Summary of Contents for Tunebug T100
- Page 2 Tunebug Shake at a Glance Touch Sensitive Control Area Indicator LED Touch Sensitive Control Area Shake Jack Shake Mounting Bracket Tunebug Shake Included Accessories Gecko Mount Tunestrap Audio Cable Charging Cable...
-
Page 3: Turning On/Off
Turning On/Off Check out our video guide www.tunebug.com On | Place two fingers over touch sensitive control areas for 3 seconds Indicator LED will flash green, then turn blue Off | Place two fingers over touch sensitive control areas for 3 seconds... -
Page 4: Volume Adjust
Volume Adjust Volume Up | Hold finger over right control button until desired volume is reached Volume Down | Hold finger over left control button until desired volume is reached Volume Down Volume Up... - Page 5 Connecting with Audio Cable Plug one end of Audio Cable into the Shake Jack Plug other end into the headphone jack of audio source (MP3 player, iPod, iPhone, portable CD player)
-
Page 6: Connecting Wirelessly
Connecting Wirelessly With Shake in off state, place two fingers over control button areas for 4 seconds to enable Bluetooth ® pairing mode Indicator LED will flash blue and red when Shake enters pairing mode... -
Page 7: Pairing Devices
Pairing Devices When your Bluetooth-enabled audio device recognizes the Shake, accept the connection and enter the passkey “0000” If the Shake is not auto-recognized, make sure Bluetooth is enabled on the audio device and accept Shake when recognized to complete the connection... - Page 8 Connection Complete Once you have made a connection to the audio device, the Shake’s indicator LED will flash blue, signal- ing that it is now paired Music from the audio device may now be played through the Shake...
- Page 9 Using Gecko Mount 1 Attach straps by hooking them over tabs on Mount (Figure 1) 2 Peel backings from three Dual Lock discs and attach one to bottom of each pad, pressing firmly (Figure 2) Let stand 30 minutes for adhesive Figure 1 to cure 3 Attach three more discs as shown,...
- Page 10 Attach Shake to Gecko Mount Place Shake into Gecko mount as shown, aligning the 3 tabs of the Shake Mounting Bracket into the slots of the mount Slide latch at bottom of mount to lock the Shake in place Slide Latch to Lock...
- Page 11 Attach Gecko Mount to Helmet Attach Gecko Mount as shown For best results, make sure helmet is clean and smooth and bottom of Shake comes in full contact with surface Let stand for 5 minutes for adhesive to cure Play audio through the Shake and if needed, adjust tension on straps by repositioning Dual Lock discs to improve sound quality...
- Page 12 Using the Tunestrap Stretch open and slide Shake into Tunestrap sleeve as shown Make sure Shake Jack aligns with hole in sleeve Tunestrap Sleeve Shake Jack...
- Page 13 Attach Tunestrap to Helmet Feed Velcro strap through vents in helmet Feed ends of Velcro strap through plastic loops on Tunestrap and fold over to attach to itself Tighten Velcro strap as needed to prevent Tunestrap from sliding around Adjusting the strap tension will also help improve the Shake audio...
- Page 14 Charging Plug mini-phono connector of Charg- ing Cable into the Shake Jack Plug USB connector into any device’s powered USB port For faster charging, turn Shake off and use a USB wall charger (not included)
-
Page 15: Charge Indicators
Charge Indicators When Shake is On… Above 20% battery charge Less than 20% battery charge When Shake is Off & Charging… Charging Fully charged (no LED) Blue LED Indicates At Least 20% Red LED Indicates Low Charge Charge Remaining Warning or Charging... -
Page 16: Limited Warranty
© 2010 Silicon Valley Global LLC. All rights reserved. and SurfaceSound are trade- marks of New Transducers Limited. The Bluetooth word mark and logos are registered trade- ® marks owned by Bluetooth SIG, Inc. and any use of such marks by Tunebug is under license.
