Summary of Contents for MoFi Electronics UltraDeck
- Page 2 IN THE BOX UltraDeck™ Turntable Power Cord Dustcover Counterweight Delrin Platter Additional Parts ‰ • Hex Wrench (2) Platter Belt • Anti-skate Weight • Stylus Brush RCA Interconnects...
- Page 3 ASSEMBLY Make sure UltraDeck™ is placed on a level surface If cartridge is not included, follow cartridge manufacturer’s installation instructions Carefully place the Delrin platter ‰ on the bearing hub, making sure it spins freely. Install the turntable belt, with the...
- Page 4 Notch 1: 4g – 6g cartridges Notch 2: 6g – 8g cartridges Notch 3: 8g – 10g cartridges Notch 4: 10g – 12g cartridges If UltraDeck™ came with the UltraTracker™ cartridge preinstalled, use Notch 3.
- Page 5 VTA AND AZIMUTH If UltraDeck™ came with UltraTracker™ preinstalled, the following steps were completed at the factory After setting tracking force and anti-skate, adjust the tonearm’s height. Loosen the hex screw located at the base of the tonearm to raise or lower the arm height,...
- Page 6 CONNECTIONS AND LEVELING Install the RCA interconnects and ground wire to your preamp’s phono section, and then connect the power cord from the turntable to any outlet or power conditioner of your choice. If the turntable is on an unleveled surface, place a bubble level on the platter, then carefully adjust each foot until the turntable’s...
- Page 7 STYLUS CARE AND DUSTCOVER Back to Front Keep your records clean by using a high-quality record brush and record cleaner After each play, gently clean your stylus, always brushing back-to- front using the supplied stylus brush. We also recommend using a liquid stylus cleaner such as Mobile Fidelity LP#9.
- Page 8 StudioDeck™ UltraDeck™ Motor 300 RPM AC Synchronous 300 RPM AC Synchronous Speeds 33 1/3 RPM, 45.0 RPM 33 1/3 RPM, 45.0 RPM Platter 3.88 lb Delrin 6.8 lb Delrin ‰ ‰ Wow & Flutter 0.017% – 0.025% 0.017% – 0.025%...
- Page 9 MoFi Electronics – 1811 W Bryn Mawr Ave Chicago IL...
