Strong International Ballantyne PRO-35 Instruction Manual

35 mm projector mechanism
Hide thumbs

Advertisement

Quick Links

Download this manual
Film-Tech
The information contained in this Adobe Acrobat pdf
file is provided at your own risk and good judgment.
These manuals are designed to facilitate the
exchange of information related to cinema
projection and film handling, with no warranties nor
obligations from the authors, for qualified field
service engineers.
If you are not a qualified technician, please make no
adjustments to anything you may read about in these
Adobe manual downloads.
www.film-tech.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ballantyne PRO-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Strong International Ballantyne PRO-35

  • Page 1 Film-Tech The information contained in this Adobe Acrobat pdf file is provided at your own risk and good judgment. These manuals are designed to facilitate the exchange of information related to cinema projection and film handling, with no warranties nor obligations from the authors, for qualified field service engineers.
  • Page 2 BALLANTYNE PRO-35 35mm Projector Mechanism Rev. 2/98 STRONG INTERNATIONAL a division of Ballantyne of Omaha, Inc. 4350 McKinley Street Omaha, Nebraska 68112 USA Tel 402/453-4444 • Fax 402/453-7238...
  • Page 5 2943 Oil Fill Hose Oil Level Ring (Do Not Overfill) P8014 Flywheel & Pulley 2786-D Washer 3041 Screw 2783 Cap Intermittent Movement...
  • Page 6 2812 Pulley (on Pro-35) 54-67-0 Idler 2937 Timing Belt 2829 Pulley (on Model VII)
  • Page 7 FILM PATH Framing Aperture Pressure Pad Retaining Screw Film Gate Release Lever Framing Lever...
  • Page 10 (Open) Upper (Feed) Pad Roller, Closed Sprocket Assembly Pad Roller, Closed (Pad Roller, Lower (Holdback) Open) Sprocket Assembly...
  • Page 11 Quarter Panel Framing Lever...
  • Page 14 Coupling Assembly Mounting Screw, (1) of (3) Rack Teeth Intermittent Sprocket Assembly...
  • Page 16 Ballantyne replacement parts are available through any authorized Strong International Dealer. Please order by Part Number and Description. All returned goods must display a Return Authorization Number issued to an authorized Strong International Dealer. STRONG INTERNATIONAL a division of Ballantyne of Omaha, Inc, 4350 McKinley Street Omaha, Nebraska 68112 U.S.A.
  • Page 17 MAIN FRAME 2749 2651 2727 2973 2920 2921 2752N 2752-S 2922 2751 2650...
  • Page 18 VERTICAL SHAFT ASSEMBLY 2744 2900 2901 2716 2815 2815 2902 (Early Models) 2901 2903 2900 2745...
  • Page 19 HORIZONTAL SHAFT ASSEMBLIES 2712 2952 2904 2651 2972 2715 3052 2905 2900 2717 2968 2812 2951/4397 2972 2904 2901 2717 2665R-1 2973 2906 2952 2712 2973 2905 2715 2951/4397 2906 2901 2900 2835 3052...
  • Page 20 SHUTTER SHAFT ASSEMBLY P-1432 3001 2803 2651 4481 28-65-3 2768D 4482 10181 2754-R2 2915 2805 2915-S 41-51606 2901 10181 2804 4397 2763 2720-B 2720-A H-3328 3066 2971 2912 3261 2967 2802-C 3008 2913 3006 2918 2922 2847 41-51111 2800 2801 2917 2786 2765R-1...
  • Page 22 HORIZONTAL FRAMING ASSEMBLY 23-60-0 2920 3112 2921 2728 (as req’d.) 2949 2923 2857 3008 2924 2975 2973 3078 2806...
  • Page 23 VERTICAL FRAMING ASSEMBLY 2676 7-111 2743 (ref.)* 2733 (ref.)* * Order 21-52005 2931 2932 2920 2932 2921 2746 2815...

  • Page 24: Lens Mount Assembly

    LENS MOUNT ASSEMBLY 3057-C 2778 3057-C 2654 3057-W 2985 2807-R SC-2345-BB 2771 2771 2985 3075 2653 R 41-51229 41-51229 3057-W 2923 3057-C 2777 2985 2767-R 2773-R 3057-C 2978 3057-W 2808S 2772 2977 2775 2776R 2980 Assembly No. 24-42-09...
  • Page 25 2927 5116 3935 3935...
  • Page 26 FILM TRAP ASSEMBLY 41-51040 2859 2769R-2 7-115 41-51040 3552 3521 2832 2993 41-51040 7-115 2844 2988 2787 3638 3522 S1280E 3520 41-51081 3552 2788 3553 Assembly No. 23-32-79 2993...
  • Page 27 FILM GATE ASSEMBLY 3090 3047 2927 10535 2908 2909 2985 2784-R 2837 Assembly No. 29-88-4...
  • Page 28 FILM GATE PRESSURE PAD ASSEMBLY 7460A 2827X 7459A 7369 7458-12 W 278 E S1280E N227E S1279E 7370 E67L2 7458-12 W 278 E S1280E N227E S1279E 7461 7459A 7458-12 E67L2 E67L2 3016 Sold as Assembly Only 2838 S278E S1280E N227E S1279E Assembly No.
  • Page 30 GATE DETENT MOUNTING ASSEMBLY 2756 4446 4447 2820 2981 2687 2674 2910 2969 2935 2908 2969 2927 2933 2683 2688-R 2909 2809 2707 2969 2686 Assembly No. 21-23-36 2989...

  • Page 31: Pad Roller Assemblies

    PAD ROLLER ASSEMBLIES 4273 2909 SC-1236 2967 2907 4516 2753 2910 2908 7-21 3097 2911 2967 4521 Assembly No. 21-86-83 (Upper) 4520 2966 SC-1236 2907 2909 4274 2967 2753 2910 2908 7-21 2966 2967 3097 2722 4521 Assembly No. 21-86-84 (Lower) 4517 4520 2911...
  • Page 32 2909 4251 41-51263 4254...

  • Page 33: Intermittent Movement

    INTERMITTENT MOVEMENT Assembly No. 82-02-84-6 2943-A 3232 P8014 21-20001 3086 2750 2900 2982 2901 2940 2950 2719 3610 2786-D 3596B 3609 3041 2945 2783 2681 3596B 2962 3250 3637 2684R 2725 2940 2754 2660 2940 2661 2838-D...
  • Page 35 INTERMITTENT SPROCKET ASSEMBLY 3101 3045 4826 3088 2929 2701 7343 7371 3043 2930 3237 4826 Assembly No. P8352...
  • Page 36 FRAMING COUPLER 2678 2959-W 2959-W 3057-W 2709 3057-W 2959-C 3951 3005 3057-C Assembly No. 62-31-59...
  • Page 37 TOP PLATE SUB-ASSEMBLIES 2938 3064 7-126 3208 2761-A 3026 3064 3064 2761-A 3211 2766 2923 3210 2749...
  • Page 38 BELT TENSION ROLLER 41-70023 3027 3245-48 2924 31121/32 2923 2926 2924 7-109 2926 Assembly No. 54-67-0 2650...

  • Page 39: Oil Drain

    FILM GUIDE ROLLER Assembly No. 26-15-0 2851 P8105 3028 2923 OIL DRAIN Assembly No. 37-67-9 2822 2821* 2946 2975 2823* 5363 * Order 37-67-9A 5358...
  • Page 40 DRIVE MOTOR, 115 V.AC INDUCTION Assembly No. P8236 4474 41-51603 2936 4474 4432 41-51605 2758 2996-GE 3264-GE 4440 3077 3264-GE 3077...
  • Page 41 DRIVE MOTOR, 230 V.AC INDUCTION Assembly No. P8237A 4474 41-51603 4474 2936 4433 41-51605 3697-R1 3264-GE 4444 3077 4441 3264-GE 3077...
  • Page 42 DRIVE MOTOR, 115 V.AC SYNCHRONOUS 3251 4216 3410 3098 3407-O 3099 3405-A 3407-I 3745 3479 To convert existing Pro-35 from Induction to Synchronous Motor Drive, Order Kit No. P8021.
  • Page 44 CHANGEOVER & FRAMING LIGHT POWER SUPPLY Assembly No. 6968 Relay Socket 21-40142 Pulsed Relay 21-45050 Installed Held Relay 21-45038 Installed...
