Wireless Bluetooth Mouse User's Guide
PRIMAX ELECTRONICS LTD.
MOBTEJO
Model：
Thanks for purchasing Bluetooth Optical Mouse. This creative and easy-to-use Bluetooth Mouse
will bring you a whole new wireless life experience.
Appearance Drawing
System Requirement
Mouse compatible with standard Microsoft Mode.
IBM compatible PCs running Windows Operating System which supports USB devices.
If your computer doesn't have built in Bluetooth function, please make sure that you have the
Bluetooth Dongle. Bluetooth Dongle is not included in this product.
Main Features
Switchable CPI among 800/1000/1200/1600(some bluetooth mouse have no this function).
Features comfortable, ergonomic design
Built-in software solutions with Bluetooth human interface device and comply with the
standard version of the Bluetooth SIG Bluetooth 2.0
Work with Windows 98, ME, 2000, XP and Vista OS
AA alkaline battery x2
Frequency band: 2.402 - 2.480GHz unlicensed ISM band
Receiving sensitivity: -75bm (standard)
Operation distance: 10m
Operating temperature: 0~55°C
Operation Humidity: 10%-85% RH at 25°C
Storage Temperature: -20~+60°C
Storage Humidity: 5%-95% RH at 25°C
Precaution
! The optical mouse cannot work on a glass or mirror surface. Avoid operating this mouse on a
glossy surface. Otherwise, this mouse may not operate normally.
Advertisement
Table of Contents
Related Manuals for Primax Electronics MOBTEJO
Summary of Contents for Primax Electronics MOBTEJO
- Page 1 Wireless Bluetooth Mouse User’s Guide PRIMAX ELECTRONICS LTD. MOBTEJO Model： Thanks for purchasing Bluetooth Optical Mouse. This creative and easy-to-use Bluetooth Mouse will bring you a whole new wireless life experience. Appearance Drawing System Requirement Mouse compatible with standard Microsoft Mode.
-
Page 2: Installation Guide
! For consideration of saving battery power, it is strongly recommended to operate an optical mouse on a bright surface with fine texture to obtain lower power consumption of the Agilest high illumination LED. A very dark surface will cause higher power consumption. ! For a better transmission distance, avoid to use this device on a metal plate or desktop because a large surface of iron, aluminum. - Page 3 Note: If being unused after 5 minutes, the mouse will transfer to the battery save mode. Just double click the left button will reactivate the mouse. Once connected, after you drag off the dongle or turn off the computer, double click the left button will reactivate the mouse, no need for reconnecting. Also, if you press the Connect Button inadvertently or some abnormal disconnection occurs during using, please reconnect the mouse.
- Page 4 2. Wait till the Mouse is found, select mouse, click “Next”. 3. Select” No Password”, click “Next”, the system will install the new facility automatically. C. Match on IVT Software 1. Make sure that the Bluetooth function is active. Double click the Bluetooth Icon, open the Management window, select “Search for Bluetooth facilities”...
- Page 5 2. Click the Bluetooth Mouse founded, click the right button for “Refresh Service”. 3. Select the Bluetooth Mouse again, click the right button for “Connect-Bluetooth Input Service”, the system will auto install the HID facility. After that you can use your Bluetooth Mouse at ease. FAQ: If unable to connect the Bluetooth Mouse to the computer, or the Mouse work unconventionally, please try the steps below:...
-
Page 6: Fcc Statement
reconnecting. Also, if you press the Connect Button inadvertently or some abnormal disconnection occurs during using, please reconnect the mouse. If this is not available, please open the Bluetooth Dongle Software window, delete or disconnect the mouse (as the picture shows), then reconnect. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
