DURAVIT DL 7541 Installation Instructions

Leben im Bad
Living bathrooms
Delos

Installation instructions

A A
mm inch
600 23 5/8"
Instructions for use
Power supply 110 V GFCI outlet must be provided on-site.
Distance between sensor and reflecting surfaces => 3" (75 mm).
Without sensor switch = 0 (wall switch required), sensor left = L, sensor right = R.
The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
Though designed for the wet environment, direct contact with water should be avoided, for example, when showering.
We reserve the right to make technical improvments and design modifications to the products illustrated.
MAL_Delos_DL7541/15.04.1
B B
mm inch
412 16 1/4"
2x 100
4x S8
# F30368
4x 5,5x50
# DL 7541
