PRODUCT NAME: CD-ROM DRIVE
MODEL NUMBER: 120D, 160D, 200SD, 240SD, 240D, 320JD, 320D
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCC COMPLIANCE STA TEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
INFORMATION TO USER:
This equipment has been tested and found to comply with the limits of a Class digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occurred a
particular installation, if this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
1.
Reorient / Relocate the receiving antenna.
2.
Increase the separation between the equipment and receiver.
3.
Connect the equipment into an outlet on a circuit difference from that
which the receiver is connected.
4.
Consult the dealer or an experience video/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the users anthority to operate the equipment.
CONTENTS
1. INTRODUCTION
1.1 FEATURES
1.2 POWER SAVE MODE
1.3 SAFETY NOTICE
2.PRECAUTIONS FOR INSTALLATION, OPERATION AND HANDLING
2.1 INSTALLATION PRECAUTIONS
CD-ROM DRIVE UNIT
INSTRUCTION MANUAL
REV. 1.0
Interface: IDE/ATAPI
FCC
DECLARATION OF CONFORMITY
to

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 120D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cyberdrive 120D

  • Page 1 Interface: IDE/ATAPI DECLARATION OF CONFORMITY PRODUCT NAME: CD-ROM DRIVE MODEL NUMBER: 120D, 160D, 200SD, 240SD, 240D, 320JD, 320D FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE FCC COMPLIANCE STA TEMENT: This device complies with part 15 of the FCC Rules.

  • Page 2: Table Of Contents

    7.1 COMMONLY ENCOUNTERED PROBLEMS AND THEIR SOLUTIONS 1. INTRODUCTION 1.1 FEATURES . 1.8MBytes/s (120D), 2.4Mbytes/s (160D), 3.0Mbytes/s (200SD), 3.6Mbytes/s (240SD,240D), 4.8Mbyters/s (320JD, 320D) data transfer rate. . Half height, 5.25 inch form factor. . Motorized tray loading, Open/Close is controlled by the EJECT button or by a software command or mechanical eject.

  • Page 3: Handling Precautions

    1. To avoid error, do not move the CD-ROM drive during operation. 2. Do not operate the CD-ROM drive in a high temperature, high humidity environment. 3. When placing a disc in the tray, be careful not to touch or scratch its surface. 2.3 HANDLING PRECAUTIONS 1.

  • Page 4: Specifications

    AUDIO DIGITAL ANALOG DC INPUT ATAPI RGGL +5 G G +12 ....... .

  • Page 5: Error Rates

    (1) Disc diameter 12cm, 8cm (2) Disc capacity 660MBytes ( mode 1, 12cm discs ) (3) Data transfer Rate 1.8MBytes/s (120D), 2.4mbytes/s (160D) 3.0MBytes/s (200SD), 3.6MBytes/s(240SD,240D) 4.8MBytes/s (320JD,320D) (4) Access time 1/3 stroke average 150ms* (120D), 130ms*(160D), 110ms* (200SD, 240SD, 240D)

  • Page 6: Environmental Conditions

    (1) Power requirements DC + 5V ± 5% DC + 12V ± 10% Voltage Current 0.35A (max.) 1.7A (max.) (2) Dimensions ( WxHxD ) 146mm x 41.3mm x 203mm (3) Weight 1000g 2.2 lb. 4.5 ENVIRONMENTAL CONDITIONS MTBF 100,000 POH OPERATING NON-OPERATING Temperature...

  • Page 7: Prerequisite For Installation

    6.1 PREREQUISITE FOR INSTALLATION For user with MS-DOS version under 6.0 1. Contact local proper representative to obtain a copy of MSCDEX.EXE file (version 2.22 or above). 2. Copy the MSCDEX.EXE file onto the DOS directory (ex: C:\DOS) 6.2 CD-ROM DEVICE DRIVER INSTALLATION 1.

  • Page 8: Device Driver (Atapicd.sys) Parameter List

    line C:\CDROMDRV\MSCDEX /V /D:CD003 /M:10 to your AUTOEXEC.BAT file. After the modification procedure is completed, the final display below will be shown. The installation is successful. You must reboot your computer to activate the modifications that were performed. Do you want to reboot now? If, instead, you select NO, this display will be shown.

  • Page 9: Windows 95' Nt & Os2 Warp

    the function of each parameter. Use a text editor, such as MS-DOS 'EDLIN' or 'EDIT', to modify the appropriate line in your AUTOEXEC.BAT file. The syntax of the MSCDEX.EXE entry in AUTOEXEC.BAT is : [drive:][path] MSCDEX.EXE /D:device name[/M:n][/E][/V] [/L:drive letter] Note : The actual MSCDEX.EXE command line in the AUTOEXEC.BAT file is not truncated and should be placed entirely on one line.
  • Page 10 the address port of the CD-ROM drive. If no sound comes from the speakers: 1. Have the connections between the LINE OUT jacks and the input terminals of the amplifier and/or speakers been properly made? 2. Is power to the amplifier and/or speakers turned on? If no sound comes form headphones: 1.
