EnGenius EDS1130 Quick Installation Manual

Package content
- Camera
- Camera stand
- Quick Start Guide
- 12V/1A Power adapter
- RJ-45 Ethernet cable
- CD
- QR Code label
- Wall mount screw set
Before getting started
Ensure that your gateway/router is already connected to the internet for
proceeding the camera setup.
For local network: PC-based wizard (EnViewer finder)
For remote netwerk: Mobile Viewer (EnViewer), EnGenius Cloud services (web)
Connecting the gateway/router
You can either set up the camera connectivity using an Ethernet cable (option 1)
or via Wi-Fi (option 2).
Option 1
A. Plug one end of the Ethernet cable into the LAN port of your gateway/router
and plug the other end of the cable into the Ethernet port of your camera.
B. Connect the power adapter to your camera and plug into a wall outlet.
C. Wait for power LED indicator stop flashing and become sold green. It may
take up to 90 seconds.
EnGenius Europe | Veldzigt 28, 3454 PW De Meern,
Netherlands | 0900-WIFIABC | www.wifiabc.com
EDS1130
Option 2
A. Connect the power adapter to your camera and plug into a wall outlet.
B. Wait for the power LED Indicator to stop flashing and become solid green. It
may take up to 90 seconds.
C. Press the WPS button on your gateway/router until WPS LED blinks.
Note: Please make sure your device is equipped with WPS button.
.
Disclaimer: Information may be subject to changes without prior notification.
