Ju-soft HQP-1072SD Hardware User's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

HQP-1072 Series System
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HQP-1072SD and is the answer not in the manual?

Questions and answers

Summary of Contents for Ju-soft HQP-1072SD

  • Page 1   HQP-1072 Series System User Guide...

  • Page 2: Table Of Contents

    HQP‐1072 System User Guide  Table of Contents   HQP-1072 Hardware User Guide ..............3 1. HQP-1072 system Introduction ..............4 Box Contents ................4 Specification................6 Appearance................8 2. Setting Up....................10 Connect Power Cord.............10 Connect Monitor/Keyboard/Mouse........10 Power On the System ............10 3. Installing the Server in a Rack..............12 Installing the Server into the Rack ........12 4.

  • Page 3: Hqp-1072 Hardware User Guide

    Please do not execute any other software which is not relevant. Some customers may install two or more applications on the same system, please confirm with retailers of Ju-Soft CO., LTD whether they can be simultaneously executed.

  • Page 4: Hqp-1072 System Introduction

    HQP‐1072 System User Guide  1. HQP-1072 system Introduction Box Contents Each HQP-1072 System has a complete burn-in test before delivery. Hard drives are preinstalled in the server；please check if they are present and undamaged once you open the package. 47CM 17CM 65CM Open the box and ensure the listed items are present. If not, please contact your retailer immediately.

  • Page 5: User Guide

    HQP‐1072 System User Guide   Motherboard driver disc  HQP-1072 System warranty document  User Guide Accessories US type power cord *1  EU type power cord *1  Layer 1：Cover Layer Power Cord Layer 2：  HQP‐1072 & Power Cord 5   ...

  • Page 6: Specification

    HQP‐1072 System User Guide  Specification Chassis 1U, 19" Rack-mount Dimension Height 1.7＂(43mm) Width 17.2＂(437mm) Depth 9.8＂(254mm) Weight 4.5kg Front Panel Buttons Power On/Off button System Reset button Power LED Hard drive activity LED 2 x Network activity LED System Overheat LED Motherboard Super X9SPV-LN4F-3QE Intel®...
  • Page 7 HQP‐1072 System User Guide  Chipset Intel® QM77 Chipset Networking 4 x RJ45 LAN ports 1 x RJ45 Dedicated IPMI LAN port Graphic Intel Integrated Graphics HD 4000 On-Board Input/Output 5 x RJ45 ports (include 1 Dedicated IPMI LAN port) 4 x USB 2.0 ports (4 x rear) 1 x VGA port 1 x COM ports (1 x rear) Operating System...

  • Page 8: Appearance

    HQP‐1072 System User Guide  Appearance HQP-1072 Series Front View： 1  2  3  4  Control Panel LEDs The control panel located on the front of the chassis has five LEDs. These LEDs provide you with critical information related to different parts of the system. Overheat/Fan Fail Status Description...
  • Page 9 HQP‐1072 System User Guide  Channel activity for all hard drives. This light indicates hard drive activity on the system when flashing. Power Indicates power is being supplied to the system's power supply units.   This LED should normally be illuminated when the system is operating. Control Panel Buttons There are two push-buttons located on the front of the chassis: a reset button and a power on/off button.

  • Page 10: Setting Up

    HQP‐1072 System User Guide  2. Setting Up HQP-1072 System is a rack-mount server, installed on a 19" rack usually. For the first time, it’s recommended to power on and test the server on the desk, and then assemble it into the rack after successfully booting the server. Follow the instructions to check weather it can be turned on and function normally.
  • Page 11 HQP‐1072 System User Guide  Booting process of HQP-1072 Series System may takes around 30 seconds. Default login password of the Windows 7 system is “HQP”. The screenshot will be like this after you log on Windows 7 system: Now, you can follow the software manual to start the software test of the HQP-series software, see if the software can function normally.

  • Page 12: Installing The Server In A Rack

    HQP‐1072 System User Guide  3. Installing the Server in a Rack After the server has been testified, please follow the instructions to mount HQP-1072 system into a Rack to ensure the stability. Installing the Server into the Rack Confirm that chassis includes the four mounting screws required to mount the chassis into a rack.
  • Page 13 HQP‐1072 System User Guide  Insert the mounting screws into the thru holes in the front of the chassis and through the thru holes in the rack and secure.  ...

  • Page 14: System Maintenance

    HQP‐1072 System User Guide  4. System Maintenance   HQP-1072 System is designed and tested under strict quality control for a long time before delivering to ensure product quality. However, the damages of components are irresistible since the computers are used continuously without shutting down. As the test results indicated, the hard drive, power supply unit and fans account for the most frequently damaged components.
  • Page 15 HQP‐1072 System User Guide  2. You will see there are 2 disk trays in the chassis, one for system disk and one for data disks. System Disk Tray DATA Disk Tray   ...
  • Page 16 HQP‐1072 System User Guide  3. Release the 4 screws on the bottom of the chassis to unlock the system hard disk tray. 4. Release the 4 screws to unlock the abnormal system disk and replace it with a backup. Replace with the backup HDD 5. Screw the system hard disk tray back to the chassis and put the cover back.
  • Page 17 HQP‐1072 System User Guide  6. System restoration Please prepare an external DVD-ROM drive and connect it to the HQP-1072 system. Insert the win7 installation disc then restart the system. Follow the step below to start the system restoration. Windows will first start loading files needed for system restoration. Please click Next to go to the next step.
  • Page 18 HQP‐1072 System User Guide  Please click Repair your computer. When you see this page, please take out the Window7 installation disc and put the Restore CD disc 2/2 into the DVD-ROM drive. Select the option Restore your computer using a system image that you created earlier and click Next.
  • Page 19 HQP‐1072 System User Guide  The system will start scanning for system image backup. In this page, please select the option Select a system image and click Next.  ...
  • Page 20 HQP‐1072 System User Guide  Please choose the system image in the DVD-ROM drive and click Next. Select the date and time of system image and click Next.  ...
  • Page 21 HQP‐1072 System User Guide  Please press Next to go to next step. In this page, please click Exclude disks to exclude the data disks from restoring.  ...
  • Page 22 HQP‐1072 System User Guide  Please select Intel Raid 1 Volume (Disk 1) and press OK. Press Next.  ...
  • Page 23 HQP‐1072 System User Guide  Press Finish. To restore your system for a system image backup, please press Yes. Windows start to restore the system disk from the system image backup.  ...
  • Page 24 HQP‐1072 System User Guide  During system restoring, it will ask you to put the restore disc 1/2 into the DVD-ROM, please do it and press OK. After put the restore disc 1/2 into the DVD-ROM, it will continue to rebuild the system. The system will ask you again to put the restore disc 2/2 into the DVD-ROM, please do it and press OK.
  • Page 25 HQP‐1072 System User Guide  After put the restore disc 2/2 into the DVD-ROM, it will continue to rebuild the system. The system restoration may take about 30 minutes. While system restoration is complete, please remove the external DVD-ROM drive and restart the system. After system restoration, the system can resume its work as usual.

  • Page 26: Data Drive Failed

    HQP‐1072 System User Guide  4.1.2. Data Drive Failed HQP-1072 built-in two 1TB data hard drives mirrored as a data array. When one of these two drives fail, the system can still work normally. But It is suggested to check the status of HDD once a week. The Intel®...
  • Page 27 HQP‐1072 System User Guide  In Manage page, we can see that the system has a SATA SSD system disk(56GB) and a SATA_Array data disk (932GB). 3  4  5  6  Hard disk status may be confirmed either by the icon shown on disk or status column after selecting the disk.
  • Page 28 HQP‐1072 System User Guide  Open the chassis you will see there are two disks stacked together like the picture below. Disk0 indicate the upper disk, and Disk1 indicate the lower disk. According to these information, you can determine which disk should be replaced. If the Disk0 (Port 0) is abnormal, please replace the upper disk with backup.
  • Page 29 HQP‐1072 System User Guide  1. To replace a troubled data disk, please release these 5 screws to remove the cover of the chassis. (Rear 1, Left 2, Right 2) 2. You will see there are 2 disk trays in the chassis, one for system disk and one for data disks.
  • Page 30 HQP‐1072 System User Guide  3. Release the 4 screws on the bottom of the chassis to unlock the data hard disk tray. 4. Release the 4 screws to unlock the disk and replace it with a backup. (In the picture below, we use Disk0 for example.) Replace with the ...
  • Page 31 HQP‐1072 System User Guide  5. Reverse the steps to fasten the hard drive and hard drive tray to the chassis. 6. Connect the cables according to the picture below. (Port0 to Disk0 & Port1 to Disk1) 7. Put the cover back and fasten the 5 screws in step 1 to finish the hard disk replacing.
  • Page 32 HQP‐1072 System User Guide  After replace the troubled data hard disk, please reconnect the system with the power cord, monitor, keyboard and mouse. Follow the step below to start system restoration. 8. Power on the system and wait the Intel® Rapid Storage Technology program to launch.
  • Page 33 HQP‐1072 System User Guide  It will ask you to select a disk to rebuild the volume. Please check the back disk and press Rebuild. 11. Waiting until the rebuild finish. (It may take probably 3 hours to rebuild a 1TB hard drive.) 12. When rebuild is completed, the system can function normally.  ...

  • Page 34: Replacing Power Supply

    HQP‐1072 System User Guide  Replacing Power Supply When power supply failed, the system will not be able to power on. Please follow the step below to replace it with a backup power supply. Remove the cover of the chassis. Disconnect all wiring from the bad power supply. Remove the four screws which hold the power supply in the chassis.
  • Page 35 HQP‐1072 System User Guide  Replace the bad power supply with a backup and screw back the 4 screws in step 3. Connect all power cord and put the cover of the chassis back to finish replacing power supply.  ...

  • Page 36: Replacing System Fan

    HQP‐1072 System User Guide  Replacing System Fan   If the system fan not work normally, the system might get overheat and crash. So, regular clean up is necessary. When system fans fail, be sure to replace them as soon as possible. The following steps will show you how to replace a system fan.
  • Page 37 HQP‐1072 System User Guide  Take a new fan and put it into the fan housing, remember to place it in the right direction. (Check the picture below) Front side of the chassis Connect the fan cables to the motherboard and put the cover back on the chassis to finish system fan replacement.  ...

  • Page 38: Routine Maintenance Work

    HQP‐1072 System User Guide  Routine Maintenance Work   Aside from the above mentioned maintenance work, it is suggested to   execute the following routine maintenance work for a better broadcast quality and ensuring that HQP-1072 System can work in long time operation.    Regularly Restart HQP-Series Software It is suggested to restart HQP-Series software every week during off-peak hours.

  • Page 39: Spare Parts

    HQP‐1072 System User Guide  5. Spare Parts System Backup SSD   HQP-1072 System built-in a 60GB SSD (SLC) as the system disk to provide higher system efficiency and reliability. You can purchase an additional system backup SSD (mirrored from the original system disk), when there is some problem with the system disk (system crash or infect by virus), you can use it to replace the bad hard disk for system recovery.

  • Page 40: Power Supply

    HQP‐1072 System User Guide  Power Supply   HQP-1072 System use one 200W high-efficiency power supplies (80 PLUS Platinum Certified). If the power supply failed, you can follow Chapter 4.2 to replace it with a backup power supply.              ...
