Summary of Contents for Dafra DRT510
- Page 1 DRT510 Operation Manual PAGE 1 PLEASE SPEND 2 MINUTES READING THESE INSTRUCTIONS BEFORE USING YOUR NEW RATCHET RIVNUT TOOL. TRUST US, IT WILL SAVE YOU TIME AND INCONVENIENCE IN THE LONG RUN.
- Page 2 DRT510 Operation Manual PAGE 2 Ratchet Rivnut & Rivstud Setting Tool – DRT510 TOOL CAPACITY Rivnuts Metric: M5, M6, M8 and M10 – all styles & materials. UNC: 3/16”, 1/4", 5/16” and 3/8” – all styles & materials TOOL SPECIFICATIONS Net weight: 1.20kgs...
- Page 3 DRT510 Operation Manual PAGE 3 SETTING UP THE TOOL 1. With the tool facing as pictured, set the ratchet switch in the UP position. 2. Holding the forward handle still, rotate the rear handle clockwise until it clicks. 3. Rotate the rear handle anti- clockwise 1 –...
- Page 4 DRT510 Operation Manual PAGE 4 Setting a rivnut. 1. Wind a rivnut onto the mandrel until it comes into contact with the nose tip. If the tool is setup correctly, you should see 1 mandrel thread protruding from the end of the rivnut.
- Page 5 DRT510 Operation Manual PAGE 5 Setting a rivnut continued. 3. Hold the forward handle still and rotate the rear handle right to left. The rivnut will pull up and form a flange on the rear side of your work piece.
- Page 6 DRT510 Operation Manual PAGE 6 Setting a rivnut continued. 6. Rotate the splined knob on the back of the mandrel anti- clockwise to remove the mandrel from the set rivnut. 7. To set another rivnut, the tool must be returned to position 1.
