G-Tech P7202 Instruction Manual

Rf wireless slim keyboard and mouse desktop
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RF Wireless Slim Keyboard and Mouse Desktop
The wireless keyboard and optical mouse operate with digital radio technology. There is no
connecting cable to pile up desktop. The keyboard and mouse use radio frequencies to
send data to the receiver, which forwards these to your computer. You can use the
keyboard and mouse on any computer equipped with a free USB interface. There are two
channels, CH1 and CH2 for your selection.
CE marking
This equipment complies with the requirements of Directive 1999/5/EC of the European
Parliament and Commission from 9 March 1999 governing Radio and Telecommunications
Equipment and mutual recognition of conformity.
BATTERY INSTALLATION
The cordless optical mouse uses two AAA rechargeable batteries.
The cordless keyboard uses two AAA batteries.
pic.2
PDF created with FinePrint pdfFactory trial version
Instruction Manual
pic.1
Version: GT3.0
1.
Press the tab to remove the battery
compartment cover on the bottom of the
mouse.
2.
Insert two supplied AAA rechargeable
batteries in the battery compartment
according to the polarity marked inside.
3.
Replace the cover.
1.
Press the tab to remove the battery
compartment cover on the bottom of the
cordless keyboard.
2.
Insert two AAA batteries according to the
polarity marked inside.
3.
Replace the cover.
http://www.fineprint.com
- 1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P7202 and is the answer not in the manual?

Questions and answers

Related Manuals for G-Tech P7202

Summary of Contents for G-Tech P7202

  • Page 1 RF Wireless Slim Keyboard and Mouse Desktop Instruction Manual Version: GT3.0 The wireless keyboard and optical mouse operate with digital radio technology. There is no connecting cable to pile up desktop. The keyboard and mouse use radio frequencies to send data to the receiver, which forwards these to your computer. You can use the keyboard and mouse on any computer equipped with a free USB interface.

  • Page 2: Battery Notes

    BATTERY NOTES Dispose of old batteries promptly and properly. Do not burn or bury batteries. Use only fresh batteries of the required size and recommended type. Do not mix old and new batteries, different types of batteries (standard, alkaline or rechargeable), or rechargeable batteries of different capacities.

  • Page 3: Setting Channel

    SETTING UP THE ID WIRELESS LINK Set up your Keyboard and Mouse ID wireless link separately. Slim Keyboard Press CONNECT key on the receiver after booting the system. The green LED inside the connect key will light on. To set up the keyboard wireless link, press CONNECT key on the bottom of the slim keyboard.
  • Page 4 is as bellows: For mouse to set channel If you decide to use “CH 1” for mouse, Remove the battery compartment cover on the mouse, turn the button inside the compartment to “ CH 1 “ and replace and close the cover. Press the “...

  • Page 5: Battery-Low Warning

    SETTING UP THE ID WIRELESS LINK The operation is same as that BATTERY LOW WARNING On the Mouse The mouse has a battery-low indicator, which will light RED when battery has low power. Low power indicator Pic7 On the Keyboard When you press any key, the power indicator &...

  • Page 6: Software Installation

    charging, the mouse power indicator will also light green. Notes: Do not use non-rechargeable batteries; only use rechargeable batteries. The recharge power is available while the computer is powered off if the input electricity is available. Be sure the indicator lights red when charging the batteries. SOFTWARE INSTALLATION Note: Before installing the software, in order to achieve a successful installation, please uninstall other...
  • Page 7 Stop screen output (Scroll Lock) Using Your Mouse The mouse has five buttons: left button, right button, mid-button, fourth and fifth buttons. The mid-button (wheel) functions both as a wheel and a button, which can be used as a button or for scrolling, e. g. in documents or on Internet pages. For scrolling in documents, roll the wheel forward Right button Wheel button...

  • Page 8: Troubleshooting And Tips

    Internet pages, which are organized into categories including Shopping, Finance, etc. Information on the key assignment and how you can configure the keys is contained in the software’s online help. Outside the Internet browser, the keys have the standard functions. Increasing the volume This key increases the volume of the connected loudspeakers.
  • Page 9 Mouse or Keyboard Not Detected 1. Make sure you have installed the batteries correctly, See BATTERY INSTALLATION. 2. Make sure the batteries have enough power, See BATTERY LOW WARNING. 3. Make sure the receiver is correctly connected. See CONNECTING THE RECEIVER. Set the communication code once more See SETTING UP THE ID WIRELESS LINK.
  • Page 10 CAUTION To avoid interference with an aircraft's electronic systems, do not use your wireless desktop during a flight. Make sure you have removed the batteries from yo ur wireless keyboard and mouse UL CAUTION PDF created with FinePrint pdfFactory trial version http://www.fineprint.com...
  • Page 11 PDF created with FinePrint pdfFactory trial version http://www.fineprint.com...
