WALK BEHIND SWEEPER
Operating Instructions (ENG)
MODELS: RWB36
Read instructions before operating the machine.
B
980200 03/11/08

Advertisement

Table of Contents
loading

Summary of Contents for Radius RWB36

  • Page 1 WALK BEHIND SWEEPER Operating Instructions (ENG) MODELS: RWB36 Read instructions before operating the machine. 980200 03/11/08...
  • Page 2 MACHINE DATA LOG/OVERVIEW MODEL _______________________________________ DATE OF PURCHASE __________________________ SERIAL NUMBER ______________________________ SALES REPRESENTATIVE # _____________________ YOUR DEALER Name: __________________________________________________________________________________________________ Address: _______________________________________________________________________________________________ Phone Number: _________________________________________________________________________________________ 980200 05/28/04...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Machine Data Log/Overview........2 GROUP PARTS LIST Table of Contents..........3 Frame/Body Group..........5-1 HOW TO USE THIS MANUAL Brush/Belt Group..........5-3 Motor/Drive Group..........5-7 How to use this Manual........1-1 Battery/Filter Group..........5-11 Brake Group............5-13 SAFETY EC Declaration of Conformity......5-15 Warranty.............
  • Page 4: How To Use This Manual

    HOW TO USE THIS MANUAL This manual contains the following sections: The SAFETY section contains important information regarding hazard or unsafe practices of the machine. HOW TO USE THIS MANUAL Levels of hazards is identified that could result in SAFETY product or personal injury, or severe injury resulting OPERATIONS in death.
  • Page 5: Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using a battery powered appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. WARNING: To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual.
  • Page 6: Hazard Intensity Level

    HAZARD INTENSITY LEVEL The following symbols are used throughout this guide as indicated in their descriptions: HAZARD INTENSITY LEVEL There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY. The level of hazard intensity is determined by the following definitions: WARNING WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
  • Page 7: Security Warning

    SECURITY WARNING IMPORTANT NOTE Precautions to be taken before attempting to start machine: To facilitate transport, the side brush, the handlebar and the upper casing have not been assembled in their actual work position. Therefore before using he machine, assemble them as shown in this manual. IMPORTANT: The Manufacturer cannot and will not be held responsible for damage in the event the machine is used for purposes other than those it was designed for.
  • Page 8: Operations

    OPERATIONS UNPACKING THE MACHINE Mounting the Handlebar: Unpack the machine with the utmost care; avoid 1. Loosen the handlebar fixing screws. carrying out any operation that could damage your 2. Put the handlebar in most comfortable work unit. position. 3. Tighten the handlebar fixing screws. Once it has been unpacked, check for damage of any visible component.
  • Page 9: Controls

    OPERATIONS STARTING THE MACHINE CONTROLS CAUTION The machine must be used by authorized personnel only. DO NOT leave the machine UNATTENDED when it is running. Turn off power and remove the key before leaving the machine. To start the machine carry out the following steps: 1.
  • Page 10: Cleaning Waste Bins

    OPERATIONS CLEANING THE WASTE BINS Before cleaning of waster bins, make sure all pertinent parts are off the machine. CAUTION Wastes must be disposed of strictly in accordance to local, state or governing law in your area. Front Bin 1. Lift and turn the two bin locks. 2.
  • Page 11: Maintenance

    MAINTENANCE FILTER MAINTENANCE BATTERY MAINTENANCE The filter is one of the machine main components. It is essential for the best results from your machine. If you notice WARNING that dust forms when the machine is at work, check the filter. The battery should be serviced in a properly ventilated area.
  • Page 12 MAINTENANCE REPLACING AND ADJUSTING THE SIDE BRUSH Adjusting: 1. Open the top bonnet. NOTE: By pulling up Replacing: the handle, the brush will turn idle. This will 1. Lift the front part of machine. allow you to position the brush in a place 2.
  • Page 13 MAINTENANCE REPLACING THE BELTS (Cont.) Inner Side Flaps: 1. Lift the front part of the machine. Side Brush Belt: 2. Remove and retain the screws that secure the flaps 1. Remove side brush belt from to the frame. grooves of pulley A. 3.
  • Page 14 MAINTENANCE REPLACING THE TRACTION CABLE 6. Remove the bad motor and replace it by carrying out the above operations in reverse To replace the cable, proceed as follows: order. 1. Remove the upper bonnet of the machine. NOTE: Make sure the motor is mounted level 2.
  • Page 15: Service Schedule

    MAINTENANCE CAUTION All routine and special maintenance must be carried out by authorized personnel or service center. Always use manufactures spare parts. WARNING Before performing any maintenance on machine, be sure power is OFF and batteries are disconnected. SERVICE SCHEDULE Every Every Every...
  • Page 16: Frame/Body Group

    FRAME/BODY GROUP 980200 05/28/04...
  • Page 17 FRAME/BODY GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500226 UPPER COVER, BLUE RWB36 1500002 FIXING SCREW 86309760 FRONT DRAWER 1500213 RUBBER HAND GRIP 50941 LABEL, WINDSOR LOGO NOT SHOWN 1500214 HOPPER LOCK CLAMPS 1500231 BACK DRAWER 1500215 REAR HOPPER GASKET...
  • Page 18: Brush/Belt Group

    BRUSH/BELT GROUP 36 35 980200 05/28/04...
  • Page 19 BRUSH/BELT GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500242 TRACTION HANDLE 1500030 SIDEBRUSH DRIVE LEVER 1500035 DRIVE CABLE SHEATH 1500036 DRIVE CABLE 1500029 TURNED ADJUSTER DIA. 7 1500037 DOWEL 5 X 6 1500040 SCREW 8 X 25 1500038 WIRE FIXING SCREW 1500015 WASHER 8 X 17 1500039...
  • Page 20 BRUSH/BELT GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500065 OUTER SNAP RING DIA. 15 1500070 BEARING HK 1012 1500091 PULLEY DIA. 27 X 15 1500062 DOWEL 6 X 5 1500060 KEY 5 X 5 X 15 1500090 SPACER 1500092 BELT DIA.
  • Page 21 BRUSH/BELT GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500065 OUTER SNAP RING DIA. 15 1500070 BEARING HK 1012 1500091 PULLEY DIA. 27 X 15 1500062 DOWEL 6 X 5 1500060 KEY 5 X 5 X 15 1500090 SPACER 1500092 BELT DIA.
  • Page 22 NOTES 980200 05/28/04...
  • Page 23: Motor/Drive Group

    MOTOR/DRIVE GROUP 980200 05/28/04...
  • Page 24 MOTOR/DRIVE GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500268 SCREW 5X 20 1500286 HANDLE FOR BUTTERFLY 1500057 NUT, M5 1500270 BALL DIA. 5 SPRING FOR AIR CONVEYOR 1500281 5 X 16 ELASTIC CATCH 1500285 CABLE FOR BUTTERFLY 1500284 AIR CONVEYOR 1500093 WASHER 8 X 24 1500017...
  • Page 25 MOTOR/DRIVE GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500279 REDUCERS TOOTHED SHAFT 1500275 KEY 5 X 5 X 20 1500276 TOOTHED GEAR 1500278 REDUCERS STRAIGHT TOOTHED GEAR 1500282 MAIN BROOM ADJUSTING RAIL 1500052 BLOCK NUT M6 1500283 WASHER 15 X 28 1500065 OUTER SNAP RING DIA.
  • Page 26 NOTES 5-10 980200 05/28/04...
  • Page 27: Battery/Filter Group

    BATTERY/FILTER GROUP 5-11 980200 05/28/04...
  • Page 28 BATTERY/FILTER GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500302 DASHBOARD PLATE 1500184 NUT, M4 1500152 KEY SWITCH 1500154 SCREW 5 X 20 1500304 BATTERY CHARGER CONNECTOR 1500167 UNLOCKING FILTER HANDLE 1500166 NUT, M8 1500205 FILTER 1500306 FILTER, POLYESTER OPTIONAL 1500223 FILTER GASKET 1500161...
  • Page 29: Brake Group

    BRAKE GROUP 5-13 980200 05/28/04...
  • Page 30 BRAKE GROUP SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 1500328 PARKING BRAKE BUSHING 1500329 PIVOT 1500330 PARKING BRAKE SPRING 23 1500331 SEEGER H UNI7434 DIA 6 1500332 BUSHING 1500333 PARKING BRAKE BLOCK 1500334 PARKING BRAKE PIVOT 700 1500335 PARKING BRAKE SPRING 46 1500336 PIVOT 1500337...
  • Page 31 711ET – 720ET – 721ET – 731 ET - 740ET – 900 EH - 700EH – Teknova srl heeft het technische rapport betrekking hebbende op het onderhavige model BPS-28 – SWP-2800 – SCOUT 28 – RWB28 – RWB36 – 460 3610- opgesteld SCOUT 24 -Vi forsikrer under eget ansvar at folgende produkt som omfattes af denne erklæring er i...
