  • Page 1 Dear VIZIO Customer, For assistance 888-VIZIOCE (888-849-4623). Manufactured under license from Dolby Laboratories. HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
  • Page 2 Read the following safety instructions before operating the display. Keep these instructions in a safe place for future reference. three-pronged grounded plug, a plug with a third (grounding) pin. Do not defeat the safety purpose of the grounded plug. www.VIZIO.com...
  • Page 3 Your VIZIO TV comes with a built-in tuner capable of processing digital broadcasts, making it easier for you, the end user, to receive this type of signal without the need of an extra converter box.
  • Page 4 Opening the Package Package Contents IMPOTANT: Do not apply pressure or throw any object into the screen display area which may compromise the integrity of the display. The manufacturer’s warranty does not cover user abuse or improper installations. www.VIZIO.com...
  • Page 5 Additional Certified Accessories for the VIZIO VW46L FHDTV20A are sold separately www.VIZIO.com Attaching the Safety Strap www.VIZIO.com...
  • Page 6 Preparing Your LCD HDTV for Wall Mounting To remove the stand base Note: www.VIZIO.com...
  • Page 7 Table of Contents Chapter 1 Basic Controls and Connections ..............9 Chapter 2 Connecting Equipment .................. 13 Chapter 3 Setting Up to Watch Television ..............27 Chapter 4 Advanced Adjustment of HDTV ..............35 www.VIZIO.com...
  • Page 8 Chapter 5 Maintenance and Troubleshooting ............. 64 Chapter 6 Miscellaneous Information ................68 www.VIZIO.com...

  • Page 9: Chapter 1 Basic Controls And Connections

    Chapter 1 Basic Controls and Connections 1.1 Front Panel Power ‘VIZIO’ light Remote Control Sensor 1.2 Right Side Panel Controls POWER ( MENU CHANNEL +/- VOLUME +/- INPUT (ENTER) www.VIZIO.com...
  • Page 10 HDMI 1 HDMI 2 HDMI 3 RGB PC COMPONENT 1 (YPb/CbPr/Cr with Audio L/R) COMPONENT 2 (YPb/CbPr/Cr with Audio L/R) AV/S-VIDEO IN DTV/TV OPTICAL AUDIO OUT ANALOG AUDIO OUT AC IN www.VIZIO.com...
  • Page 11 1.4 VIZIO Remote Control GUIDE POWER HDMI MUTE COMPONENT LAST MENU NUMBER BUTTON PAD INPUT - (DASH) www.VIZIO.com...
  • Page 12 1.4.1 Insertion of Batteries in the Remote Control 1.4.2 Remote Control Range 1.4.3 VIZIO Remote Control Precautions www.VIZIO.com...

  • Page 13: Chapter 2 Connecting Equipment

    Chapter 2 Connecting Equipment 2.1 Which Video Connection Should I Use? www.VIZIO.com...
  • Page 14 2.2 Connecting Coaxial (RF) 2.2.1 Using Your Antenna or Digital Cable for DTV /TV 2.2.2 Using the Antenna or Cable through your VCR www.VIZIO.com...
  • Page 15 2.3 Connecting Your HDTV Set-Top Box 2.3.1 Using HDMI Connecting your HDTV Set-Top Box (Best): www.VIZIO.com...
  • Page 16 For HDTV Set-Top Boxes with DVI: www.VIZIO.com...
  • Page 17 2.3.2 Using Component Video Connecting your HDTV Set-Top Box (Better): www.VIZIO.com...
  • Page 18 2.4 Connecting Your Basic Set-Top Box 2.4.1 Using Composite Video 2.4.2 Using Coax (RF) www.VIZIO.com...
  • Page 19 2.5 Connecting Your DVD Player 2.5.1 Using HDMI Connecting your DVD Player (Best): www.VIZIO.com...
  • Page 20 For DVD Players with DVI: www.VIZIO.com...
  • Page 21 2.5.2 Using Component Video Connecting your DVD Player (Better) www.VIZIO.com...
  • Page 22 2.5.2 Using S-Video (AV) Connecting your DVD Player (Good): 2.5.3 Using Composite (AV) Video Connecting your DVD Player (Good): www.VIZIO.com...
  • Page 23 2.6 Connecting Your VCR or Video Camera www.VIZIO.com...
  • Page 24 2.7 Connecting an external Receiver/Amp LAST 2.7.1 Optical Output Audio received with Programs www.VIZIO.com...
  • Page 25 2.8 Connecting a PC Computer www.VIZIO.com...
  • Page 26 2.8.1 Preset PC Resolutions 2.8.2 Resolution (1920x1080) through RGB (15-Pin VGA) Input www.VIZIO.com...

  • Page 27: Chapter 3 Setting Up To Watch Television

    Chapter 3 Setting Up to Watch Television 3.1 Basic LCD HDTV Start Up 1. Connecting the Power Cable 2. Connect Audio and Video Cables to the HDTV 3. Turning Power On 4. Initial Setup www.VIZIO.com...
  • Page 28 Note: LAST www.VIZIO.com...
  • Page 29 Note: www.VIZIO.com...
  • Page 30 5. Select Input Source Note: www.VIZIO.com...
  • Page 31 TV sets. Some examples of these channels are: 105, 106, 115 and 116. 6. Fine Tuning your TV set for Home Use MENU LAST LAST www.VIZIO.com...
  • Page 32 Note MENU LAST www.VIZIO.com...
  • Page 33 3.2 Watching a TV Program www.VIZIO.com...
  • Page 34 3.3 Adjusting Basic HDTV Settings Volume TV Channels Wide MENU 3.4 Program Information www.VIZIO.com...

  • Page 35: Chapter 4 Advanced Adjustment Of Hdtv

    Chapter 4 Advanced Adjustment of HDTV 4.1 Using the On Screen Display (OSD) MENU VOL+ VOL– LAST LAST www.VIZIO.com...
  • Page 36 4.2 DTV / TV Input Picture Adjustment 4.2.1 Picture Mode MENU LAST www.VIZIO.com...
  • Page 37 4.2.2 Backlight LAST Reminder: 4.2.3 Brightness LAST www.VIZIO.com...
  • Page 38 4.2.4 Contrast LAST 4.2.5 Color LAST 4.2.6 Tint LAST www.VIZIO.com...
  • Page 39 4.2.7 Sharpness LAST 4.2.8 Color Temperature LAST www.VIZIO.com...
  • Page 40 4.2.9 Advanced Video LAST Black Level Extender LAST White Peak Limiter LAST www.VIZIO.com...
  • Page 41 LAST Flesh Tone LAST Adaptive Luma LAST Dynamic Contrast Ratio (DCR) LAST www.VIZIO.com...
  • Page 42 4.3 DTV / TV Input Audio Adjustment 4.3.1 Volume MENU LAST 4.3.2 Bass LAST www.VIZIO.com...
  • Page 43 4.3.3 Treble LAST 4.3.4 Balance LAST 4.3.5 Surround LAST www.VIZIO.com...
  • Page 44 4.3.6 Digital Audio Out LAST 4.3.7 Speakers 4.3.8 Lip Sync MENU LAST www.VIZIO.com...
  • Page 45 4.4 DTV / TV Tuner Setup LAST 4.4.1 Tuner Mode MENU LAST 4.4.2 Auto Search LAST 4.4.3 Skip Channel MENU LAST www.VIZIO.com...
  • Page 46 4.4.4 MTS LAST 4.4.5 Time Zone LAST 4.4.6 Daylight Saving LAST www.VIZIO.com...
  • Page 47 4.5 DTV / TV Input Setup 4.5.1 Language MENU LAST 4.5.2 Sleep Timer LAST 4.5.3 Wide LAST www.VIZIO.com...
  • Page 48 4.5.4 Input Naming MENU MENU LAST LAST LAST www.VIZIO.com...
  • Page 49 4.5.5 Closed Caption (CC) LAST 4.5.6 Digital Closed Caption Style (Digital CC Style) Font Size Font Color Font Opacity Background Color Background Opacity Window Color Window Opacity LAST 4.5.7 H/V Position Note: This feature is available when viewing digital TV. www.VIZIO.com...
  • Page 50 H- Position LAST V- Position LAST H-SIZE LAST V-SIZE LAST 4.5.8 System Reset LAST Note: Neither Setup Wizard nor Reset All Setting will reset the Parental Control password. www.VIZIO.com...
  • Page 51 4.6 DTV / TV Input Parental Control MENU 4.6.1 Channel Block MENU LAST www.VIZIO.com...
  • Page 52 4.6.2 US TV Rating MENU www.VIZIO.com...
  • Page 53 4.6.3 US Movie Rating MENU 4.6.4 Canadian English Rating MENU www.VIZIO.com...
  • Page 54 4.6.5 Canadian French Rating MENU 4.6.6 DTV Rating DTV Rating LAST www.VIZIO.com...
  • Page 55 4.6.7 Block Unrated Programming LAST 4.6.8 Change the Password LAST www.VIZIO.com...
  • Page 56 4.7 HDMI Input Picture Adjustment LAST 4.8 HDMI Input Audio Adjustment LAST 4.9 HDMI Input Setup LAST www.VIZIO.com...
  • Page 57 4.10 Video Input Picture Adjustment 4.11 Video Input Audio Adjustment www.VIZIO.com...
  • Page 58 4.12 Video Input Setup 4.13 Video Input Parental Control www.VIZIO.com...
  • Page 59 4.14 PC Input Picture Adjustment 4.14.1 Auto Adjust MENU LAST 4.14.2 Backlight LAST www.VIZIO.com...
  • Page 60 4.14.3 Brightness LAST 4.14.4 Contrast LAST www.VIZIO.com...
  • Page 61 4.14.5 Color Temperature LAST LAST LAST 4.14.6 H-SIZE LAST 4.14.7 H-Position LAST www.VIZIO.com...
  • Page 62 4.14.8 V-Position LAST 4.14.9 Fine Tune LAST 4.15 PC Input Audio Adjustment 4.16 PC Input Setup www.VIZIO.com...
  • Page 63 4.17 Understanding Viewing Features 4.17.1 Viewing Modes Normal Mode Wide Mode Stretch Mode Panoramic Mode www.VIZIO.com...
  • Page 64 4.17.2 Using a Cable or Satellite Remote Note Chapter 5 and Troubleshooting Maintenance 5.1 Maintenance Important Cleaning the Housing and Remote Control Cleaning the Screen www.VIZIO.com...
  • Page 65 5.2 Troubleshooting Guide www.VIZIO.com...
  • Page 66 5.3 Telephone & Technical Support VIZIO www.VIZIO.com www.VIZIO.com...
  • Page 67 5.4 Compliance 5.5 FCC Class B Radio Interference Statement www.VIZIO.com...
  • Page 68 Chapter 6 Miscellaneous Information 6.1 Specifications www.VIZIO.com...
  • Page 69 Digital TV (DTV): Enhanced Definition TV (EDTV): HDTV Monitor (sometimes called HDTV Ready): HDTV Tuner (also decoder, receiver, set-top box): High-Definition Television (HDTV): Integrated HDTV: Interlace Scan: Plug-and-Play or Digital Cable Ready: Progressive Scan: Standard Definition TV (SDTV): Note www.VIZIO.com...
  • Page 70 DNR (Dynamic Noise Reduction, 40 Connecting your HDTV Set-Top Box, 16 Flesh Tone, 41 White Peak Limiter, 40 Glossary, 70 Cleaning your VIZIO TV, 65 Coax (RF) Connecting for DTV, 14 HDMI Connecting your Basic Set Top Box, 18 Connecting your DVD Player, 19...
  • Page 71 Range, 12 Auto Search, 45 Remote Control Skip Channel, 45 Using your Cable or Satellite Remote to Operate your Tuner Mode, 45 VIZIO TV, 64 Connecting your PC, 25 Video Input Audio Adjustment, 57 Auto Phase, 58 Screen Size explanation, 63...
  • Page 72 Parts Repairs may be made with new or recertified parts, or the entire unit may be replaced with a new or recertified unit, at VIZIO’s option and sole discretion. Replacement parts or replacement units provided under this limited warranty are warranted for the remaining portion of the original warranty period, or for ninety (90) days from warranty service or replacement, whichever is later.
  • Page 73 This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This is the only warranty applicable; no one is authorized to extend or modify it or to grant any other warranty on VIZIO’s behalf.
  • Page 74 Return authorization numbers are valid for only fifteen (15) days from issuance. The customer is responsible for and must prepay all shipping charges and shall assume all risk of loss or damage to the product while in transit to VIZIO. If the product is returned to VIZIO (i) without a VIZIO return authorization number, and/or (ii) beyond the fifteen (15) day period, and/or (iii) without proper packaging, VIZIO retains the right to refuse delivery of such return or may return the unit to the customer at the customer’s...
  • Page 75 VIZIO, must be utilized. The cost of shipping to VIZIO’s service center is at the customer's expense. After the product is repaired and tested, the VIZIO service center will ship the unit back to the customer at VIZIO’s expense.
