frame work is heavy enough. It would the receiver when backing up.
