Related Manuals for ATL AM4
Summary of Contents for ATL AM4
-
Page 5: Installation
SCOPE INTRODUCTION EXAMPLE APPLICATIONS AM4 BACK TO BACK SET-UP AM4 TO INTERNET VIA A DSLAM CONSTRUCTION AM4 FRONT PANEL AM4 REAR PANEL 4.3.1 REAR CONNECTIONS 4.3.2 CABLES 4.3.3 POWER SUPPLY INSTALLATION LED POWER ON SEQUENCE DEFAULT SETTINGS SETTING UP USING THE WEB BROWSER... - Page 6 6.4.5.2 AT THE CPE UNIT ADVANCED SETUP 6.5.1 SHDSL 6.52 6.5.3 BRIDGE 6.5.4 VLAN 6.5.4.1 802.1Q VLAN 6.5.4.1 PORT-BASED VLAN 6.5.5 ROUTE 6.5.6 NAT/DMZ 6.5.6 VIRTUAL SERVER 6.5.7 FIREWALL 6.5.7.1 BASIC FIREWALL SECURITY 6.5.7.2 AUTOMATIC FIREWALL SECURITY 6.5.7.3 ADVANCED FIREWALL SECURITY 6.5.7.4FILTERING RULE FOR SMTP CONNECTION STATUS 6.6.1...
- Page 7 7.3.2.7 ADMIN 7.3.2.8 UTILITY COMMAND LINE INTERFACE 7.4.1 SETTING UP THE CLI INTERFACE 7.4.2 SETTING UP THE MENU DRIVEN INTERFACE COMMISSIONING SPECIFICATION AM4 DIMENSIONS TRANSMISSION PERFORMANCE 9.2.1 2-WIRE NOISE FREE RANGE 9.2.2 4-WIRE NOISE FREE RANGE ENVIRONMENTAL 9.3.1 TRANSPORTATION 9.3.2 STORAGE 9.3.3...
-
Page 8: Compliance Notes
COMPLIANCE NOTES 10.1 TELECOMMUNICATION STANDARDS ORDERING INFORMATION APPENDIX 1 GLOSSARY... - Page 12 The AM4 is a desktop unit housed in a non-flammable plastic case (UL94 rating V0). AM4 FRONT PANEL The front panel of the AM4 is shown below. The LEDs show the current state of the AM4 Front Panel of AM4 4-port Modem...
- Page 13 LINE DC-IN CONSOLE Rear Panel of AM8 4-wire/4-port Modem...
- Page 52 Index Protocol Direction Action Source Destination Dest. Port Schedule Inbound Permit External Internal Always Outbound Permit Internal External >1023 Always Outbound Permit Internal External Always Inbound Permit External Internal >1023 Always Either Deny Always Packet Direction Source Destination Protocol Dest. Port Action (Rule) Inbound 192.168.3.4...
- Page 53 Packet Direction Source Destination Protocol Dest. Port Action (Rule) Inbound 10.1.2.3 171.16.3.4 6000 Deny (E) Outbound 171.16.3.4 10.1.2.3 5150 Deny (E) 172.16.3.4:6000 10.1.2.3:5150 Internet Firewall Attacker X11 Server Update Filtering Rule Index Protocol Direction Action Source Destination Source. Port Dest. Port Inbound Permit External...
- Page 54 Rule Source Address Destination Address Action 10.0.0.0 172.16.6.0 Permit 10.1.99.0 172.16.0.0 Deny Deny Rule Source Address Destination Address Action 10.1.99.1 172.16.1.1 Deny (B) 10.1.99.1 172.16.6.1 Permit (A) 10.1.1.1 172.16.6.1 Permit (A) 10.1.99.1 172.16.1.1 Deny (C) 192.168.3.4 172.16.6.1 Deny (C) Rule Source Address Destination Address Action...
- Page 70 COMMAND DESCRIPTION enable The enable option allows the user to modify the current user privilege setup The setup option allows the user to con gure the modem status The status opyion displays the current status of the modem The show option displays the current hardware and software con guration show write The write option allows the user to write the new con guration to the FLASH...
- Page 87 COMMAND DESCRIPTION The shdsl status option displays the status of the line rate, SNR margin, TX power, attenuation and the CRC error of the unit. It also displays the SNR shdsl margin, attenuation and CRC error for the remote unit (when two modems are configured back to back) The wan status option displays the status of the 8 PVC's route...
- Page 97 0.4mm 0.5mm 0.6mm Line Speed 26 AWG 24 AWG 22 AWG Kbps 12.8 16.0 10.6 13.2 11.4 11.0 11.0 10.5 10.5 10.1 10.0 1024 1088 1152 1216 1280 1344 1408 1472 1536 1600 1664 1728 1792 1856 1920 1984 2048 2304...
- Page 98 0.4mm 0.5mm 0.6mm Line Speed 26 AWG 24 AWG 22 AWG Kbps 12.8 16.0 10.6 13.2 11.4 11.0 11.0 10.5 10.5 1024 10.1 1152 10.0 1280 1408 1538 1664 1792 1920 2048 2176 2304 2432 2560 2688 2816 2944 3072 3200 3328 3456...
- Page 100 Front View Loop A Loop B Pin Number Description No Connection RxD (0) TxD (1) No Connection No Connection 9 way Male D-Type CTS (0) RTS (1) No Connection...
