- Page 1 ET series hardware manual www.epordo.com Make Things Simple Manual Model: ET series ET007V ET008V ET 009V ET80 ET90 MSN: barry588o@hotmail.com / efocus003@hotmail.com E-mail: barry@securiticn.com / sophia@securiticn.com Tel: +86 755 8341 8779/ 8825 7909...
- Page 2 ET series hardware manual www.epordo.com E-Focus Industrial Leading Manufacturer on Biometrics & Smart Card Devices/Solutions We, E‐FOCUS, are Efficient, Creative, Organized, Reliable and Excellent for your choice. Since1999, E‐Focus are leader in the development of fingerprint applications, comprising R&D, design and manufacture. We have been offering core fingerprint algorithm technology and mature embedded application products.
- Page 3 ET series hardware manual www.epordo.com role in biometrics appliances. 2002: Spread core technology to Security and Information Technology field, started to make Door Lock, Payment System etc. obtained good shares of market 2004: Started to utilize telecom tech, launched door phone, cell phone jammer, GPS jammer etc into market, and offered OEM/ODM products in a big scale for international market.
- Page 4 ET series hardware manual www.epordo.com function and master basic knowledge about installation, using, maintenance and management of the terminal. Brief Introduction In comparison with traditional locks, fingerprint lock is provided with more conspicuous advantages for its application. The exclusiveness and portability of "fingerprint key" improves user's requirement on safety and convenience greatly. The unique physiological attribute of fingerprint eliminates the hidden troubles of missing or burglary fundamentally.
-
Page 5: Table Of Contents
E-Focus lives up to any responsibilities. Without the authorization about the manual copyright of E-Focus Industrial Co., Limited, the manufacturers involved prohibit the modification and printing brochures. http://www.epordo.com/ for more product information of E-Focus: CONTENTS Chapter 1 Using Notice…………………………………………………………………………………………………………………………7 1.1 Note…………………………………………………………………………………………………………………………………………….7... - Page 6 ET series hardware manual www.epordo.com 2.6 Original Interface…………………………………………………………………………………………………………………………..17 Chapter 3 Process Of Check-In And Verification………………………………………………………………………………………..17 3.1 Register New Users……………………………………………………………………………………………………………………….17 3.2 Backup For The Registrations………………………………………………………………………………………………….…….…26 3.3 Verification………………………………………………………………………………………………………………………………….27 3.4 Hints For Successful Registration………………………………………………………………………………………………………28 3.5 Delete Users……………………………………………………………………………………………………………………...…………31 3.6 Security Level Set………………………………………………………………………………………………………………………….32 Chapter 4 Data Communication…………………………………………………………………………………………………………..…33 Chapter 5 Time Setting………………………………………………………………………………………………………………………..38...
-
Page 7: Chapter 1 Using Notice
ET series hardware manual www.epordo.com Chapter 1 Using Notice 1.1 Note * Please don’t install it in large temperature difference environment. Please install in the room where the temperature is appropriate. * Please don’t install it in dirty and moist places. - Page 8 ET series hardware manual www.epordo.com * Please don’t use sharp objects or weights crushing to blow equipment. Otherwise it may lead to equipment, fingerprint identification and exterior damaged, which will impact the use and appearance. * Please keep equipment away from dust, water and fire.
- Page 9 ET series hardware manual www.epordo.com * Please keep equipment steady. Otherwise it may lead to internal or mobile equipment damage. * Please do not repair privately if equipment fails. If you are in need of repairing equipment, please contact the equipment providers.
-
Page 10: The Way Of Pressing A Fingerprint
ET series hardware manual www.epordo.com * It is better to manage device by two or more admin. It is useful to facilitate the coordination of the work of various departments and the transition of related technical parameters. * Equipment administrators need to study the methods of operation seriously. -
Page 11: The Feature And Parameter Of The Device
ET series hardware manual www.epordo.com A few incorrect ways of pressing: Notice: Please use the correct method to press. Our company does not bear the result of reducing identifying ability due to the inappropriate operation of the users. Our company retains the right to explain and modify this. - Page 12 ET series hardware manual www.epordo.com ● Built in embedded standalone module with high performance SAMSUNG 32 bit X-scale CPU, big capacity FLASH and CMOS chips, it is easy to integrate with various systems. ● Alarm clock function for giving the correct time on time. (Optional) ●...
-
Page 13: Keyboard
ET series hardware manual www.epordo.com Language English, Japanese, Spanish, Franch, Deutsch, Portugues, Espanol, Pyccknn Working mode Time & attendance, standalone, can working persistently Save function Turn off device automatically for saving Time & Attendance mode Fingerprint, password, fingerprint +password, card(optional),fingerprint + card... -
Page 14: Chapter 2 Fundamental Concepts Introduction
ET series hardware manual www.epordo.com Keyboard Function: Exit or cancel an operation MENU Enter into machine menu Confirm an operation ⊙ Switch on or off machine ▲ Shift up the menu ▼ Shift down the menu Input numerical values Chapter 2 Fundamental Concepts Introduction This part includes the definition and description of the fundamental concepts. -
Page 15: Registration Of Users
ET series hardware manual www.epordo.com 2.1 Registration of users There are two kinds of users, including administrators common users: Administrators: Those who are authorized to operate all the procedures on the terminal, browse the deleted or recorded data, browse the system information and set up functions and environment. -
Page 16: Verification Of User
ET series hardware manual www.epordo.com 2.2 Verification of user When the user presses the fingerprint on the collecting device or types in an ID number and then types in the password or the fingerprint, this process is called verification. The system will send the information on whether the verification is successful or not. -
Page 17: Limitation Level
ET series hardware manual www.epordo.com 2.5 Limitation level There are 2 limitation levels for the ET series attendance recording device. Users: they are the people required to verify identification for certain purposes, such as to open the door by using the device, or record their entering and exiting history. - Page 18 ET series hardware manual www.epordo.com register by using their fingerprint. The last group of people should be around 1% of the total number of users. Slight changes can be done according to the actual user groups. The different selection of terms will be entering different branches.
- Page 19 ET series hardware manual www.epordo.com It includes four options: User, Admin, Ver Mode, U-up load,as shown below: Notice: You can also choose “Admin” to register administrator. The step is the same with “User Enroll”, every manager also can register three different fingers, and every machine can register at least 1 admin and maximum 10.
- Page 20 ET series hardware manual www.epordo.com At this time, common user cannot enter into the main menu until the administrator has been identified successfully. Press “OK” button and display the interface as such: It includes two options: New Reg., Backup. Press “OK” button and display the interface as such: It includes five options: Finger, Password, ID Card, FP&Pass, FP&Card.
- Page 21 ET series hardware manual www.epordo.com I. fingerprint registration 1）Select the “Finger” and press ”OK” to enter the next step displaying the following information: 2）Enter the number you want to register in the “registration number” term. (The number is in between 1---99999999) press OK to confirm and type in the next step, showing the following information: ꎨ...
- Page 22 ET series hardware manual www.epordo.com Press “OK” to save the previous fingerprint registration to finish one registration process. If the registration successful, the system will instruct you to re-type. Return to step (2) to continue the registration. II. Password Registration (1) Select “Password...
- Page 23 ET series hardware manual www.epordo.com 3) Type in the number you want to register in the “registration number” term. (The number is in between 1---99999999) press OK to confirm and enter the next step, showing the following information: Notice: The length of the password is 1-8 digits.
- Page 24 ET series hardware manual www.epordo.com If the registration is unsuccessful, the system will instruct you to reinput. Return to step (1) to continue the registration. III. Finger and password 1) Select Fingerprint and password(Fp&Pass) and press “OK” to confirm and go to the next step with the following information displayed: 2) Press “OK”...
- Page 25 ET series hardware manual www.epordo.com 3) An interface will be displayed after the fingerprint is registered successfully for 3 times. Type in a number you want to register (between 1 and 99999999) and then the following information is presented: 4) Follow the instruction to type in your password and press OK to confirm. The following information is displayed: MSN: barry588o@hotmail.com / efocus003@hotmail.com...
-
Page 26: Backup For The Registrations
ET series hardware manual www.epordo.com 5) Re-type your password and press “OK” to confirm. Notice: 00000003-0P the second last digit of 1 represents a fingerprint and the last digit of P represents a password. 5) Another interface will be displayed after the registration is done successfully. The following information will be displayed: Press to save the registration data and finish one fingerprint and password registration process. -
Page 27: Verification
ET series hardware manual www.epordo.com The following steps are the same as the ones to the only different is new registration becomes a backup at the end Notice: It is good to keep at least 2 fingerprints registered for a long term user. - Page 28 ET series hardware manual www.epordo.com 3.3.2 Password verification: Type in your ID number at the original interface and the screen will display as such: Press “OK” to confirm and the screen will instruct you to enter password, and then the screen will display as such: MSN: barry588o@hotmail.com / efocus003@hotmail.com...
- Page 29 ET series hardware manual www.epordo.com Type in the right password and press to confirm. The screen will display as such: If the typed in password is incorrect, the system will hint that this is the wrong password and the screen will display as such: Notice: After admin registered, when you go back to the main interface, press the key “MENU“...
-
Page 30: Hints For Successful Registration
ET series hardware manual www.epordo.com At this time, common user cannot enter into the main menu until the administrator has been identified successfully. 3.4 Hints for successful registration If the fingerprint undergoing verification is of good quality, the speed of the identity verification will proceed quickly. If the fingerprint undergoing verification is of bad quality, the speed of the identity verification will proceed slowly, or misjudgment may occur. -
Page 31: Delete Users
ET series hardware manual www.epordo.com Position of pressing Make sure the finger is placed horizontally on the fingerprint collecting plate and cover as large an area as possible. Do not press the finger perpendicularly on the collecting plate. Do not click the plate with the finger quickly, nor sliding the finger across. -
Page 32: Security Level Set
ET series hardware manual www.epordo.com Input the ID number you want to delete, then press “OK” to confirm and delete the user’s information from the fingerprint device. 3.6 Security Level Set Choose “Register—Ver Mode", the screen will display as following: Press “OK”... -
Page 33: Chapter 4 Data Communication
ET series hardware manual www.epordo.com Security Level includes 1:1, 1:N. 1:1 means when verify, you must enter user’s ID number before pressing fingerprint, or inputting password, the machine itself will select the ID number for comparing between current status and the registered one. - Page 34 ET series hardware manual www.epordo.com Press “OK” and following information displays: It includes six options: Glog&Del, All Glog, Slog&Del, All Slog, Enr. Data, LoadData Select relative menu items to download until it shows: download！.The relative items and meanings are as follows: Glog: “Glog”...
- Page 35 ET series hardware manual www.epordo.com format of U-disk RS232 downloading : turned on, you can connect one end of the special cable which is offered by our company with fingerprint device, and the other end with your computer. Choose “RS232”, the screen will display as following: Notice: There are 9600, 19200, 38400, 57600, 115200 to choose as the Baudrate.
- Page 36 ET series hardware manual www.epordo.com Ethernet download: whether communicating by using TCP/IP protocol or not. ꎨ (1)IP Address: Type in the IP address that your computer is using to communicate with the fingerprint device at the IP address term. (1- 255) It cannot be the same as another computer’s IP or else an IP conflict will be caused.
- Page 37 ET series hardware manual www.epordo.com . Access Control System (This does not apply to ET80) Notice: To connect the machine a bit far (1.5 meters), or multi sets of machines, please use the RS485 communication method. And the distance by RS485 mode can be as far as 1200 meters.
-
Page 38: Chapter 5 Time Setting
ET series hardware manual www.epordo.com Chapter 5 Time setting Press “MENU” and select “Set time”, and the screen will display the following information: MSN: barry588o@hotmail.com / efocus003@hotmail.com E-mail: barry@securiticn.com / sophia@securiticn.com Tel: +86 755 8341 8779/ 8825 7909... -
Page 39: Chapter 6 Device Setting
ET series hardware manual www.epordo.com You can use the “OK “ button to alter between year, month, date, hour, minute and second. Then select the place you want to modify and press “OK” again. Save and exit the program when it is done. -
Page 40: Chapter 7 Record Setting
ET series hardware manual www.epordo.com 1. Machine ID: Device number is the sequence number for such device. You don’t need to change it if you only have one device. Otherwise you need to modify the number for different devices so that the software is not going to mess up. - Page 41 ET series hardware manual www.epordo.com Warnings for attendance recording: when the recording space left has reached a preset value, the device will automatically send the warning that the storage space is almost full ꆣ Reconfirm period: within the preset period of time (unit: minute), if someone’s attendance record already exists, then the second attendance record result will not be saved.
-
Page 42: Chapter 8 Door Locking Settings For Users
ET series hardware manual www.epordo.com Chapter 8 Door locking function settings 8.1、Access control function summary The door lock function setting is the time and right setting to unlock the door for the registered users. Settings for each user include 3 different time interval settings and a group setting. The relationship between time intervals is “or”. There are also 3 time intervals to be set within group settings. - Page 43 ET series hardware manual www.epordo.com MSN: barry588o@hotmail.com / efocus003@hotmail.com E-mail: barry@securiticn.com / sophia@securiticn.com Tel: +86 755 8341 8779/ 8825 7909...
-
Page 44: Access Control Function Explains In Detail
ET series hardware manual www.epordo.com 8.3 Access control function explains in detail Press “MENU” and select “Advanced－LockCtrl” , and then the screen will display the following information: Under this window, the following definitions about door locking function can be made: 8.3.1 The definition of the function of the time setting... - Page 45 ET series hardware manual www.epordo.com Press “OK” to enter the setups for time interval 1. The screen will display the following information: For example: The definition for the interval number 1 is: People are not allowed to get in on Saturday or Sunday. People can enter within the working periods from Monday to Friday and between 08:30-18:00.
- Page 46 ET series hardware manual www.epordo.com From then on, many time intervals can be defined accordingly. The system can define a maximum of 50 time intervals. 8.3.2 Lock Register You can enter the menu to check a particular user’s door locking settings. It includes: the setting for the user groups and the setting for time intervals.
- Page 47 ET series hardware manual www.epordo.com Press “OK” to confirm, then there is following information: For example: The setting for the user numbered 00000001 is belonging to the first user group; available at time interval 1, 40 and 48. The screen will display the following information: Press “OK”...
-
Page 48: Unlock Group
ET series hardware manual www.epordo.com 8.3.3 Time Group Setting Time group setting is to make different groups to combine and form different configurations to unlock the door. There are 5 groups defined by the system: group 1, group 2, group 3, group 4 and group 5. The default group is group1, and the user can change to another group. - Page 49 ET series hardware manual www.epordo.com that only the users in group 4 can unlock the door after verification is done. The system can define at most 10 unlock configurations and only one is needed to pass for unlocking. Enter “...
-
Page 50: Unlock Time
ET series hardware manual www.epordo.com From the setting above, it can be seen that: 1,2,3 are in a configuration 4 is in a configuration 2,4 are in a configuration 4,5 are in a configuration 1,5 are in a configuration a. When people from group 1, 2 and 3 have done the fingerprint verification successfully and the present time is within the effective time interval, the door can be unlocked. -
Page 51: Lock Type Setting
ET series hardware manual www.epordo.com 8.6 Lock Type Setting Select “Lock Type Set”, it includes 2 options: 1) Alarm Type: 3 different types in total: “NG” ,”NO” and “NC”. “NG” means the magnetic door switch is not in use.” NO” means that the door must be opening at the same time as unlocking, or the magnetic door alarm will be triggered when the time delay for the magnetic door has been exceeded. -
Page 52: Chapter 9 View Information
ET series hardware manual www.epordo.com Chapter 9 View Information Enter “MENU－ViewInfo” and the screen will display: 9.1 Storage detail Enter “Info View－Reg.Data” menu and the screen will display the following information: User registration (User Reg) is restoring the total number of the registered users. -
Page 53: Record Details
ET series hardware manual www.epordo.com Password registration (Password) is a way to record attendance according to card number and password. Induction card registration (ID Card) is only for the attendance record by employees using their cards when they start and finish working. - Page 54 ET series hardware manual www.epordo.com Type in the registration number you want to inquire. Press the “OK” button and you can examine the attendance record for this particular employer. If no number is typed in, it will be “00000000” and the attendance record for all the employers can be examined.
- Page 55 ET series hardware manual www.epordo.com Preview User Record(Preview URec) can roll the page up and down to view the attendance record for each person at different times. Delete all Records(Delete All Rec): that is to delete the information of all the users from the fingerprint machine. It is similar to the process of resetting to the primary status.
-
Page 56: System Detail
ET series hardware manual www.epordo.com 9.3 System detail Enter “ViewInfo－Product” menu. The screen will display the following information: 9.3.1 Select “manufacturer” and press “OK”, and the screen will display the following information: This shows the logo and website for our company. - Page 57 ET series hardware manual www.epordo.com 9.3.2 Device name: shows the name and the model of the device. 9.3.3 Release Time: 9.3.4 Serial Number MSN: barry588o@hotmail.com / efocus003@hotmail.com E-mail: barry@securiticn.com / sophia@securiticn.com Tel: +86 755 8341 8779/ 8825 7909...
- Page 58 ET series hardware manual www.epordo.com 9.3.5 Firmware Version 9.3.6 Software Version MSN: barry588o@hotmail.com / efocus003@hotmail.com E-mail: barry@securiticn.com / sophia@securiticn.com Tel: +86 755 8341 8779/ 8825 7909...
-
Page 59: Chapter 10 Maintenance
ET series hardware manual www.epordo.com Chapter 10 Maintenance 10.1 Cleaning Sometimes the optical lenses, the key board and the displaying screen need to be cleaned. For they are working in different external environment, we cannot give advice on an accurate period of time for cleaning, but the following guide may help you. -
Page 60: Chapter 11 Protocol For The Permission Of Software Usage
ET series hardware manual www.epordo.com 10. 3 Clean the optical lenses To clean the optical lenses, Please follow the advice below: 1) If they are filled with dust or sand, blow dry the dirty stuff on the lenses first. 2) Use the non-drying rubberized fabric to clean the displaying screen. - Page 61 ET series hardware manual www.epordo.com If the transformation has happened, the original file and its accompanying files must all be copied and transfer together. The copies not transferred must all be destroyed. 4. This system can only be used in multi user environment or the internet when one of the following conditions is fitted. The multi user environment or the internet are permitted by the system to use and proclaimed in writing.
-
Page 62: Chapter 12 Solutions For Frequently Asked Question
ET series hardware manual www.epordo.com suspend, or any forms of indirect, special, accidental or unavoidable damage, or claim indemnity from a third party, our company and its agents, salesmen do not have the responsibility, even if our company has been informed that these sorts of situations may happen previously. - Page 63 ET series hardware manual www.epordo.com Solutions: the reasons can be: a. The setting for the communication port is incorrect. The communication port selected to connect is not the actual COM port. b. The bit frequency of the computer’s communication port is different from the bit frequency set for the attendance recording device.
- Page 64 Solution: This situation can be related to the data cable or the converter or the COM port of the computer. You can reduce the bit frequency of the attendance recording device and the computer, for example changing to 19200 or 9600, then undergo loading. Welcome visit our website: http://www.epordo.com MSN: barry588o@hotmail.com / efocus003@hotmail.com E-mail: barry@securiticn.com / sophia@securiticn.com...
