  • Page 1 Q U I C K G U I D E...
  • Page 2 VÄLKOMMEN! This Quick Guide describes a selection of the features and functions in your Volvo. More detailed information is available in the vehicle's center display, in an app and on the Internet. THE CENTER DISPLAY The owner's manual is available in the center display's Top view.
  • Page 3 CONTENT 01. GETTING TO KNOW YOUR VOLVO This section provides overviews of your Volvo's interior, exterior and the center display. 02. INTERIOR AND CONNECTIONS This section provides information about features and functions in the passenger compartment. 03. CENTER DISPLAY VIEWS This section contains information about the center display's main views, which control many vehicle functions.
  • Page 5 . These services include Volvo On Call, map services and the opportunity to book service and repairs. A Volvo ID can be cre- ated using the Volvo On Call app or can be done directly in your vehicle. Sensus Sensus is your vehicle's intelligent interface and includes all of its solu- tions relating to entertainment, connecting to the Internet, navigation and the user interface between the driver and the vehicle.
  • Page 7 EXTERIOR OVERVIEW Checking the engine oil level and tire pressure is done from the height, open the tailgate manually to the desired position and app in the center display's App view. You can also press for at least 3 seconds to store this position. Car status view any status-related messages and book service and repairs here.
  • Page 9 LOCKING AND UNLOCKING THE VEHICLE Remote key Press to lock the doors/tailgate and arm the alarm. Press to unlock the doors/tailgate and disarm the alarm. Press briefly to unlock the tailgate only (and disarm the alarm for the tailgate). On vehicles equipped with the power tailgate*, press and hold to open/close the tailgate.
  • Page 11 INTERIOR OVERVIEW The center display is used to control many of the vehicle's main and deselecting . Select gear Parking Brake and Suspension functions, such as the climate system, driver support systems and N and turn the start knob clockwise as far as possible and hold it in apps.
  • Page 13 CENTER DISPLAY Many of the vehicle's settings and functions are controlled from the center display, which has 3 main views: Home view, Function view (from Home view, swipe the screen from left to right) and App view (from Home view, swipe the screen from right to left). The center dis- play also has a Top view, which is accessed by swiping from the top of the screen downward.
  • Page 14 2. Select the desired function in the center display by turning the con- trol. 3. Change the desired settings by pressing the upper/lower/front/rear sections of the control. Some of the settings can also be made by tapping the respective buttons in the center display. Storing seat settings 1.
  • Page 15 FOLDING THE REAR SEAT BACKRESTS It may be necessary to move the front/second row seats in order to fold down the second row backrests completely. Second row of seats, center position 1. Press down the head restraint manually by pressing the button located between the head restraint and the seat's backrest.
  • Page 16 STEERING WHEEL The steering wheel's height and reach can be adjusted. Push the lever Adaptive cruise control*: helps maintain a set speed and/or a set under the steering wheel downward/forward to release the steering time interval to a vehicle ahead. wheel.
  • Page 17 Right-side steering wheel keypad The right-side keypad controls the instrument panel. Open/close the app menu. From here, you can control the trip computer, media player, a connected cell phone and the naviga- tion system. Press the left/right arrows to scroll among the available apps. Select/deselect or confirm a choice, e.g., select the trip comput- er's menu or erase a message from the instrument panel.
  • Page 18 Home safe lighting switches on the headlights, parking lights and door handle lights* to illuminate the area in front of the vehicle in dark conditions. To activate this function, switch off the ignition and push the lever toward the dashboard as far as possible and release it. After a period of time, the lights will switch off automatically.
  • Page 19 RIGHT-SIDE STEERING WHEEL LEVER The right-side steering wheel lever is used to control the vehicle's wip- ers/washers and the rain sensor*. – Move the lever down and release it for a single sweep. – Move the lever upward in steps for interval/normal speed/high speed wipers.
  • Page 21 PASSENGER COMPARTMENT CLIMATE Climate system settings Climate system functions for the front and rear sections of the passen- ger compartment are controlled from the center display, using buttons on the center console and the climate panel on the rear side of the tun- nel console*.
  • Page 22 Vehicle modem Internet smartphone. In order to connect your devices to the vehicle, the ignition When the modem is used to make the connection, the Volvo On Call must be in at least mode I. services will use this connection.
  • Page 23 These sockets can be used to connect external devices to e.g., play media. The USB sockets can also be used for Apple CarPlay/Android When connecting using the vehicle's modem, Volvo On Call services will use this connection.
  • Page 24 USING CONNECTED DEVICES When an external device such as a cell phone or media player is con- nected to the vehicle, you can e.g., handle phone calls and listen to media through the vehicle's infotainment system. Handling calls You can make and receive calls in the vehicle from a Bluetooth-con- nected cell phone.
  • Page 25 USB-connected device 1. With the device connected to a USB port, start the app in the center display's App view. 2. Select a song, etc., and playback will begin. Mp3 player or an iPod 1. Start playback in the connected device. 2.
  • Page 27 HOME VIEW The center display starts up in Home view, which has sub-views for Navigation, Media, Phone and recently used vehicle functions. Navigation: tap to go to the Sensus Navigation system. Set a destination by entering text: Tap to display a screen where text can be entered.
  • Page 29 FUNCTION VIEW AND APP VIEW Function view 2. Drag it to the desired position and release it. In Home view, sweep the screen from left to right to access Function view. From here, you can activate/deactivate various vehicle functions * and *.
  • Page 31 TOP VIEW Tap (or pull down) the tab at the top of the screen to open Top view. This provides access to and the Settings Owner's manual Profile vehicle’s stored messages. Personal settings Many personal settings, such as changing the center display's appear- ance and the information that is shown there, mirrors, the driver's seat, navigation, etc., can be changed under Settings.
  • Page 33 DRIVER SUPPORT A number of standard and optional driver support functions are availa- Pilot Assist is activated/deactivated using the buttons on the left-side ble in your vehicle to help make driving safer and are designed to help steering wheel keypad. In order to provide steering assistance, the driv- avoid accidents or mitigate their effects.
  • Page 35 PARKING ASSISTANCE SYSTEMS Park Assist Pilot (PAP)* – Tap the icon in the center display's Function view to acti- Camera vate/deactivate the camera. PAP assists in parking or leaving a parking space by e.g., scanning a potential parking space and thereafter controlling the steering wheel to guide the vehicle into the space.
  • Page 37 ECONOMICAL DRIVING PLEASURE Planning your trips and driving economically can help reduce fuel con- sumption, emissions, operating expenses and environmental impact. Plan your drives by always: Planning your route to avoid unnecessary stops and frequent • changes in speed, which are factors that contribute to increased fuel consumption Drive economically by: Activating the...
  • Page 38 • Recent calls • Read message • Message to [contact] Radio and media voice commands Media • • Play [artist] Play [song title] • • Play [song title] from [album] Play [radio station] • • Tune to [frequency] • Tune to [frequency] [waveband] •...
  • Page 39 • Set fan to max Turn off fan • Clear itinerary • Raise fan speed Lower fan speed • Repeat voice guidance • Turn on auto • Turn off voice guidance • Air condition on Air condition off • Turn on voice guidance •...
  • Page 40 Volvo On Call only functions in areas where • The full weight of the front seat passenger •...
  • Page 41 • USING CONNECTED DEVICES activated, the information in the head-up display Please be aware that Volvo has no control over the will be replaced by a graphic relating to the content of the Apple CarPlay/Android Auto apps. respective systems. This graphic will illuminate even if the head-up display is turned off.
  • Page 42 TP 24149 (English - USA & Canada), AT 1717, MY18, Copyright © 2000-2017 Volvo Car Corporation...
