Video • Data • Power
Passive UTP Transceiver Hub
with Integral Isolated Camera Power
Installation Guide
Models Include:
HubSat8DiV
- Eight (8) Channel Passive UTP Transceiver Hub with Integral Isolated Camera Power
HubSat82DiV
- Eight (8) Channel Passive UTP Transceiver includes eight (8) HubWayAv
Video Balun/Combiners
HubSat83DiV
- Eight (8) Channel Passive UTP Transceiver includes eight (8) HubWayDv
Video Balun/Combiners
Rev. 041212
More than just power.
TM
Advertisement
Table of Contents
Summary of Contents for Hubsat HubSat8DiV
- Page 1 Passive UTP Transceiver Hub with Integral Isolated Camera Power Installation Guide Models Include: HubSat8DiV - Eight (8) Channel Passive UTP Transceiver Hub with Integral Isolated Camera Power HubSat82DiV - Eight (8) Channel Passive UTP Transceiver includes eight (8) HubWayAv Video Balun/Combiners...
- Page 2 (Fig. 4, pg. 6). 4. S elect 24VAC or 28VAC power output for each of the Channels 1-4 on HubSat Circuit Board A and HubSat Circuit Board B (Fig. 4, pg. 6) with the corresponding output voltage switches. Select OFF position when servicing or installing individual cameras (Fig.
- Page 3 8. Set illuminated master power disconnect circuit breaker to the RESET (ON) position (Fig. 4a, pg. 6) power LEDs (Green) of the HubSat8DiV will illuminate when AC power is present (Fig. 1e, pg. 4) and HubWayAv or HubWayDv Video Balun/Combiner LEDs will illuminate indicating power is present (Fig. 2b, 2d, pg. 6).
- Page 4 9. Set illuminated master power disconnect circuit breaker to the RESET (ON) position (Fig. 4a, pg. 6). 10. The power LEDs (Green) of the HubSat8DiV will illuminate when AC power is present (Fig. 1e, pg. 4). Note: If any of the power LEDs are not illuminated the cause may be due to the following: a.
- Page 5 Altronix from HubWay Model Number Unit Output Voltage to Camera Camera Type Power LED HubWayAv *24VAC/28VAC *24VAC/28VAC *24VAC/28VAC Green HubWayAv2 *24VAC/28VAC *24VAC/28VAC *24VAC/28VAC HubWayDv *24VAC/28VAC 12VDC 12VDC cameras *Based on camera load and structured cable length. HubSat8DiV - 5 -...
- Page 6 Structured Connector Connector Cable from AC Power Cable from 12VDC Power of Camera of Camera HubSat8DiV to Camera HubSat8DiV to Camera Data to Data to Camera Camera HubWayAv/HubWayAv2 passes AC voltage through pins HubWayDv converts AC voltage to DC voltage through 4, 5, 7, 8 and [AC Power] terminals.
- Page 7 Typical Application Drawing HubSat8DiV Passive UTP Transceiver Hub with Integral Camera Power: Fig. 5 Head End Equipment (DVR) Monitor RS485 Data Video Data Power CAT-5 Data Video HubWayA Power CAT-5 Video Balun Combiner 24VAC PTZ HubWayD Camera Video Balun Combiner...
- Page 8 10.5” 1.0” (25mm) (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 website: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. IIHubSat8DiV L01P MEMBER - 8 - HubSat8DiV...
